Leergang offshore wind Uitdagingen in de logistiek Prof.dr. Ruud - PowerPoint PPT Presentation

faculteit economie vakgroep operations 14-11-2019 | 1 en bedrijfskunde | 14-11-2019 1 Leergang offshore wind Uitdagingen in de logistiek Prof.dr. Ruud Teunter Dr. Jasper Veldman 14-11-2019 | 2 Offshore logistics network 14-11-2019


  1. faculteit economie vakgroep operations 14-11-2019 | 1 en bedrijfskunde | 14-11-2019 1 Leergang offshore wind Uitdagingen in de logistiek Prof.dr. Ruud Teunter Dr. Jasper Veldman

  2. 14-11-2019 | 2 Offshore logistics network

  3. 14-11-2019 | 3 Port facilities

  4. 14-11-2019 | 4 Spare parts  Infield cables  Export cables  Turbine blades  Turbine components  Spare turbines

  5. 14-11-2019 | 5 Transport

  6. 14-11-2019 | 6 Transport

  7. 14-11-2019 | 7 The main players in O&M (S)LSP = (specialist) logistics service providers, OWF = offshore wind farm, OEM = original equipment manufacturer IMSP = independent maintenance service provider

  8. 14-11-2019 | 8 Some basic principles › A service provider uses a mix of maintenance policies:  Corrective (run-to-failure)  Calendar-based  Condition-based › Different jobs, different turbine components, different vessels › Importance of weather restrictions

  9. 14-11-2019 | 9 Offshore wind – O&M overview Offshore wind process Installation Logistics Maintenance • Turbine layout design • Fleet size and mix • Spares supplier selection Strategic • Wind park dimensioning • Warehouse location • Contracts definition horizon level Planning Tactical Human resource capacity planning • Master distribution plan • Environment forecasting • Spare parts inventory policies • Maintenance policy optimization • Vehicle routing • Scheduling maintenance tasks Operational • Spare part distribution and collection • Routing technicians Our focus

  10. 14-11-2019 | 10 TACTICAL MAINTENANCE JACK-UP VESSEL DEPLOYMENT

  11. 14-11-2019 | 11 The setting › Jack-ups needed for large component replacements (e.g., blades) › Short term chartering costs are immense › Logistics-related delays drastically raise costs

  12. 14-11-2019 | 12 Cooperation options

  13. 14-11-2019 | 13 Vessel sharing

  14. 14-11-2019 | 14 Vessel sharing

  15. 14-11-2019 | 15 TACTICAL LOGISTICS SPARE PARTS MANAGEMENT (ON AN SOV)

  16. 14-11-2019 | 16 Service Operations Vessel https://www.youtube.com/watch?reload=9&v=lk_ww_ynWh4

  17. 14-11-2019 | 17 Characteristics Service Operations Vessel Offshore for 2 to 3 weeks • Can host tens of workers • Small repair shop • Small crane • Electronic gangway system • Helicopter deck • Carries spare parts or • subassemblies for - Hydraulics - Generator - Gearbox - Electric system

  18. 14-11-2019 | 18 What to bring offshore? SOV Kit › Goal: find (nearly) optimal SOV stock › Determine the probability that (the n-th) part of some type is needed on a tour › Calculate the ratio of that probability and the cost price of a part › Rank parts based on the ratio (high to low) and add parts to the stock in this order › Easily done in Excel

  19. 14-11-2019 | 19 TACTICAL MAINTENANCE (AND PRODUCTION) GET VESSELS, PARTS, TOOLS AND TECHNICIANS READY

  20. 14-11-2019 | 20 Smart supply chain Internet of Things (IoT)

  21. 14-11-2019 | 21 Wind turbine sensoring

  22. 14-11-2019 | 22 Condition-based maintenance Condition monitoring › Condition data (Big data) › Condition information (analytics, data mining) › Condition-based maintenance

  23. 14-11-2019 | 23 Condition-based production › Maintenance planning lead time Condition monitoring › Control of the production rate Weather Technicians lead time Spare parts Tools

  24. 14-11-2019 | 24 Smart production & SC › Variable production speed › Higher production speed leads to more vibration and higher temperatures › Trade-off: production versus deterioration

  25. 14-11-2019 | 25 Smart production & SC A block diagram of a wind turbine system (ABB, 2011)

  26. 14-11-2019 | 26 The single turbine case Decelerate Decrease risk of failure Accelerate Increase production

