Industry Information Live Maskinsikkerhed med TIA-portalen - PowerPoint PPT Presentation

Industry Information Live Maskinsikkerhed med TIA-portalen integreret og skalerbart Vrter Ole Dyval og Kim Meyer-Jacobsen Siemens Digital Industries Dagens vrter Kim Meyer-Jacobsen - Technology Specialist Ole Dyval - Technology


  1. Industry Information Live Maskinsikkerhed med TIA-portalen – integreret og skalerbart Værter Ole Dyval og Kim Meyer-Jacobsen Siemens Digital Industries

  2. Dagens værter Kim Meyer-Jacobsen - Technology Specialist Ole Dyval - Technology Specialist Moderator – Lars-Peter Hansen

  3. Maskinsikkerhed med TIA-portalen - integreret og skalerbart

  4. Maskinsikkerhed med TIA-portalen – integreret og skalerbart • Hvad er Simatic Safety Integrated? • Hvordan kan man enkelt integrere safety-funktioner med TIA-portalen • Eksempler på diagnosemuligheder • Bonusinfo • Q/A • Kommende Webinar

  5. Understanding and implementing Machine Safety

  6. Werner von Siemens Berlin, 1880 "The prevention of accidents must not be understood as a legal requirement, but as a precept of human duty and economic reason."

  7. you have to deal with… Integrated added value STO EN ISO 12100 Scalability Evaluation Tool Shared Device WEB server Safety Integrated CE marking Openness SIL and PL Everywhere One Engineering Risk assessment Access PROFISAFE Risk minimization Proven components IEC 62061 SIMATIC Controller Digitalization Usability ISO 13849-1 These topics define the SIMATIC Safety systems.

  8. SIMATIC Safety Integrated! Hazard due to Electric shock Heat and fire Dangerous functional faults radiation Safety Integrated for personnel, machines and the environment

  9. SIMATIC Safety Integrated! • An easy way to integrate simple or complex Safety function in to your TIA automation platform.

  10. Of SIMATIC Safety Integrated! • One Controller • One Engineering framework • One Network • Channel granular diagnostic info • Flexibility in regards to Sensors, Actuators and Implementation

  11. The path to a safe machine is completed by the EC declaration of conformity and CE marking. EC declaration of conformity CE marking

  12. Where to start? ? Describe the machine and identify hazards

  13. The potential hazards can be identified according to EN ISO 12100. Risk assessment Cutting Dropping Motion Gravity Approach Rotation

  14. The Machinery Directive involves three specific steps to achieve a safe machine. Risk assessment Risk minimization Verification Develop a Describe the machine Carry out the validation safety concept Implement a Proof that his machine is in Identify hazards safety concept conformance with directive Assess the risks Document measures Attach a CE marking

  15. A high initial risk must be reduced to an acceptable residual risk. Risk minimization Initial Acceptable Risk minimization risk residual risk

  16. A high initial risk must be reduced to an acceptable residual risk. Risk minimization The defined safety category (SIL, PL) determines the magnitude of the acceptable residual risk, and therefore the demanded reliability of the safety system. Use "proven components", Regular functional tests, Automatic fault 10 -4 identification,Redundant design, Redundancy + fault identification PL a 10 -5 PL b Not more than 1 potentially hazardous failure of the safety function 3*10 -6 SIL 1 in 10 years PL c 10 -6 Not more than 1 potentially hazardous failure of the safety function SIL 2 PLd in 100 years 10 -7 Not more than 1 potentially hazardous failure of the safety function SIL 3 PL e in 1000 years 10 -8

  17. The safety concept can be developed based on the 3-stage method according to EN ISO 12100. Risk minimization Start 1. Safe design Yes Risk appropriately reduced? No 2. Technical measures Yes Risk appropriately reduced? No 3 User information about residual risks Yes Risk appropriately reduced? No End New risk assessment

  18. The Machine after Risk assessment - mechanical Risk minimization

  19. The Machine after Risk assessment - electrical

  20. Implementing Safety Integrated

  21. One Controller for Controlling and Safety

  22. Maskinsikkerhed med TIA-portalen – integreret og skalerbart • Hvad er Simatic Safety Integrated? • Hvordan kan man enkelt integrere safety-funktioner med TIA-portalen • Eksempler på diagnosemuligheder • Bonusinfo • Q/A • Kommende Webinar

  23. The SIMATIC Controller portfolio always provides the right controller - Plus integrated added value! Efficient engineering Innovative design Range of diagnostic options Safety Integrated Security Integrated Technology Integrated

  24. Why is it safe? Operation systems expansion Discrepancy analysis Protection Mechanisms Short- cross- Diverse part of the safety circuit monitoring program generated by Safety Advance Wire break Communication monitoring with the PROFIsafe profile Light- dark-test Switch on test

