Jiangsu Yoke Technology PhireGuard ELF-606 Marketing Presentation 30 December 2016 1

PhireGuard ELF-606 Characterictics  Chlorinated Diphosphate Esters  Extremely low Fogging and VOC’s  Compatible with slabstock and molded foams  No impact on reaction profile and processability  Miscible in polyol blends  Enhanced fire properties over wide range of foam density  Offer durable Fire Protection 30 December 2016 2

PhireGuard ELF-606 Key Properties  Appearance: Clear Liquid  Viscosity: # 1800 mPa.s  Phosphorus Content > 9.2 wt%  Chlorine Content > 31.5 wt%  Acidity: < 0.2 mgKOH/g  Water Content: < 0.1 wt%  Colour APHA: < 100  OH value (Water and Acid excluded): 0 mgKOH/g  Non Reactive 30 December 2016 3

PhireGuard ELF-606 Value Proposition  Latest Development of the “V6” technology  Extremely low level of TCEP, i.e. < 1000 ppm  Enhanced Emission (VOC’s, Fogging) performance  Compatible with most Fire Safety Standards:  BS 5852 Crib 5  Cal TB 117  UL-94  FMVSS  High molecular weight, non “fugitive” FR, meaning that ELF - 606 provide the flexible PU foam with durable fire protection 30 December 2016 4

Typical formulations based on PhireGuard ELF 606 Foam 30 kg/m3 35 kg/m3 density FMVSS 302, SE rating 5-6 php 4-5 php Cal TB 117 A 7-8 php 6-7 php BS 5852 11 php + 9 php + Crib 5 21 php Mel 18 php Mel 30 December 2016 5

PhireGuard ELF’s are non fugitive % Phosphorous retention at 70 deg C, measured by P -NMR. 120 100 TCPP TDCP 80 ELF-606 60 40 20 0 Unaged 2 Weeks 2 Months 6 Months 30 December 2016 6

PhireGuard ELF-606 Fogging Performance DIN B-75201, 120 deg C, 24 hours 100 mg / 10 g 90 80 70 60 50 40 30 20 10 0 TCPP Standard EL-22 / NC-28 ELF-606 TDCP 30 December 2016 7

VDA 278 VOC’s / Fog Test VOC’s o 90 C, 30 min Foam (10-50 mg) Carrier Gas O Cryogenic Trap (-150 C) Helium O 280 C Fog o 120 C, 60 min Molecules Recognition & Quantification 90 80 70 60 Mass Spect. Gas Chrom. 50 40 30 20 10 0 W X Y Z Data Analysis 30 December 2016 8

ELF-606 VDA 278 Perofrmance 300 250 200 Max 150 ELF contribution 100 50 0 VOC, 90 C Fog, 120 C  PhireGuard ELF-606 hardly contributes to the foam VOC emission  Very limited contribution to the Fogging (# 30 ppm), which gives to the Foamer a wide formulation latitude whilst still remaining below the 250 ppm 30 December 2016 9

PhireGuard 606 Summary The top Class FR Best Emission family (VOC’s, Superior FR Fogging Performance Performance). Processability, Limited Impact on Foam Properties Chlorinated DiPhosphate Ester 30 December 2016 10

One more thing…  PhireGuard ELF-606 belongs to the new class of Flame Retardants that the Jiangsu Yoke Technology Corporation has recently launched on the market.  The PhireGuard tradename is associated with Innovation, Quality Consistency and Cost in Use Efficiency 30 December 2016 11
