Mounting systems for all types of solar power plants Installation of solar power plants www.solarsk.com.ua
ABOUT THE COMPANY www.solarsk.com.ua Solar Steelconstruction company was founded in 2012 and now is the biggest in Ukraine in the manufacturing and installation of mounting systems in the solar power station. The activity of the company is focused on high-tech manufacturing of mounting systems, construction, and exploitation of solar power plant (SPP), as well as implementing the entire range of installation works. Our company provides a full range of services: • production of mounting systems for SPP • designing of mounting systems • building solar power plants • manufacturing of steel constructions for energy objects (lighting, substations, power transmission towers). During the elaboration of mounting systems , we use only the best world practice combining them with the lightweight steel and aluminum profiles, which allows us reaching the optimal ratio of weight and durability, price and quality. We also consider the individual conditions of the construction site to make sure the ease of installation.
OUR EXPERIENCE www.solarsk.com.ua Solar Steelconstruction company is: • 7 years on the market of alternative energy • over 1200 MW of power of installed SPP • over 1700+ finished roof objects at the territory of entire Ukraine • over 200 finished on-land objects in Ukraine and abroad we use only the certified product that corresponds to the highest international quality standards • • own integrated manufacturing process with the outgoing power of 800 MW a year • the geography of projects embraces Ukraine, Belarus, Moldova, Russia, Germany, Japan, Hungary, Kazakhstan, Italy, Netherlands, and the UK. We do export to: Italy, Germany, Netherlands, Belarus, Sakha Republic, Dagestan, Japan, Armenia, Georgia, Kazakhstan. 120 MW in total. Ukraine: Commercial SPP are equal to 900 MW comprising of 200 objects. Individual SPP comprise of 10 MW, 1000+ objects.
OUR ADVANTAGES www.solarsk.com.ua • Own design department 1200 MW 7000 • Own manufacture • Anticorrosive treatment Implemented commercial PVS objects PVS implemented private facilities for • Delivery of mounting systems ‘turnkey’ 2019 Manufacturer price • • Professional installation • 10-year warranty • After-warranty servicing. 55 000 tonnes 350 MW Implemented PVS for the private sector tonnes Metalwork for the alternative energy Advantages of our product market • Reliability and universality Full compatibility of parts • • Constant availability in stock • Full corrosion protection • We have experience of production of over 800+ MW for SPP Total Construction Management •
OUR PRODUCTION www.solarsk.com.ua The plant for producing mounting systems, Baryshivka city of Kyiv region • the line of cutting • the rolling lines • hot dip galvanizing section К yiv К orzhi The power of manufacturing is 30.000 tonnes a year. The plant for producing the bent profiles, Kyiv city • over 400 standard sizes of profiles Dnipro • preparatory site • the line of longitudinal-transverse cut of rolls • the line of manufacturing of the bent corners the line of manufacturing of the bent channels • • the line of welding • rolling lines. The power of manufacturing is 15.000 tonnes a year The plant for producing mounting systems, Dnipro city • the line of production of clamps the line of making openings • • the line of stamping the details • warehouse. The power of manufacturing of the complex fastening systems is 500 MW a year.
