www.thalesgroup.com/germany PAM FRA Holger NEUFELDT Patrick LEFEVRE Recapitulation: Surveillance Technologies 2 / Surveillance Technologies distributed centralised cooperative cooperative non- independent dependent cooperative Radar

  1. www.thalesgroup.com/germany PAM FRA Holger NEUFELDT Patrick LEFEVRE

  2. Recapitulation: Surveillance Technologies 2 / Surveillance Technologies distributed centralised cooperative cooperative non- independent dependent cooperative Radar ADS MSPSR Multilateration active passive active passive passive / ADS-C ADS-B PCL MSPSR PSR SSR active Mode A/C 1090 ES Airport UAT TMA Mode A/C/S non- cooperative VDL-4 WAM cooperative independent WAM = Wide Area Multilateration WAM/MLKAT Training Thales Shawnee - Part I Dec 1, 2011

  3. Fundamental Principle of Multilateration 3 / Transponder Reply Aircraft transponders reply or Mode S quitter to interrogations from SSR MLAT/WAM CPS 1 calculates surfaces or multilateration systems, and emit unsolicited of constant time squitters/extended squitters difference 2 Signals received and time stamped Multilateration 3 by Ground Stations Ground Stations 4 (GS) Ground System Output: Track Multilateration communications Aircraft reports Surveillance ATC reports Central network Data Display Processing Processor System Station (CPS) WAM/MLKAT Training Thales Shawnee - Part I Dec 1, 2011

  4. Multilateration 4 / Based on 1090 MHz signals (Mode A/C/S, 1090 ES)  Requires >4 receivers with line of sight to target, or,  at least 3 receivers + baro altitude Geometry-dependent – proper site planning is critical  Transmitter required for Mode A/C compatibility  Multi Multilate latera ration tion System System Con Configura figuration tions: s: MLAT: airport surface surveillance  PAM and TMA MLAT: precision approach monitoring or  airport terminal area surveillance Country-wide WAM: en-route surveillance  (Wide Area Multilateration) Same equipment - same software  Thales Multilateration System: MAGS (Multilateration Air/Ground Surveillance System) WAM/MLKAT Training Thales Shawnee - Part I Dec 1, 2011

  5. PAMFRA Project 5 / Custo Customer mer  DFS Locations of DFS Public-sector sites Locations the of Federal Armed Forces (Bundeswehr) Privately-owned sites Main Task Main ask  Provide Multilateration Surveillance within 128x80 NM coverage region around Frankfurt International Airport Source: Fraport AG PAM FRA Overview - WAC February 2013 - HN

  6. PAM FRA required Performance Main Par Main Parameter ameters  Output Probability of Detection: PD ≥ 97%  Up to 500 targets Mode A/C & S in coverage at any one time  Reporting interval: 1 second,  Direct plot output (no coasting, extrapolation or smoothing)  Horizontal Position Accuracy: HPA ≤ 50m RMS (150 m for ED -142)  Probability of Code Detection: PCD ≥ 97% (Mode A), ≥ 96% (Mode C)  Altitude Timeout 1s  Dual synchronisation required (GPS and RF Time Beacon)  N-1 redundancy Main cons Main constr traints aints  High Radio Frequency environment (most loaded 1090 MHz environment)  High traffic load (>500 WAM targets seen in physical coverage)  Difficult traffic mix (gliders, ultralights, helicopters, military, air transport,…) 6 PAM FRA Overview - WAC February 2013 - HN

  7. Coverage Requirements PAM FRA 7 / Wiesbaden Airport Frankfurt/Hahn Airport Frankfurt/Main Airport PAM FRA Overview - WAC February 2013 - HN

  8. Siting Concept  DFS concluded a comprehensive initial site survey presenting a selection of more than 80 sites for tenderers to choose from  Thales identified 34 sites (12 of these for airport GND alone) and their respective role  Main driver: low level visibility, rather than power budget Omni  Re-use existing sites as far as practial Antenna  Requires system adaptability: antenna types, EMC, communication, packaging, lightning protection, etc.  Confirmed findings in final site survey Sector Antenna Omni Antenna 8 PAM FRA Overview - WAC February 2013 - HN

  9. Site selection: Good sites do exist, but... .. ...many .many ot othe hers rs ca came me be before fore – an and d th they ha ey have ve simi similar lar ne need eds  No space on mast  Top position occupied  Strong transmitters  Harmonics close to the 1090 MHz frequency  Icefall may impact antenna‘s life  Daily lightning strikes 9 PAM FRA Overview - WAC February 2013 - HN

  10. Siting Model Als lso o modell modelled: ed:  all N-1 cases Position Performance Model Selected Sites  all performances RF Sync Performance Model Interrogation Performance Model  Various target altitudes 10 PAM FRA Overview - WAC February 2013 - HN

  11. Typical PAM FRA Ground Station Sites 11 PAM FRA Overview - WAC February 2013 - HN

  12. WAM Sensor Equipment AX680 Receiver • Digital, software-defined radio • 1090 ES ADS-B Decoding • Hot-swap elements WAM Ground Stations Central Processing Station Small Indoor Cabinet Regular Indoor Cabinet Outdoor Cabinet 12 PAM FRA Overview - WAC February 2013 - HN

