Mobile Internet Project Report Mobile Weather Station for Crowdsource based on OceanConnect Platform ���������� ������� �

INTRODUCTION 1 • What is NB-IOT? • Why we choose NB-IOT? HARDWARE & OCEANCONNECT 2 • Hardware devices. • OceanConnect platform. DATA VISUALIZATION 3 • Visualization on platform. • Visualization on app.

What's NB-IOT? A burgeoning standard of IOT The first step in the evolution of the cellular IOT Some pictures in the slide are quoted from HUAWEI HCDA-IoT training materials.

Present situation and the future The growth number forecast of of the IoT connection LPWA connection occupancy (Billion) *LPWAN:Low Power Wide Area Network Traditional cellular network In M2M connection scenarios, the short range commucation still dominates the game. But: • Among them, the number of LPWA connections began to grow rapidly in 2016 , and will exceeded the traditional cellular network in 2019 , about 1.4 billion . • LPWA technolo will have 11% application occupancy in 2024 .

How does it work? ��������������������� ����

How does it work? �.���������������.��� ������������-� ����������� Single-Tone: • Enables extreme low cost loT terminals to compete with non-cellular devices and enable faster time to market. • Not only cellular industry, low cost chip vendors are interested in building ST only chips. Multi-Tone: • Provides higher data rate and can target to replace most of the original CDMA/GPRS IoT applications • Chipset and module has higher cost and power Within ST Flexible bandwidth of 3.75kHz and consumption 15kHz adaptive to different scenarios

Why NB-IOT? Advantages of Low power consumption & Wide coverage Several NB-IOT applications have already been officially launched . In 2020, the NB-IOT network will be nationwide with more than 1.5 million base stations.

Hardware Devices Arduino Pro Mini NB Module Lithium-ion Battery Temperature and Humidity Sensor Solar Panel UV Sensor GPRS Module PM2.5 Sensor

Bill of the Devices

PCB & Assembly Package PCB Assembly with PCB Previous

OceanConnect Platform Profile Writing CODEC Plug-in

Profile Writing

CODEC Plug-in

Visualization on OceanConnect Issue the Instructions Issue Instruction Check Check Reported Data Reported Data

Server Deployment generate certificates pem file setup and start the server import certificates test

Subscribe HTTPS messages Restful Interface Webapp Test posting messages Got it!

New Data! Subscribe HTTPS messages Subscribe Notification North java app Got it!

Visualization on App HTTPS Crowdsourcing Data Mining Mobile Multi-parameters Interconnection

Android APK What we learned and experienced • Full stack IoT experience • Mobile network programming • Deep understanding of advanced communication technology

THANKS!
