Performance Measurement in 3G Networks Qiang Xu*, Alexandre Gerber ++ - PowerPoint PPT Presentation

AccuLoc: Practical Localization of Performance Measurement in 3G Networks Qiang Xu*, Alexandre Gerber ++ , Z. Morley Mao*, Jeffrey Pang ++ * University of Michigan Ann Arbor ++ AT&T Labs Research Visibility of Device in Cellular Network X X


  1. AccuLoc: Practical Localization of Performance Measurement in 3G Networks Qiang Xu*, Alexandre Gerber ++ , Z. Morley Mao*, Jeffrey Pang ++ * University of Michigan Ann Arbor ++ AT&T Labs Research

  2. Visibility of Device in Cellular Network X X QIANG XU MOBISYS 2011 @ WASHINGTON D.C. 2

  3. Which Sector Has High RTT? sector a-1  …  RNC 1: RTT = 500ms user’s RTT = 500 ms sector d-2  …  RNC 2: RTT = 500ms QIANG XU MOBISYS 2011 @ WASHINGTON D.C. 3

  4. Problem Statement: Accurately Localize Performance Measurement • How inaccurate is the current performance measurement localization? • How to make performance measurement localization be more accurate? • Expected benefits for cellular network operators – Assign measured performance to the correct network elements – Monitor the health of individual network elements – Detect/identify performance anomaly QIANG XU MOBISYS 2011 @ WASHINGTON D.C. 4

  5. Challenge: Complexity, Cost & Capability • Complexity – No Infrastructure/protocol supports • Cost – Collecting/delivering RNC events consumes significant resource • Capability – RNC events are limited to only certain RNCs QIANG XU MOBISYS 2011 @ WASHINGTON D.C. 5

  6. AccuLoc: Leverage Mobility Patterns • Key: user mobility patterns are restricted and predictable – Users usually move around within a small set of sectors – Sectors are correlated if always visited by the same users • Infer mobility patterns – identify top correlated sectors – BIGRAPH: a snapshot of RNC events – HANDOVER: lightweight handover counters • Compatible to all RNCs • Localize performance measurement based on mobility patterns QIANG XU MOBISYS 2011 @ WASHINGTON D.C. 6

  7. Previous Studies • Mobility patterns discovery – Understanding Individual Human Mobility Patterns [Gozalez et al. Nature’08] – Mobility Detection Using Everyday GSM Traces [Sohn et al. UbiComp’06] – Extracting a mobility model from real user traces [Kim et al INFOCOM’06] • Cellular network characterization – Metastability of CDMA Cellular Systems [Antunes et al. MobiCom’06] – Profiling Users in a 3G Network Using Hourglass Co-Clustering [Keralapura et al. MobiCom’10] – Mobility: A Double-Edged Sword for HSPA Networks [Tso et al. MobiHoc’10] QIANG XU MOBISYS 2011 @ WASHINGTON D.C. 7

  8. Outline • Introduction • Data sets • Inaccuracy of the current performance measurement localization • AccuLoc: infer/leverage mobility patterns • Adopt AccuLoc in performance anomaly detection QIANG XU MOBISYS 2011 @ WASHINGTON D.C. 8

  9. Data Sets IPFlowRecords: end-to-end perf. measurement PDPSetupLocations: initial network locatio n RNCGroundTruth: actual network location BIGRAPH Inaccuracy Characterization QIANG XU MOBISYS 2011 @ WASHINGTON D.C. 9

  10. Outline • Introduction • Data sets • Inaccuracy of the current performance measurement localization • AccuLoc: infer/leverage mobility patterns • Adopt AccuLoc in performance anomaly detection QIANG XU MOBISYS 2011 @ WASHINGTON D.C. 10

  11. Localization Inaccuracy • Network location has levels of precision, i.e., sector/site/RNC) level – The sector-level accuracy is ~30% – The RNC-level accuracy is ~70% QIANG XU MOBISYS 2011 @ WASHINGTON D.C. 11

  12. Lessons from Inaccurate Localization • Accuracy at higher aggregation levels (i.e., site/RNC) is low • Mobility patterns cannot be captured by such static clusters as site/RNC QIANG XU MOBISYS 2011 @ WASHINGTON D.C. 12

  13. Outline • Introduction • Data sets • Inaccuracy of the current performance Measurement localization • AccuLoc: infer/leverage mobility patterns • Adopt AccuLoc in performance anomaly detection QIANG XU MOBISYS 2011 @ WASHINGTON D.C. 13

  14. How BIGRAPH Works 1. Build correlation graph sector  vertex • likelihood  edge • 2. Cut correlation graph Goal: minimize • edge lost Constraint: cluster • size QIANG XU MOBISYS 2011 @ WASHINGTON D.C. 14

  15. Evaluate BIGRAPH • Cluster-level localization accuracy changes over the size of cluster • BIGRAPH’s accuracy is 70% (cluster size is 4), which is comparable to the RNC-level accuracy QIANG XU MOBISYS 2011 @ WASHINGTON D.C. 15

  16. Evaluation: BIGRAPH’s Accuracy over Time • 1 week: accuracy is consistently high (~70%) • 5 months: accuracy is still reasonably high – BIGRAPH’s accuracy is comparable to the RNC- level accuracy (cluster size is 32) QIANG XU MOBISYS 2011 @ WASHINGTON D.C. 16

  17. Outline • Introduction • Data sets • Inaccuracy of the current performance measurement localization • Acculoc: infer mobility patterns • Adopt AccuLoc in performance anomaly detection QIANG XU MOBISYS 2011 @ WASHINGTON D.C. 17

  18. Inaccurate Location’s Impact on Performance Anomaly Detection user’s RTT increases 10x user’s RTT is 50 ms user’s RTT is 500 ms QIANG XU MOBISYS 2011 @ WASHINGTON D.C. 18

  19. Detecting RTT Spikes • “Performance of clusters” captures RTT spikes better QIANG XU MOBISYS 2011 @ WASHINGTON D.C. 19

  20. Contribution • Identified and characterized measurement localization challenge in cellular networks • Developed AccuLoc, a system to accurately localize performance measurement using mobility patterns • Applied AccuLoc to performance anomaly detection with good results • “Accuracy vs. measurement overhead” is a common tradeoff – Other types of cellular networks, e.g., EV-DO – Future cellular networks, e.g., LTE QIANG XU MOBISYS 2011 @ WASHINGTON D.C. 20

  21. Thanks, Questions, & Answers