  13. System Integration Primary ATM System RadNet MaC/S CMD SDR P1/ATCAS RDPS A+B Central ATCAS Processing CMMC LAN Systems further GS RU systems CWP CPS TP A 1 Ground Fallback ATM System further Stations GS RU Core systems LAN FBS COM CPS TP B 2 GS RU LAN PHOENIX CWP RMCDE (ops) GS RU SDR CMS Phoenix CC PAM-FRA WAM Sensor Track Server A+B RMCDE ADS-B Data New interface to existing (test) Evaluation system MWP 13 PAM FRA Overview - WAC February 2013 - HN

  14. WAM Data used by DFS Performance everywhere to Spec Screenshots taken 30NOV2012 – hardly any GA 14 PAM FRA Overview - WAC February 2013 - HN

  15. WAM Data seen by the System Performance Seen on summer weekend: not everywhere >520 targets to Spec Screenshots taken 30NOV2012 – hardly any GA 15 PAM FRA Overview - WAC February 2013 - HN

  16. All Data seen by the System Blue = ADS-B Screenshots taken 30NOV2012 – hardly any GA 16 PAM FRA Overview - WAC February 2013 - HN

  17. Low Level G/A aircraft test flight (EDFH) Evaluation by DFS (S. Stanzel) and Eurocontrol (D. Lambers / J. Steinleitner) EDFH low approach (100 ft GND) EDFH traffic pattern (500-1000 ft GND) Reference: GPS tracker Source: planepictures.net Mode S Antenna 17 PAM FRA Overview - WAC February 2013 - HN

  18. Measured Horizontal Position Accuracy 18 / Calculated by DFS comparing WAM to ADS-B across track error using Across track error known good ADS-B aircraft eliminates latency effects of (DLH, BA, RYR) ADS-B PAM FRA Overview - WAC February 2013 - HN

  19. New WAM Performance Assessment Tool: MAGS Explorer 19 / Main Fe Main Feat atur ures: es:  Main performance parameters for MLAT/WAM  PD / PFD / Gaps  PCD / PFCD  HPA  Latency / Data Age  Usage of different data sources  ASX CAT10, 20, 21, 48, 62  Evaluation considering site specifications  Coverage area / Airport layout & GS position  Configurable requirements & evaluation volumes  Flexible analysis options  Overall or track based analysis  Graphical and numerical result presentation  Result documentation via automatic reporting function Title of presentation: 26/02/2013

  20. PAM FRA actual Performance Main Par Main Parameter ameters  Output Probability of Detection: PD ≥ 97% OK  Up to 500 targets Mode A/C & S in coverage at any one time OK  Reporting interval: 1 second, OK  Direct plot output (no coasting, extrapolation or smoothing) OK  Horizontal Position Accuracy: HPA ≤ 50m RMS (150 m for ED -142) OK  Probability of Code Detection: PCD ≥ 97% (Mode A), ≥ 96% (Mode C) OK  Altitude Timeout 1s OK  Dual synchronisation required (GPS and RF Time Beacon) OK  N-1 redundancy OK ´ Type approval by regulator, SAT passed: MAGS is compliant to PAM FRA Requirements 20 PAM FRA Overview - WAC February 2013 - HN

  21. 21 / Global Surveillance WAM/MLKAT Training Thales Shawnee - Part I Dec 1, 2011

  22. Technologies: A dilemma for ANSPs… 22 / Conventional Highly mature, Surveillance continuously improving, Technologies : widely deployed technologies, PSR, SSR Mode S cornerstone of CNS infrastructures New Surveillance Maturing solutions, more & more Technologies: proven references and increasing WAM, ADS-B operational deployment WAM/MLKAT Training Thales Shawnee - Part I Dec 1, 2011

  23. The answer : a Global Surveillance approach 23 / Made of the best mix of MLAT, ADS-B & Radars ADS-B RADAR WAM Surveillance Solution Find the composite surveillance solution best matching ANSPs needs WAM/MLKAT Training Thales Shawnee - Part I Dec 1, 2011

  24. Enabling for global surveillance implementation Implemen Implementi ting ng Gl Glob obal al Su Surveill rveillan ance ce req requires uires  A “common language” applicable to any surveillance technologies:  Requirements  Solution description  Performance  Costs  An Integrated Tooling Suite supporting this common language  Requirements capture  Solution design & sitting  Performance assessment  Solution costing An improved mutual understanding between ANSPs & industry

  25. Enablers for global surveillance implementation (1) 1- Capture of operational requirements CTR A CTR B Class D Class D SFC-3500ft CTR G SFC-3500ft Class D SFC-2500ft CTR F Class D CTR C SFC-2500ft Class A CTR E SFC-2500ft Class D CTR D Class D SFC-2000ft SFC-2000ft 19500 ft 2 layers, Update < 4 s (6000 m) 3 layers, Update < 4 s 3 layers, Update < 1 s 0 ft First focus on needs, not on solution…
