Losinger Marazzi Vision and deployment of BIM Damien Chevarin Head - PowerPoint PPT Presentation

Losinger Marazzi Vision and deployment of BIM Damien Chevarin Head of BIM Management Summary 1. BIM by Losinger Marazzi 2. Use cases 3. BIM at the new Limmattal hospital 4. Conclusion Losinger Marazzi - d.chevarin buildingSMART at


  1. Losinger Marazzi – Vision and deployment of BIM Damien Chevarin – Head of BIM Management

  2. Summary 1. BIM by Losinger Marazzi 2. Use cases 3. BIM at the new Limmattal hospital 4. Conclusion Losinger Marazzi - d.chevarin ¦ buildingSMART at the new Limmattal hospital ¦ 23.06.2017 2

  3. BIM by Losinger Marazzi Losinger Marazzi - d.chevarin ¦ buildingSMART at the new Limmattal hospital ¦ 23.06.2017 3

  4. Why deploy BIM? Anticipation Quality Complexity of Customer projects Requirements Multiple Increasing Collaboration Efficiency partners digitalisation Losinger Marazzi - d.chevarin ¦ buildingSMART at the new Limmattal hospital ¦ 23.06.2017 4

  5. Our BIM development priorities Customer relationship Project Management Site management Losinger Marazzi - d.chevarin ¦ buildingSMART at the new Limmattal hospital ¦ 23.06.2017 5

  6. Our BIM development priorities Customer relationship Project Management Site management Losinger Marazzi - d.chevarin ¦ buildingSMART at the new Limmattal hospital ¦ 23.06.2017 6

  7. Dataorganisation: agility Geometer Customer Architect Room by room 3D Model Architect Gen. Contractor + Engineers MEP engineers All Partners STR engineer Gen. Contractor Gen. Contractor Losinger Marazzi - d.chevarin ¦ buildingSMART at the new Limmattal hospital ¦ 23.06.2017 7

  8. Workflow Losinger Marazzi - d.chevarin ¦ buildingSMART at the new Limmattal hospital ¦ 23.06.2017 8

  9. Data is our priority detailled definition 3D model (from our partners) of each element Centralized and collaborative database Losinger Marazzi - d.chevarin ¦ buildingSMART at the new Limmattal hospital ¦ 23.06.2017 9

  10. 2 Use cases Losinger Marazzi - d.chevarin ¦ buildingSMART at the new Limmattal hospital ¦ 23.06.2017 10

  11. Urban regeneration projects and Smart Cities Sustainable neighborhood Les Vernets – Geneva (GE) Losinger Marazzi - d.chevarin ¦ buildingSMART at the new Limmattal hospital ¦ 23.06.2017 11

  12. Visualization and validation with VR Decision supports / Digital mock-up Losinger Marazzi - d.chevarin ¦ buildingSMART at the new Limmattal hospital ¦ 23.06.2017 12

  13. Digital mock-up Clinic CIC Riviera – Clarens (VD) Losinger Marazzi - d.chevarin ¦ buildingSMART at the new Limmattal hospital ¦ 23.06.2017 13

  14. Business presentation with on site augmented reality Logistics building and offices – Plan-les-Ouates (GE) Losinger Marazzi - d.chevarin ¦ buildingSMART at the new Limmattal hospital ¦ 23.06.2017 14

  15. Design Management Hotel – Grand-Saconnex (GE) BIM coordination by Losinger Marazzi (with external partner for few projects) Use of IFC for 3D-model and BCF for the issues Software: Solibri Model Checker Coordination meeting BIM COORDINATOR PROJECT MANAGEMENT ARCHITECTS MEP ENGINEERS STRUCTURE ENGINEER Losinger Marazzi - d.chevarin ¦ buildingSMART at the new Limmattal hospital ¦ 23.06.2017 15

  16. End-of-design documentation Neuroscience Laboratories – Prilly (VD) Losinger Marazzi - d.chevarin ¦ buildingSMART at the new Limmattal hospital ¦ 23.06.2017 16

  17. BIM on site Neuroscience Laboratories – Prilly (VD) Proof of concept of multiple solutions in progress Losinger Marazzi - d.chevarin ¦ buildingSMART at the new Limmattal hospital ¦ 23.06.2017 17

  18. Delivery & logistics on site Sustainable neighborhood Eikenøtt Building A2 – Gland (VD) Losinger Marazzi - d.chevarin ¦ buildingSMART at the new Limmattal hospital ¦ 23.06.2017 18

  19. Prefabrication and construction methods Student housing – Zurich Losinger Marazzi - d.chevarin ¦ buildingSMART at the new Limmattal hospital ¦ 23.06.2017 19

  20. 3 BIM at the new Limmattal hospital Losinger Marazzi - d.chevarin ¦ buildingSMART at the new Limmattal hospital ¦ 23.06.2017 20

  21. A pilot project The first hospital project in Switzerland in design-to-cost One of the first projects with BIM Voluntary approach from multiple partners to implement a BIM-process Losinger Marazzi - d.chevarin ¦ buildingSMART at the new Limmattal hospital ¦ 23.06.2017 21

  22. Workflow and organisation Losinger Marazzi - d.chevarin ¦ buildingSMART at the new Limmattal hospital ¦ 23.06.2017 22

  23. 1 st Use case: data management Why? - To support customer relations management - To integrate the right information into the documentation How? - at the beginning: an Excel-sheet (XX Mo with Macro) - during the optimization: dRofus (with connection to 3D-Models) Which use cases? - View of all the rooms for execution - Quantities check (Project vs Roombook) Losinger Marazzi - d.chevarin ¦ buildingSMART at the new Limmattal hospital ¦ 23.06.2017 23

  24. 2 nd Use Case: Coordinated Model Losinger Marazzi - d.chevarin ¦ buildingSMART at the new Limmattal hospital ¦ 23.06.2017 24

  25. 3rd Use Case: Quantities Check the quantities and the costs of the project in the design phase Losinger Marazzi - d.chevarin ¦ buildingSMART at the new Limmattal hospital ¦ 23.06.2017 25

  26. 4th use case: Manage the time schedule Manage the time schedule with: • - An efficient production of the “ room by room ” drawing (6 views) - A quality control with 3D-Model main entrance Losinger Marazzi - d.chevarin ¦ buildingSMART at the new Limmattal hospital ¦ 23.06.2017 26

  27. All Users 3D Model 3D Merged Control Learn 2D Plan Database «Revit Model model model Model «Allplan» «dRofus» Server» «Nova» «Glue» «Field» «HTC» Customers X X Architects X X Civil engineers X MEP engineers X X BIM Management X X X X X Design Manager X X X X Construction X X X workers Losinger Marazzi - d.chevarin ¦ buildingSMART at the new Limmattal hospital ¦ 23.06.2017 27

  28. Use of file formats Design Execution FM Comments IFC Yes Yes ? Models exchange BCF No No No Technology not compatible Test between 3dmodel+database COBie No Test ? and Maximo RVT Yes Yes ? NWD Yes Yes ? Used also for the “BIM2Field” FBX No Yes ? Losinger Marazzi - d.chevarin ¦ buildingSMART at the new Limmattal hospital ¦ 23.06.2017 28

  29. 4 Conclusion Losinger Marazzi - d.chevarin ¦ buildingSMART at the new Limmattal hospital ¦ 23.06.2017 29