OUR PRODUCTION LINES www.solarsk.com.ua Hydraulic guillotine shear for cutting The line for rolled steel transverse cutting metal Our manufacturing powers: • 4 lines to cut the rolled steel with width 0.3-2 mm and 2-6 mm • 8 profile bending lines to manufacture over 400 standard sizes of the most common types of profiles The manufacturing line for U, C profiles Two manufacturing lines for U, C, Z profiles Over 160 units of equipment to process • metal, including stamping, cutting, welding and so on. • All premises are equipped with overhead cranes and catheads with a lifting capacity of up to5-20 tonnes. More than 300 of standard size profiles
MACHINERY PARK www.solarsk.com.ua Our advantages: • 8 ramming machines Gayk; More than 30 units. specialized construction • machinery; • More than 300 employed installers with work experience and opportunity to stay in the Schengen countries for 180 days; • Availability of medical insurance for installers; • Personnel is equipped with professional HILTI tool • Warranty for workmanship • Constant feedback with customers; • Providing of all necessary documents; • Trouble-proof and properly functioning equipment; • On-site construction supervision; The turnkey work package: • A full range of electrical work (digging trenches, cable laying, Packaged Transformer Substation installing); • Pile driving for PV station; • Installation of tables and modules for PV station;
OUR PRODUCT www.solarsk.com.ua MOUNTING SYSTEMS MOUNTING SYSTEMS WITH MONTAGE OF THE SOLAR ROOF SYSTEMS EXCHANGEABLE ANGLE MOUNTING SYSTEMS
MOUNTING SYSTEMS www.solarsk.com.ua 15 TYPES MOUNTING SYSTEMS FOR ANY TYPE OF SOIL AND TERRAIN SMS mounting systems are universal mounting systems for photoelectric modules for open spaces SMS-211 - has a view of a worktable with portrait aligning of SMS-302 - has a view of a worktable with landscape aligning of photoelectric modules located in two rows with the static slope angle photoelectric modules located in three rows with the static slope angle within 15°-45°. It is mounted on one row of stands-axes within 15°-45°. It is mounted on two rows of interconnected stands-axes. SMS-402 has a view of a worktable with landscape aligning of SMS-212 - has a view of a worktable with portrait aligning of photoelectric modules located in four rows with the static slope angle within photoelectric modules located in two rows with the static slope angle 15°-45°. It is mounted on two rows of interconnected stands-axes. within 15°-45°. It is mounted on two rows of interconnected stands- axes.
SOLAR ROOF SYSTEMS www.solarsk.com.ua The design of the mounting systems of solar modules for roofs ‘Solar Roof Systems’ is a universal mounting device to fasten the photoelectric modules (PVM). Solar Steelconstruction company designs, manufactures, and installs the systems of fastening using: • aluminum profiles • steel profiles covered with zinc in hot method • profiles of the zincified roll THE MOUNTING SYSTEM ON SLOPE ROOFS is a set of carrying profiles, clamping elements for PVM and fastening that connect the profiles with the rafter construction or the roofing. This construction of fastening of PVM is used on the sloped roofs with the slope angle up to 60°. The location on the roof can be both portrait and landscape. THE MOUNTING SYSTEM FOR FLAT ROOFS has the design of the construction for fastening PVM that forms any required angle for tilting the panels. The slope is most often between 10° and 20°. THE BALLAST MOUNTING SYSTEM ON FLAT ROOFS has the design of the construction for fastening PVM that forms the required angle of tilting panels. It is used when it is undesirable or forbidden to lay the roof.
FEATURES OF OUR CONSTRUCTIONS ON THE ALUMINUM PROFILE www.solarsk.com.ua Features of ARS mounting systems for sloped and flat roofs: • High quality and long exploitation term (anodized aluminum) Simple profiles fastening • • Great ratio of price and quality • Fast and simple mounting. It has convenient grooves and installation openings • High universality of the structure • Full synchronization of all installation elements and mountings Fast and simple installation. • On-ground mounting systems are designed considering the adaptability for high and swift alterations of terrain height, which allows installing PVM and combining them into conditionally endless rows, and in the case of application of aluminum profiles, excluding the additional loads on the constructions under the temperature influence. We have over 300 MW of implemented projects using the aluminum profiles.
FEATURES OF OUR CONSTRUCTIONS ON THE STEEL ZINCED PROFILE www.solarsk.com.ua The features of mounting systems: • High universality of constructions • Adaptability to the terrain alterations • Maximum factory readiness • Full synchronization of all mounting details and fastening • Complex delivery • Fast and simple installation. We manufacture the steel profiles of the grade S235/S355 under EN 10025 with the following anticorrosion cover by hot zincing according to the requirements of ISO 1461:2009 . Systems of fastening for sloped and flat roofs are a universal technical solution, which allows creating constructions of any configuration from profiles of a single type to install PVM on any surfaces. We have over 800 MW of implemented projects.
www.solarsk.com.ua OUR IMPLEMENTED PROJECTS
Yaviriv 72 Mw Location: Lviv region, Ukraine Quantity of panels: 270 000 Pile ramming: 56 000 Mounting systems: SMS-301
Main facilities Belarusneft 58 MW Location: Gomel region, Rechitsa , Republic of Belarus Quantity of panels: 218 430 Pale ramming: 48 000 Mounting systems: SMS-301-2-12 / SMS-301-2-9 with exchangeable angle
