Technical training for the wind turbine industry Presentation of Danish Wind Power Academy, 2013 [Module index END] DWPA Presentation 2013 GB-R10 Page 1

Technical training for the wind turbine industry History Strong background.  Danish Wind Power Academy (DWPA) was founded in 2004 by technicians with strong experience from the wind turbine industry. Innovative educational concept.  We have developed an innovative educational concept for technical personnel at all levels.  Today our instructors together count on almost 60 years of practical “hands-on” experience with the challenges from all kind of turbines, but most important…. our instructors use precisely this valuable knowledge in our training courses.  High flexibility and adaptability with reference to the participants skills and backgrounds for targeted and efficient training.  Wide range of training courses divided within the following fields of study: - Mechanics - Hydraulics - Electrics - WTG controller and operation. Mission  To get turbines perform as desired by technicians and operation staff achieving understanding of technology and operation . [Module index END] DWPA Presentation 2013 GB-R10 Page 2

Technical training for the wind turbine industry Target group, clients & products Target group.  We focus on the technicians as their knowledge and experience are decisive for operation of the wind turbines, but today we find more than 60% of our participants on our open training classes being O&M management seeking transparency. Furthermore we have a targeted program for new employees entering the wind turbine industry with absolutely no previous WTG background Clients.  Our typical clients is IPP´s, turbine owners and operators, 3 rd party service providers, and not at least a large number of very important sub suppliers to the industry  Upwind Solutions  DONG Energy  Mitsubishi Power Systems  Vattenfall  Frontier Pro  E.ON Climate & Renewables  Outland Energy Services  RWE  Availon  Juwi Wind  B9 Energy Ltd  Renewable Energy Systems  Vestas Wind Technology Ltd  EDF Renewables  Siemens Wind Power A/S  Pattern Energy  ABB  DUKE Energy  Bosch Rexroth  AES  SKF  NAES  ZF Wind Power  Meridian Energy  CC-Jensen  AGL Energy Ltd  kk-electronic  Pacific Hydro [Module index END] DWPA Presentation 2013 GB-R10 Page 3

Technical training for the wind turbine industry Concept About the DWPA training wheel.  We see a training course as a dynamic 1. Uncovering process starting with the uncovering of a of the need. need for more knowledge or practical experience.  If the need can be met in the best way by a customer adjusted training course, the process shown will then be passed through step by step. 2. Exchange of  When the acquired knowledge and 5. Anchoring experience are anchored, you will see documentation the favourable profit of the training course in your organisation.  However, the process does not stop here. The need to develop knowledge lasts for ever and therefore the training process will be never-ending.  Please visit our website at www.danishwpa.com for more detailed description of our training wheel. 4. Training 3. Development [Module index END] DWPA Presentation 2013 GB-R10 Page 4

Technical training for the wind turbine industry Your advantages Achieving a better operation  The technicians will be capable of making the wind turbines operate satisfactorily from an operating perspective, but most importantly understand “generation mindset”: Downtime will be minimized Availability will be maximized  This means efficient operation of your wind turbines. Optimizing turbine operation  Your own operational data is used to generate the most efficient training, targeted at the errors in your turbines  Reduced expensive shutdowns by early fault recognition  Build up of “knowhow” and transparency in your operation Optimizing the skills  The targeted training optimizes your staff in proportion to your needs. Help for uncovering the future needs for resources  As a result of the analysis of the skills by means of tests. Anchor your technicians.  Reduce the flow of technicians thru your organization by training them to understand their job. Certification.  Ensuring the needed new knowledge by the means of targeted multiple choice test. [Module index END] DWPA Presentation 2013 GB-R10 Page 5

