Rigorous Evaluation Usability Testing
What is Usability Testing? • Formal and rigorous testing using a structured process • Validate adherence to interaction requirements • “Actual” users who perform realistic and representative tasks • Utilize a functional prototype • Quantitative and qualitative usability measures
Chuckism • Usability Evaluation instead of Usability Testing • Want to put participants at ease • The word test automatically invokes feelings of anxiety • Don’t use the word test on - Recruiting artifacts (flyers) - Consent forms - Label on door to testing room - first thing the user sees when they get to the evaluation • Your conversation (“We are evaluating the software and not you.”)
Usability Measures • Ease of learning (learnability)—how fast can a user learn to accomplish basic tasks? • Ease of remembering (memorability)—can a user remember enough to be effective the next time? • Efficiency of use—how fast can an experienced user accomplish tasks? • Error frequency and severity (understandability/comprehensibility) - how often do users make errors, how serious are they, and how do users recover from them? • Engaging (Subjective satisfaction)—how much does the user like using the system?
Usability Evaluation - Ethics
Awareness of Regulations • Human Subjects Protocols • You must be fully aware of the regulations imposed by the various institutions and regulatory bodies that pertain to your experimental design • Health and well being of subjects • The U.S. Department of Health and Human Services Web site • http://www.hhs.gov/ohrp/ • Informed consent form – all participant users should read and sign • Explains the study, risks (if any), and contact name for questions/issues • Written consent to record participants (video and audio) • How you may or may not use their image/voice
Advantages and Limitations of Usability Evaluation • Advantages • Discover usability issues before deployment • Particularly important for a market driven product • Begin to build user loyalty • Gain knowledge for future releases • Disadvantages • Artificial context • No guarantee of product acceptance • Result skew if true user demographic missed • May not be the most efficient and cost effective method for usability evaluation
Comparative • Can be formative or summative - Formative: what do we need to change vs competition, with which design should we proceed - Summative: verify we are better than competition • Between your own designs/prototypes • Vs. competition • Methodology - Compare to pre-determined standard or benchmark - Use performance and preference criteria - Between or within-subjects design
Format of the Test Plan 1. Purpose/goals 2. Research questions (usability requirements) 3. Target Audience 4. Design of the Usability Evaluation 5. Logistics 6. Data Collection Methodology 7. Deliverables Description
1. Purpose • High level reasoning for performing the test at this time • Need sound reasons – NOT … • Everyone else has a testing program • Goal examples from 3.3 of Tullis/Albert - Comparing products (you vs. competition) (summative) - Comparing designs - Evaluate Information Architecture (IA) - Problem discovery - Evaluate critical feature or product - Impact of change on established user base
2. Research Questions / Usability Requirements • Describes issues/questions that need to be resolved and focuses the research • Precise, accurate, clear and measurable (or observable) • Helps you plan your test design Your test results will need to answer these questions • If a test task scenario isn’t related to one of the questions, it should be removed • If you don’t have a test task scenario to answer one of these, need to add one
2. Research Questions / Usability Requirements • Too unfocused and vague - Is the current product usable? - Is product ready for release? • Better … - Can users successfully install the software using the setup guide without assistance? - Do the screens reflect the end user’s conceptual model? - Can users perform task xyz in under 3 minutes? - Can users perform task abc without instruction (first-use intuitive.)? - Do users prefer prototype A vs. prototype B? - How quickly & easily can users perform picture upload from a mobile device?
Activity Outline a first version of your project test plan: • Define the purpose of the usability evaluation - Which system will you compare your design against? • Define the usability evaluation goals • Use the Test Plan template
3. Target Audience • Participants should be real users • You don’t need a large sample (8-15 or so) to get good feedback • Recruit users with the following characteristics: • Availability • Responsiveness • Objectivity • Diversity – background, experience, responsibility, … • Represent primary user roles
4. Design of the Usability Evaluation • Introductory paragraph - Layperson’s explanation of how you will conduct the test • Test Design - Type of study (within-, or between- subjects) - Number of participants - Duration of each session - Number and types of tasks performed by each participant - Matrix design
Test Design: Intro Paragraph Example In this between-subjects test, each participant will sit through a one-hour usability study session. Approximately 15 minutes of each session will be used to explain the session to the participant, review basic background information with the participant, and conduct a pre-test questionnaire. During the middle 30 minutes of the session, participants will use the XYZ software to complete 4 tasks, which the moderator will administer. Each participant will be asked to use the think-aloud protocol while conducting the tasks. The last 15 minutes will be used to conduct the post-test questionnaire and debriefing.
Within-Subjects Test Design • A single group of participants • Essentially comparing each participant to themselves • Compare Designs - Each participant uses both interfaces - Preferred interface measures • Repeated measures - Example: Multiple trials of same task, Compare time on task between trials - Can be used to measure “learnability” of product • Advantage: fewer participants required • Disadvantage: carryover/transfer of learning - Mitigate via counterbalancing
2 Products – 1 Group – 1 Set of Tasks A B Within-Subjects Test Design
Between-Subjects • Comparing Interfaces - Randomly assign participants to groups - Randomly assign all participants - Randomly assign males to each group then females to ensure equal distribution between groups - Or balance novice and expert between groups • Comparing groups - Manually assign to group based upon characteristic - group of experts vs. group of novices
2 Products – 2 Groups – 1 Set of Tasks A B Between-Subjects Test Design
Disadvantage of Within-Subjects What if Product A leaves a bad taste? What if participants learned something using Product A that made Product B easier to use? *Carryover/transfer of learning A B Think: Taste Test
Counterbalancing • Alternate order of tasks • Alternate order of interface use • Alternate order of both interfaces and tasks
Within-Subjects: Comparing Interfaces *More Typical Compare Interfaces Tasks Participants A 1 B 1 A 2 B 2 A 3 B 3 A 4 B 4 P 1 B 1 A 1 B 2 A 2 B 3 A 3 B 4 A 4 P 2 A 1 B 1 A 2 B 2 A 3 B 3 A 4 B 4 P 3 B 1 A 1 B 2 A 2 B 3 A 3 B 4 A 4 P 4 A 1 B 1 A 2 B 2 A 3 B 3 A 4 B 4 P 5 B 1 A 1 B 2 A 2 B 3 A 3 B 4 A 4 P 6 A 1 B 1 A 2 B 2 A 3 B 3 A 4 B 4 P 7 B 1 A 1 B 2 A 2 B 3 A 3 B 4 A 4 P 8 A n = Tasks for Interface A B n = Tasks for Interface B Tasks A n equivalent to task B n in their respective interfaces
Session Outline • General description of what will happen during session • Contains high-level outline with timings - Pre-session setup (5 minutes) - Intro and informed consent (5 minutes) - Background questionnaire (5 minutes) - Tasks (not a list of tasks) (30 minutes) - Post task questionnaire (5 minutes) - Post-session debrief and questionnaire (10 minutes)
Activity Work on the design of the usability evaluation section • Define the user tasks • Design the task matrix • Design the session outline • Use the Test Plan template
5. Logistics • Schedule • Location • Resources – people and equipment • Materials, e.g. task scenarios – how will tasks be used in the user environment?
Constraints on Usability Testing • Time to … • Design, prepare, and administer the test • Analyze the results • Financial • Equipment and software • Laboratory time • Recording media • [Participant compensation ] • Space— to perform the usability test • A dedicated laboratory or room is recommended.
People • Tester roles • Test project leader, expert • Moderator – interacts with the participant during the test • Data logger / Note taker • [Technician] – operational responsibility • Optional observers: • Other development team members not involved in the test • Other stakeholders
