Overview of Query Evaluation [R&G] Chapter 12 CS4320 1
Overview of Query Evaluation � Plan : Tree of R.A. ops, with choice of alg for each op. � Each operator typically implemented using a `pull’ interface: when an operator is `pulled’ for the next output tuples, it `pulls’ on its inputs and computes them. � Two main issues in query optimization: � For a given query, what plans are considered? • Algorithm to search plan space for cheapest (estimated) plan. � How is the cost of a plan estimated? � Ideally: Want to find best plan. Practically: Avoid worst plans! � We will study the System R approach. CS4320 2
Some Common Techniques � Algorithms for evaluating relational operators use some simple ideas extensively: � Indexing: Can use WHERE conditions to retrieve small set of tuples (selections, joins) � Iteration: Sometimes, faster to scan all tuples even if there is an index. (And sometimes, we can scan the data entries in an index instead of the table itself.) � Partitioning: By using sorting or hashing, we can partition the input tuples and replace an expensive operation by similar operations on smaller inputs. * Watch for these techniques as we discuss query evaluation! CS4320 3
Statistics and Catalogs � Need information about the relations and indexes involved. Catalogs typically contain at least: � # tuples (NTuples) and # pages (NPages) for each relation. � # distinct key values (NKeys) and NPages for each index. � Index height, low/high key values (Low/High) for each tree index. � Catalogs updated periodically. � Updating whenever data changes is too expensive; lots of approximation anyway, so slight inconsistency ok. � More detailed information (e.g., histograms of the values in some field) are sometimes stored. CS4320 4
Access Paths � An access path is a method of retrieving tuples: � File scan, or index that matches a selection (in the query) � A tree index matches (a conjunction of) terms that involve only attributes in a prefix of the search key. � E.g., Tree index on < a, b, c > matches the selection a=5 AND b=3 , and a=5 AND b>6 , but not b=3 . � A hash index matches (a conjunction of) terms that has a term attribute = value for every attribute in the search key of the index. � E.g., Hash index on < a, b, c > matches a=5 AND b=3 AND c=5 ; but it does not match b=3, or a=5 AND b=3, or a>5 AND b=3 AND c=5 . CS4320 5
A Note on Complex Selections (day<8/9/94 AND rname=‘Paul’) OR bid=5 OR sid=3 � Selection conditions are first converted to conjunctive normal form (CNF): (day<8/9/94 OR bid=5 OR sid=3 ) AND (rname=‘Paul’ OR bid=5 OR sid=3) � We only discuss case with no ORs; see text if you are curious about the general case. CS4320 6
One Approach to Selections � Find the most selective access path , retrieve tuples using it, and apply any remaining terms that don’t match the index: � Most selective access path: An index or file scan that we estimate will require the fewest page I/Os. � Terms that match this index reduce the number of tuples retrieved ; other terms are used to discard some retrieved tuples, but do not affect number of tuples/pages fetched. � Consider day<8/9/94 AND bid=5 AND sid=3. A B+ tree index on day can be used; then, bid=5 and sid=3 must be checked for each retrieved tuple. Similarly, a hash index on < bid, sid > could be used; day<8/9/94 must then be checked. CS4320 7
Using an Index for Selections � Cost depends on #qualifying tuples, and clustering. � Cost of finding qualifying data entries (typically small) plus cost of retrieving records (could be large w/o clustering). � In example, assuming uniform distribution of names, about 10% of tuples qualify (100 pages, 10000 tuples). With a clustered index, cost is little more than 100 I/Os; if unclustered, upto 10000 I/Os! SELECT * Reserves R FROM WHERE R.rname < ‘C%’ CS4320 8
SELECT DISTINCT Projection R.sid, R.bid Reserves R FROM � The expensive part is removing duplicates. � SQL systems don’t remove duplicates unless the keyword DISTINCT is specified in a query. � Sorting Approach: Sort on <sid, bid> and remove duplicates. (Can optimize this by dropping unwanted information while sorting.) � Hashing Approach: Hash on <sid, bid> to create partitions. Load partitions into memory one at a time, build in-memory hash structure, and eliminate duplicates. � If there is an index with both R.sid and R.bid in the search key, may be cheaper to sort data entries! CS4320 9
