FROG Owners Group A Worldwide Network of Experience April 2012

Origin ► FROG founded in 1991 ► Founding Members = utilities operating or building Nuclear Power Plants with Framatome supplying Nuclear Steam Supply System or Nuclear Island � ELECTRABEL (Belgium) � EDF (France) � ESKOM (Republic of South Africa) � GNPJVC (China) � KHNP (South Korea) ► W PWR design based models � 3-loop PWR 900 MW � 4-loop PWR 1300 MW Introduction to FROG April 2012 - p. 2

Membership ► Open to any utility operating or building NPP with AREVA supplying NSSS or NI ► On a case by case, open to utility supplied by AREVA with a major component, e.g. Reactor Vessel or Replacement Steam Generators ► Subsequent members � 1997: Vattenfall (Sweden) � 2000: LANPC (China) � 2002: British Energy (UK) Introduction to FROG April 2012 - p. 3

Other utilities participating to FROG Activities ► Other utilities invited to participate to some of FROG activities ► Steam Generator Technical Committee � AXPO (Beznau – Switzerland) � NEK (Krsko – Slovenia) � XCEL ENERGY (Prairie Island – USA) � AMEREN UE (Callaway – USA) ► Operating Procedure Working Group � FORTUM ( Loviisa – Finland) ► Outage Optimization Working Group � QNPC and NPQJVC (Qinshan – China) Introduction to FROG April 2012 - p. 4

The FROG Worldwide QNPC Introduction to FROG April 2012 - p. 5

Mission ▌ The FROG mission is dedicated to building strong and efficient teaming for mutual co-operation, assistance, and sharing of its Members' experience and expertise, to support the safe, reliable, and cost-effective operation of its Members' nuclear power units. Introduction to FROG April 2012 - p. 6

Objectives ► Constitute a forum for utilities and also designer to exchange on all aspects of operating experience ► Provide a mechanism for identifying and resolving generic issues through effective channels established between utilities, designer, and other organizations ► Provide cost/delay effective resolution of generic problems ► Allow any member to participate to development programs ► Set an organization for exchanging operating experience with similar Owners Groups Introduction to FROG April 2012 - p. 7

Organization ► Senior Executive Council � Set long term plans/objectives � Approve Charter amendment ► Steering Committee � Set short/mid term plans/objectives � Provide direction and oversight of all FROG activities � Approve budget and program funding � Chairman & Vice-Chairman elected for 2-year term ► Technical Committees, Working Groups, Correspondent Networks � Implement decisions and policies adopted by SC ► AREVA � Provide administrative and technical support Introduction to FROG April 2012 - p. 8

FROG Activities ► Meetings Operating Steam Outage Material Diesel Steering RIA Steering Procedures Generator Optimization Ageing WG WG Committee WG Committee WG TC WG ► Joint Programs � More than 30 programs completed or in progress � Examples • R&D: e.g. 600/690 Alloys Primary Water Stress Corrosion Cracking • Benchmarking studies and improvement suggestions: e.g. Operating Procedures • Degradation modes analyses: e.g. RV Internals, SG ► Correspondent Networks � Ageing Network � Spare Part Network Introduction to FROG April 2012 - p. 9

Steering Committee Meetings Operating Steam Outage Material Diesel Steering RIA Steering Procedures Generator Optimization Ageing WG WG Committee WG Committee WG TC WG ► Twice a year ► Attendance � Utility operation managers or representatives (SC Members) � FROG Secretary � AREVA Management representatives (including Engineering, Services, Fuel, I&C) � Utilities/AREVA specific speakers depending on agenda ► Agenda � Operating experience: performance & main events � Specific subjects analyzed trough Members and/or AREVA presentation, e.g. Obsolescence Management, Dose Reduction, Contractor Management in Maintenance, Spare Part Management, Feedback Process, Core Thermal Power Measurement, Human Performance Introduction to FROG April 2012 - p. 10

Working Groups Meetings Operating Steam Outage Material Diesel Steering RIA Steering Procedures Generator Optimization Ageing WG WG Committee WG Committee WG TC WG ► Currently 5 Working Groups + 1 Technical Committee ► Each group meet once a year ► Attendance � Utility/plant specialists in the WG domain � AREVA experts including US and German representatives ► Agenda � Operating experience in the WG specific domain � Specific technical issues � Discussions of potential & current Joint Programs ► Additionally, occasional Workshops: Spare Parts, Ageing, etc Introduction to FROG April 2012 - p. 11

FROG Technical Publications ► Distribution to FROG Members ► Information Notices, Significant Event Reports, Material Event Reports � Summarize an event that • occurred in a FROG Member or non-FROG Member unit • can be considered as important for FROG Members � Present event cause analysis, potential impact for FROG Member units, AREVA position and/or recommendation, as available ► Designer Newsletters � State AREVA’s position as NSSS designer on a specific topic of general interest to FROG Members ► Technical Program Reports ► FROG Performance Indicators Reports Introduction to FROG April 2012 - p. 12

Examples of Technical Reports Designer News Letters DNL 22: response to SOER 96-2(core design) DNL 23: preliminary remarks following theleakage incident on the Information Notices Sizewell B RPV seals IN3: SG tube rupture at Indian Point 2 DNL 24: Framatome ANP preliminary analysis of recent incidents of IN4: Reactor building pressurization canals and circumferential stress corrosion cracking of CRDM nozzles in US PWRs liners DNL 25: LOCA safety injection switchover time IN5: Fall of packing in the Cooling Tower DNL 26: SG partition plate IN6: South Texas 1 bottom penetration cracking Material Event Reports base welds MER 6: Boric acid corrosion (Arkansas1) IN7: Loss of Power at Forsmark 1 MER 7: Review of cracking in Ni base weld metal in RCS (Ringhals 4,..) MER 8: RCS stress corrosion of 182 and 82 Nickel base welds MER 9: Benchmarking on RPV bi-metallic welds ISI Significant Event Reports SER 29: Tihange 2 Safety Injection induced by inopportune valve test SER30: Insulation defects on K1 connecting Cables (EDF PWRs) SER31:Adjustment fault on voltage relays of new 380 V electrical boards (Tihange2) SER32: Koeberg LHSI pumps declared unoperable Technical Program reports SER 33: Transformer failure on Ringhals 3 TPR19: Sludge Lancing Benchmarking (phase 2) SER34: LAO Transformer trip TPR20: Maintenance sheets of EOPs SER35: LAO RCP pump damage TPR 21: Obsolescence of qualified I&C equipment TPR22: Operation guide on the sumps clogging issue TPR23: Obsolescence of qualified elec. and I&C equipment TPR24: Experimental program on PWSCC of Alloy182/82 TPR25: Resistance of Alloy 690 to PWSCC TPR26: Experience feedback from Cruas 4 on SG TSP clogging TPR27: Transition from EOP to Severe Accidents TPR28: same as TPR27 for shutdown states Introduction to FROG April 2012 - p. 13

Network of Experience ► A worldwide network of experience mixing plant operation and NSSS designer Introduction to FROG April 2012 - p. 14

Conclusion ► FROG Owners Group is an effective forum for building networks between utilities and involving NSSS designer ► Each FROG Member benefits from sharing a large operating experience (~ 80 plants) within a rather small group of utilities ► Work performed within FROG contribute to improving plant safety and efficiency Introduction to FROG April 2012 - p. 15

Thank you for your kind attention For further information, please contact FROG Secretary M. Alain ISNARD Phone: 33 1 34 96 77 45 Fax: 33 1 34 96 77 52 E Mail: Alain.Isnard@areva.com
