NANYANG RESEARCH PROGRAMME -SPMS07 DNA Origami Assembled by DNA - PowerPoint PPT Presentation

NANYANG RESEARCH PROGRAMME -SPMS07 DNA Origami Assembled by DNA Dendrimers for Drug Delivery Liu Haoyun Temasek Junior College OVERVIEW 1. INTRODUCTION 2.AIM 3.METHEDOLOGY 4.DISCUSSION OF RESULTS 5.CONCLUSION 1. INTRODUCTION 1.1 DNA


  1. NANYANG RESEARCH PROGRAMME -SPMS07 DNA Origami Assembled by DNA Dendrimers for Drug Delivery Liu Haoyun Temasek Junior College

  2. OVERVIEW 1. INTRODUCTION 2.AIM 3.METHEDOLOGY 4.DISCUSSION OF RESULTS 5.CONCLUSION

  3. 1. INTRODUCTION 1.1 DNA DENDRIMERS  Definition: - Molecules formed by the attachment of DNA molecules to a typically symmetrical core -Basic building blocks of the DNA scaffold in DNA hydrogels

  4. 1. INTRODUCTION 1.2 DNA HYDROGELS  Definition - Polymeric networks formed by DNA dendrimers

  5. 1. INTRODUCTION 1.2 DNA HYDROGELS  Characteristics: - Bio-compatibility - Molecular recognition capacity - Nano-scale control capability

  6. 1. INTRODUCTION 1.2 DNA HYDROGELS  Applications: - Bio-sensing - 3D growing medium - Specific drug delivery

  7. 2. AIM  To synthesize DNA dendrimers and assemble DNA nano-hydrogels that could potentially be used in specific drug delivery

  8. 3. METHODOLOGY  3.1 SYNTHESIS OF DENDRITIC DNA  3.2 PURIFICATION OF DENDRITIC DNA  3.3 SELF-ASSEMBLY OF DNA NANOHYDROGEL

  9. 3. METHODOLOGY 3.1 SYNTHESIS OF DENDRITIC DNA  Synthesis of DNA using long trebler phosphoamidite as the branching reagent through Bioautomation Mermaid 4 via solid phase oligonucleotide synthesis  Synthesized dendritic DNA consisted of 1 loading branch for functionalizing and 3 gelation branches for hybridization

  10. 3. METHODOLOGY 3.1 SYNTHESIS OF DENDRITIC DNA  Cleavage of DNA molecules from the controlled pore glass via incubation in 1ml of 33% NH4OH solution at 25 ° C for 10 minutes  Deprotection of the DNA through controlled heating at 60 ° C in a dry bath

  11. 3. METHODOLOGY 3.2 PURIFICATION OF DENDRITIC DNA  Purification of the dendritic DNA was achieved through Reverse Phase HPLC with polar phase being 0.1 M TEAA pH7 and non-polar phase ACN  DNA was collected in TEAA

  12. 3. METHODOLOGY 3.2 PURIFICATION OF DENDRITIC DNA  Dendritic DNA was incubated in 200µl of 80% acetic acid for 15 minutes for the cleavage of DMT group  Second round of HPLC to separate pure dendritic DNA from the DMT group.

  13. 3. METHODOLOGY 3.3 SELF-ASSEMBLY OF DNA NANOHYDROGEL  200nM purified dendritic DNA was mixed with 200nM of linker DNA  The mixture was heated in 95 ° C dry bath for 10 minutes for DNA annealing and cooled down naturally for self-assembly  Resultant DNA nanohydrogels collected and concentrated though centrifugation

  14. 4. DISCUSSION OF RESULTS 4.1 DNA DENDRIMER SYNTHESIS  Sequence of synthesized dendritic DNA : (CGA TTA CAG CTT GCT)3 D TTTCGA TCG  Molecular weight derived from MALDI-TOF showed a reading of 16640.73

  15. 4. DISCUSSION OF RESULTS 4.1 DNA DENDRIMER SYNTHESIS  Theoretical molecular weight was 16945.16  Synthesized DNA dendrimers were usable

  16. 4. DISCUSSION OF RESULTS 4.2 DNA NANO HYDROGEL SYNTHESIS  Synthesized DNA nanohydrogels was examined under AFM to determine their size  An average size was108.853nm

  17. 4. DISCUSSION OF RESULTS 4.2 DNA NANO HYDROGEL SYNTHESIS  Data collected from AFM verified through DLS  The readings collected from DLS showed an average size of 129.1nm  possibly due to the fact that theDNA nanohydrogel was in vacuum-driedstate in AFM

  18. 5. CONCLUSION  The DNA nanohydrogels were synthesized successfully from DNA dendrimers and are ready for loading of Doxorubicin for drug test

  19. THANK YOU!