Technical training for the wind turbine industry ROI by training Training cost:  8 technicians  4 back office operation management  5 days, NEG-Micon NM64/1500 Turbine training  Total training cost EUR 28.875 Gained efficiency:  Reduced scheduled maintenance downtime with 90 hours from 315 to 225 hours  Unplanned outage loss reduced with 380 MW/h from 400 to 20 MW/h  Availability improved with 4,28% from 94,80 % to 97,90 % ROI: Capacity Factor % Pct.  Turnover increase EUR 20.800 per month 35%  Training cost EUR 29.000 30%  ROI 42 days 25% 20%  Turnover 1 year after training EUR 220.000 including training 15% 10% Wind conditions: 5% 0%  The EUR 220.000 improved turnover was further more 6 month before 6 month after 6 month before achieved under poor wind and reduced CP factor. training in training in training in 2010 2010 2011 [Module index END] DWPA Presentation 2013 GB-R10 Page 6

Technical training for the wind turbine industry Training ready within 39 different wind turbines      SWT-1.3-62 CS B39/500 V44-600 NM43/600 M1500-600/150      SWT-2.3-82 VS B44/600 V47-660/200 NM44/750 M1800-600/150      SWT-2.3-93 B62/1300 V52-850 NM48/750 M1500-750/175      SWT-2.3-101 B54/1000 NM52/900 M1800-750/175 V66-1.65     SWT-2.3-108 NM54/950 B76/2000 V66-1.75     SWT-3.6-107 B82/2300 V80-1.8 NM64/1500    SWT-3.6-120 V80-2.0 NM72/1500   V100-2.0 NM82/1500   NM72/1650 V90-1.8/2.0   NM82/1650 V82-1.65  V90-3.0  V100-3.0 [Module index END] DWPA Presentation 2013 GB-R10 Page 7

Technical training for the wind turbine industry Available training types within each turbine Module Dura- Type of Target group Max Leaning objectives tion training partic. Turbine 5 days Theoretical Techs, operation, 12 Understand all documentation, complete turbine technology and function description, asset and risk manual operation and all typical Achilles heels in the turbine, create foundation for management trouble shooting. Understand electrical, hydraulically and mechanical isolation as well as turbine safety matters for safe work in the turbine. Maintenance 2-4 days Practical in field Techs, operation 6 Understand the maintenance checklist and related work instructions, focus on management “unwritten” checkpoints and well known turbine issues, refreshing manual operation IRL 1-4 days Theoretical Techs, operation 12 Well known typical issues from the specific turbine, and how techs and site Operational management management can become more proactive in the matter of dealing with these often challenges seen issues. Understand error and consequens errors for better trouble shooting Main 2-5 days Theoretical & Techs, operation, 5-12 General or turbine specific blade or gearbox training with focus on understanding Practical asset and risk impact from daily operation, damage development, how to inspect and report in a component management proper way, as well as how to maintain the specific main component. 2-3 days Practical in field Techs, site, 6 Focus on site specific trouble shooting related to selected systems and components, Field support operation turbine training practical refreshment, how to increase unit / park performance with management reference to operational condition. Training developed upon client turbine operation data and error logs 2 days Theoretical Operation, asset, 8 Strong focus on the individual turbines performance by being able to understand and Performance risk, and evaluate operational data and the consequences of these in the daily operation. surveillance contractual Improve your operational excellence and become able to question your own or your management OEM operation staff. 2-3 days Practical in field Asset and risk 6 Site specific challenges and turbine conditions, with reference to installation / EOW management, commissioning punch lists and available operational data, unit / park performance EOW inspecting evaluation. Complete “walk down” is carried out techs On-line 2-8 hours Remotely by Techs, operation, 12 Technical support planned to work in extension with e.g. reliability meetings to pass team viewer asset and risk on the solutions for performance improvement to the techs in the field support management On-site 1-? days Practical, on-site Techs, operation, Maximum 3 “Firefighting”, root cause analysis on specific systems and components, support with consultancy by asset and risk Groups of 2 planning and understanding work instructions for e.g. gearbox, generator exchange “Panic our instructor management participants etc.. support” [Module index END] DWPA Presentation 2013 GB-R10 Page 8