  25. Scalability with Drives

  26. Safety functions overview Overview of safety functions in the drive SINAMICS STO SS1 SS2 SOS SBC SBT SLS SLA SSM SDI SLP SP SCA Transfer F-DI  V90  G110M / G120C   2)     G120 modular       G120D S210 3)   G130 / G150             3) 4) S120 / S150 2) Only possible with CU 250S-2 with Safe Brake Relay 3) For Chassis and Cabinet Modules with Safe-Brake Adapter, for Blocksize formats with Safe Brake Relay 4) Only for CU310-2

  27. Safety functions overview Overview of safety functions in the drive SINAMICS STO SS1 SS2 SOS SBC SBT SLS SLA SSM SDI SLP SP SCA Transfer F-DI  V90  G110M / G120C   2)     G120 modular       G120D S210 3)   G130 / G150             3) 4) S120 / S150 2) Only possible with CU 250S-2 with Safe Brake Relay 3) For Chassis and Cabinet Modules with Safe-Brake Adapter, for Blocksize formats with Safe Brake Relay 4) Only for CU310-2

  28. Safety functions overview Overview of safety functions in the drive SINAMICS STO SS1 SS2 SOS SBC SBT SLS SLA SSM SDI SLP SP SCA Transfer F-DI  V90  G110M / G120C   2)     G120 modular       G120D S210 3)   G130 / G150             3) 4) S120 / S150 2) Only possible with CU 250S-2 with Safe Brake Relay 3) For Chassis and Cabinet Modules with Safe-Brake Adapter, for Blocksize formats with Safe Brake Relay 4) Only for CU310-2

  29. LDrvSafe Library

  30. LDrvSafe Library

  31. LDrvSafe Library

  32. LDrvSafe Library

  33. LDrvSafe Library

  34. SINAMICS Startdrive V16 Feature extension – Acceptance test

  35. F-runtime group

  36. F-runtime group

  37. PL / SIL by design

  38. PL / SIL by design

  39. Safe instructions certified by TÜV

  40. Safe instructions certified by TÜV

  41. How to get help and information Service og Support Safety Integrated programming guideline Safety with the S7-1200 FC CPU SLS specification via HMI Configuration control with safety PROFIsafe address assignment Mode selection

  42. Maskinsikkerhed med TIA-portalen – integreret og skalerbart • Hvad er Simatic Safety Integrated? • Hvordan kan man enkelt integrere safety-funktioner med TIA-portalen • Eksempler på diagnosemuligheder • Bonusinfo • Q/A • Kommende Webinar

  43. Display information Timestamp of the last failsafe modification Overall signature of the safety program

  44. Diagnostics in clear text

  45. Diagnostics in clear text

  46. Safety functions Detection Evaluation Reaction

  47. Cheking Safety Functions Risk mitigation The checking of safety functions is a MUST! • Prescribed by the standards EN ISO 13849 and EN 62061 • Safety concept must be evaluated and documented by way of the failure probability calculation • Evaluation possible with SET: Safety Evaluation Tool • Free use of the online tool

  48. Training by SITRAIN www.siemens.dk/sitrain

  49. Summary Now I am Safe ☺

  50. Maskinsikkerhed med TIA-portalen – integreret og skalerbart • Hvad er Simatic Safety Integrated? • Hvordan kan man enkelt integrere safety-funktioner med TIA-portalen • Eksempler på diagnosemuligheder • Bonusinfo • Q/A • Kommende Webinar

  51. TIA Portal Cloud as TRIAL SIMIT 05.2020 Customers • Fore registered customers • Free access via Voucher • Test your skills • Try all the Simulators • No installations is SIMIT TIA Portal Suite needed includes STEP 7, WinCC Advanced, 21 days • All necessary updates Safety, PLCSIM Advanced, Startdrive free usage is included and other option packages www.siemens.com/simulation-cloud

  52. TIA Portal Cloud as TRIAL How does it work (based on time limited Voucher)? 1 Sign-up and register on 2 Launch Industry Premium 3 21 days free use website Portal DAMEX approval Login with standard web browser TIA Portal V15.1 / V16 (Product and Customer) WinCC Unified PC Terms & Conditions by User Terms & Conditions (before use) Creates and sends voucher No productive usage – PLCSIM Advanced with link to SISC only TRIAL SIMIT (05/2020) User upgrades Account with Voucher credentials in SISC

  53. Yderligere information Gense webinar og download materiale på www.siemens.dk/di-webinarer Find tips og trick på YouTube Kontakt Ole Dyval ole.dyval@siemens.com Kim Meyer-Jacobsen kim.meyer-jacobsen@siemens.com
