Hardware switches - the open-source approach Ji Prko jiri@resnulli.us Red Hat 1 Scope of talk Open-source Linux support for various switch and switch-ish chips. Including L2, L3, flow-based forwarding TOR (Top-of-rack


  1. Hardware switches - the open-source approach Jiří Pírko jiri@resnulli.us Red Hat 1

  2. Scope of talk Open-source Linux support for various switch and switch-ish chips. ● Including L2, L3, flow-based forwarding – TOR (Top-of-rack switch) ● Switch chips in servers ● Mesh topologies – Could replace TORs – SR-IOV ● Switch embedded into NIC – Used for virtualization purposes – Home routers ● e.g. OpenWRT devices – Custom switch board Linux deployment ● 2

  3. Current state Ice age ● Switch chip vendors ● Broadcom, Intel, Mellanox, ... – They believe they need to protect their “intellectual property” – Each has its own “SDK” - userspace binary blob user for accessing HW – ● Vendor lock-in for appliance vendors Appliance vendors (boxes) ● Cisco, Juniper, Brocade, ... – They buy chips from others and include them into their products – Proprietary tools for switch chip manipulation – ● Vendor lock-in for customers Often use Linux kernel, however not for switch chip manipulation – 3

  4. Current state proprietary switch app #ip #tc #ethtool Network vendor X #bridge Manager proprietary custom app SDK userspace kernel RT Netlink ethtool ioctl NIC driver eth0 kernel hardware vendor X switch Y chip NIC ...... 4 swp0phy swp1phy swpNphy eth0phy

  5. Desired model Possibility to re-use existing network tools for switches ● ip , ethtool , bridge , tc , Network Manager, open vSwitch toolset – One switch port is represented as one network device (e.g. eth0) ● Port devices should be able to work as independent NICs ● L3 address assign, packet TX and RX – Routing between ports could be offloaded into hardware – Port devices should work in layered topologies ● Layered devices: bridge, bonding, Open vSwitch – Offload layered devices functionality to hardware if possible – Ethtool API implementation by driver ● Provide a way to find out if two ports belong to the same switch chip ● Model working name is “switchdev” ● 5

  6. Desired model #ip #tc Network #bridge Manager custom app #ethtool userspace kernel ethtool ioctl RT Netlink swp0 switch Y swp1 driver NIC driver eth0 swpN kernel hardware vendor X switch Y chip NIC ...... 6 eth0phy swp0phy swp1phy swpNphy

  7. Linux Switchdev infrastructure Switch device specific set of network device operations (ndos) ● To pass info to switch driver and also to query driver for some information – Switch device notifier ● To propagate hardware event to listeners – Open vSwitch RT Netlink Ethernet bridge datapath notifjer notifjer int netdev_switch_*(...) switchdev infrastructure ops->ndo_switch_*(...) int call_netdev_switch_notifjers(...) action event 7 switch X driver

  8. L2 forwarding offload Merged into upstream Linux kernel ● Linux bridge support – Rocker switch driver – Rocker switch is hardware emulated in QEMU based on OF-DPA model ● Rocker was created for testing and prototyping purposes ● Two new ndos introduced ● ndo_switch_parent_id_get – Called to obtain ID of a switch port parent (switch chip) ● ndo_switch_port_stp_update – Called to notify switch driver of a change in STP state of bridge port ● Two new switchdev notifier events introduced ● NETDEV_SWITCH_FDB_ADD and NETDEV_SWITCH_FDB_DEL – Raised by switch driver in case hardware an FDB entry is added or removed ● 8

  9. Future plans L3 forwarding offload - an attempt by Scott Feldman ● Introduction of two new ndos – ndo_switch_fib_ipv4_add and ndo_switch_fib_ipv4_del ● – Called by the core IPv4 FIB code when installing/removing FIB entries to/from the kernel FIB Flow-based forwarding offload - an attempt by John Fastabend ● Called “Flow API” – Introduces a new Generic Netlink interface called “net_flow_nl” – To be used for offloaded flows maintenance only ● Userspace app queries hardware capabilities and do the flow insertions accordingly – TC-based flow offload ● An alternative to “Flow API” – Extends existing TC Netlink API – The same interface for software datapath and hardware offload – 9

  10. TC-based flow API custom fmow open vSwitch managing app userspace userspace TC fjlters: actions: kernel RT Netlink u32 police bpf mirred ... ... xfmows xfmows generic Netlink xfmows backend API xfmows backend implementation swp0 xfmows backend implementation switch Y driver swp1 Open vSwitch br0 datapath swpN kernel hardware vendor X switch Y chip ...... 10 swp0phy swp1phy swpNphy

  11. SR-IOV use-case Embedded switch ● Interconnects VFs and PF – Capabilities differ from NIC to NIC – From Linux kernel perspective should be handled like any other switch chip – Purpose of switchdev is to provide that abstraction ● Lot of potential for virtualization use-cases – Open vSwitch acceleration ● Containers, OpenStack ● 11

  12. SR-IOV NIC X swpPF ethPF use-case embedded NIC X driver switch driver swpVF0 ethVF0 swpVF1 ethVF1 swpVF2 ethVF2 kernel hardware VF0 VF1 VF2 swpVF0 swpVF1 swpVF2 embedded switch SR-IOV swpPF NIC X 12 phyPF

  13. DSA use-case Switch PHY ● Connected via MII – Allows to rx and tx packets via particular ports using “DSA tags” – In kernel, for each port there is a netdevice created – Fits into the switchdev picture – looks like any other switch driver exposing switch ports ● 13

  14. DSA use-case swp0 switch X eth0 swp1 DSA driver tagged swpN kernel hardware switch Y chip ...... swp0phy swp1phy swpNphy 14

  15. The end Questions? ● 15