  27. 14-11-2019 | 27 Win-win scenario › Lower maintenance cost and lower production losses Cost reduction 10% -- 20% extra production

  28. Two turbines (high maintenance 14-11-2019 | 28 setup costs) › Better to maintain both wind turbines at the same time › Set higher production rate for less deteriorated turbine Condition-based production rates Constant, equal production rates Deterioration processes of turbines are much better synchronized

  29. 14-11-2019 | 29 OPERATIONAL MAINTENANCE SCHEDULING TASKS GIVEN VESSELS, PARTS, TOOLS AND TECHNICIANS

  30. 14-11-2019 | 30 Scheduling inputs › Maintenance tasks Service time, number of technicians, type of technicians, spare  parts (kg) › Availability of technicians in the harbor › Fleet Capacity for personel, spare parts, speed, costs, heterogenous  › Weather conditions How long can a particular vessel type work during a period  › Set of periods available for scheduling tasks Technicians Fleet Maintenance tasks Repair or inspection?

  31. 14-11-2019 | 31 Scheduling algorithm Minimize total costs: › Fuel/transportation costs › Technician costs (cost per day) › Maintenance costs Balancing act between 1) Vessel moves with technicians (fewer technicians needed) 2) Vessel picks up and delivers technicans between turbines (fewer vessel trips and lower fuel costs)

  32. 14-11-2019 | 32 Scheduling outcomes Technicians Fleet Maintenance tasks Repair or inspection? Transportation (fuel) costs Scheduling algorithm Technician costs Maintenance costs Plan technicians Plan tasks Select and route vessels Benefits: • Efficiency, cost reduction • Reduced mean time to maintenance • Better use of technicians • Fewer vessel trips

  33. 14-11-2019 | 33 COMBINED INSIGHTS: SIMULATION TOOL

  34. 14-11-2019 | 34 Simulation tool modules To be developed in AnyLogic Simulation Software Turbine Model Weather Model Maintenance Logistics Dashboard 1 2 3 4 5 • Wind speeds • Vehicle routing • Performance measures • Deterioration process • Maintenance policies • Temperature • Inventory management • Planning suggestions • Power generation • Preventive maintenance • Technician scheduling • Excel reports • Service demands • Rain • Corrective maintenance • State inspection • Wave heights • Repair kit problems Purely simulation Simulation and optimization Analytics and data visualization

  35. 14-11-2019 | 35 Screenshots

  36. 14-11-2019 | 36 STRATEGIC MAINTENANCE CONTRACTING

  37. 14-11-2019 | 37 Contracting & collaboration OEM Service Owner Provider

  38. 14-11-2019 | 38 Maintenance contract? › Wind turbines are often sold with two or five years of warranty › Question: › Should the buyer/owner of wind turbines directly sign a long-term maintenance contract with the OEM (bundling) or not (un-bundling)? OEM i bundling 20 yrs OEM i or OEM j OEM i unbundling auction auction

  39. 14-11-2019 | 39 Critical tradeoffs › Two features of the maintenance industry:  OEM's learning-by-doing: maintenance cost decreases over time  Competitive market: more independent service providers than OEMs › Trade-off owner: A long term contract  always takes advantage of the OEM's learning-by-doing and motivates the OEM to invest in turbine reliability, but  foregoes the chance to choose a more efficient provider

  40. 14-11-2019 | 41 Some findings Bundling Unbundling (1 contract) (2 contracts) Making a mess for others Investment in turbine reliability Learning-by-doing  turbine reliability Owner’s cost Few service providers Strong learning Owner’s cost Many service providers Weak learning

  41. 14-11-2019 | 42 BEYOND OFFSHORE WIND

  42. 14-11-2019 | 43 Smart Grids in City Areas http://smarthome.lisha.ufsc.br/index.php/Main_Page

  43. 14-11-2019 | 44 Energy storage: balancing smart grids http://www.powermatchingcity.nl

  44. 14-11-2019 | 45 Energy storage management › Integration with renewable resources such as wind and solar power › Integration with natural gas grid › Buffer to balance fluctuating consumption and generation

  45. 14-11-2019 | 46 Research questions › How to deploy and control energy storage units to improve system performance?  Where to install the conversion and storage units?  How to dimension these units?  What is the optimal control policy?

  46. 14-11-2019 | 47 Questions?