Join: Index Nested Loops foreach tuple r in R do foreach tuple s in S where r i == s j do add <r, s> to result � If there is an index on the join column of one relation (say S), can make it the inner and exploit the index. � Cost: M + ( (M*p R ) * cost of finding matching S tuples) � M=#pages of R, p R =# R tuples per page � For each R tuple, cost of probing S index is about 1.2 for hash index, 2-4 for B+ tree. Cost of then finding S tuples (assuming Alt. (2) or (3) for data entries) depends on clustering. � Clustered index: 1 I/O (typical), unclustered: upto 1 I/O per matching S tuple. CS4320 10
Examples of Index Nested Loops � Hash-index (Alt. 2) on sid of Sailors (as inner): � Scan Reserves: 1000 page I/Os, 100*1000 tuples. � For each Reserves tuple: 1.2 I/Os to get data entry in index, plus 1 I/O to get (the exactly one) matching Sailors tuple. Total: 220,000 I/Os. � Hash-index (Alt. 2) on sid of Reserves (as inner): � Scan Sailors: 500 page I/Os, 80*500 tuples. � For each Sailors tuple: 1.2 I/Os to find index page with data entries, plus cost of retrieving matching Reserves tuples. Assuming uniform distribution, 2.5 reservations per sailor (100,000 / 40,000). Cost of retrieving them is 1 or 2.5 I/Os depending on whether the index is clustered. CS4320 11
> < Join: Sort-Merge (R S) i=j � Sort R and S on the join column, then scan them to do a ``merge’’ (on join col.), and output result tuples. � Advance scan of R until current R-tuple >= current S tuple, then advance scan of S until current S-tuple >= current R tuple; do this until current R tuple = current S tuple. � At this point, all R tuples with same value in Ri ( current R group ) and all S tuples with same value in Sj ( current S group ) match ; output <r, s> for all pairs of such tuples. � Then resume scanning R and S. � R is scanned once; each S group is scanned once per matching R tuple. (Multiple scans of an S group are likely to find needed pages in buffer.) CS4320 12
Example of Sort-Merge Join sid bid day rname 28 103 12/4/96 guppy sid sname rating age 28 103 11/3/96 yuppy 22 dustin 7 45.0 31 101 10/10/96 dustin 28 yuppy 9 35.0 31 102 10/12/96 lubber 31 lubber 8 55.5 31 101 10/11/96 lubber 44 guppy 5 35.0 58 103 11/12/96 dustin 58 rusty 10 35.0 � Cost: M log M + N log N + (M+N) � The cost of scanning, M+N, could be M*N (very unlikely!) � With 35, 100 or 300 buffer pages, both Reserves and Sailors can be sorted in 2 passes; total join cost: 7500. CS4320 13
Highlights of System R Optimizer � Impact: � Most widely used currently; works well for < 10 joins. � Cost estimation: Approximate art at best. � Statistics, maintained in system catalogs, used to estimate cost of operations and result sizes. � Considers combination of CPU and I/O costs. � Plan Space: Too large, must be pruned. � Only the space of left-deep plans is considered. • Left-deep plans allow output of each operator to be pipelined into the next operator without storing it in a temporary relation. � Cartesian products avoided. CS4320 14
Cost Estimation � For each plan considered, must estimate cost: � Must estimate cost of each operation in plan tree. • Depends on input cardinalities. • We’ve already discussed how to estimate the cost of operations (sequential scan, index scan, joins, etc.) � Must also estimate size of result for each operation in tree! • Use information about the input relations. • For selections and joins, assume independence of predicates. CS4320 15
Size Estimation and Reduction Factors SELECT attribute list FROM relation list � Consider a query block: WHERE term1 AND ... AND termk � Maximum # tuples in result is the product of the cardinalities of relations in the FROM clause. � Reduction factor (RF) associated with each term reflects the impact of the term in reducing result size. Result cardinality = Max # tuples * product of all RF’s. � Implicit assumption that terms are independent! � Term col=value has RF 1/NKeys(I), given index I on col � Term col1=col2 has RF 1/ MAX (NKeys(I1), NKeys(I2)) � Term col>value has RF (High(I)-value)/(High(I)-Low(I)) CS4320 16
Schema for Examples Sailors ( sid : integer, sname : string, rating : integer, age : real) Reserves ( sid : integer, bid : integer, day : dates, rname : string) � Similar to old schema; rname added for variations. � Reserves: � Each tuple is 40 bytes long, 100 tuples per page, 1000 pages. � Sailors: � Each tuple is 50 bytes long, 80 tuples per page, 500 pages. CS4320 17
