First: The Old Way Compile plugin code on NetBSD Copy plugin - PowerPoint PPT Presentation

Feb 15, 2024 •266 likes •319 views

First: The Old Way Compile plugin code on NetBSD Copy plugin directory onto File System destined for SPC The New MSR Boot SPC Plugin Download Log in to SPC Environment requires user space and serial line or telnet

  1. First: The Old Way • Compile plugin code on NetBSD • Copy plugin directory onto File System destined for SPC The New MSR • Boot SPC Plugin Download • Log in to SPC Environment – requires user space and serial line or telnet access • Use modload(1) on SPC to load plugin – links plugin against kernel in /netbsd on SPC • Use modstat(1) on SPC to see list of loaded plugins Washington Washington jdd@arl.wustl.edu http://www.arl.wustl.edu/~jdd John DeHart - 6/24/2003 2 WASHINGTON UNIVERSITY IN ST LOUIS WASHINGTON UNIVERSITY IN ST LOUIS The New Way Exposed Functions • Compile plugin code on NetBSD • Kernel functions • Verify plugin has no undefined symbols – assert() – There is no link against running kernel anymore – MALLOC() – wu_arl/msr/usr/src/sys/msr/msr_lkm.h provides macros to needed – FREE() kernel functions and structures • Clock Functions • We can add more as we need them. • Plugins do need to be recompiled if msr_lkm.* changes – cpu_clock_1usec() • But if msr_lkm.* is stable, even if rest of kernel changes, plugin does – cpu_clock_10usec() not need to be recompiled. • Use pluginDownload utility from CP (Linux) to download – cpu_clock_1msec() plugin to SPC • LKM Functions – Only runs on Linux right now… – lkm_nofunc() • Use instantiatePlugin utility from CP to config plugin, – lkmdispatch() filters, etc – lkmexists() • Use pluginStat utility from CP to view list of loaded plugins Washington Washington John DeHart - 6/24/2003 3 John DeHart - 6/24/2003 4 WASHINGTON UNIVERSITY IN ST LOUIS WASHINGTON UNIVERSITY IN ST LOUIS 1

  2. Exposed Functions (continued) pluginDownload • Uses gnu binary utilities cross-linker • MSR Plugin Control Unit – Runs on Linux, builds a NetBSD binary – pcu_deregister_class() – Used to: • prelink to get size information – pcu_free_all_instances() • final link to relocate – pcu_register_class() • Uses new AAL5 control data channels to download plugin directly into kernel memory. – pcu_list_all_classes() – uses sendcmd API to: • allocate kernel memory for plugin • set up AAL5 data channel • call plugin entry function to complete load operation • Side Note: sendcmd API – should be expanded to include all of sendcmd, but right now we have about 15 “commands”. • Source files: wu_arl/utilities/SPC/plugDownload Washington Washington John DeHart - 6/24/2003 5 John DeHart - 6/24/2003 6 WASHINGTON UNIVERSITY IN ST LOUIS WASHINGTON UNIVERSITY IN ST LOUIS pluginDownload: steps it takes USAGE: pluginDownload – pre-link object file so we can get sizes pluginDownload [-h] [-d] [-V <vpivci>] [-D <fileDchan#> -D <symtabDchan#>] [-s] -p <port#> -e <entry> <input file> • use a bogus kernel address to force a.out file to have valid sizes -h : get this usage message – open pre-linked plugin file to get size -d : turn on debug output – allocate two chunks of kernel memory -V <vpivci> : specify the VPI/VCI to use for download. • 1: plugin code • 2: plugin symbols : overrides default of 164 + port# • returns addresses of two chunks and slot in lkm table -D <chan#> : specify the MSR Control Data Channel ids to use. – re-link plugin to relocate : First use of -D is for file channel – open two dchans into MSR kernel : second use of -D is for symbol table channel • plugin code : if they aren’t specified, they’ll be allocated • plugin symbols -p <port#> : specify the port to be downloaded to – download plugin code and symbols -e <entry> : specify the symbol name that should be called – finish plugin loading by calling its entry function : when module is loaded • sendcmd -c rp_pcu –s load causes kernel to call entry function -s : include symbols in the plugin download – release dchans Washington Washington John DeHart - 6/24/2003 7 John DeHart - 6/24/2003 8 WASHINGTON UNIVERSITY IN ST LOUIS WASHINGTON UNIVERSITY IN ST LOUIS 2

  3. USAGE: instantiatePlugin Example � ../../../utilities/bin/$MYOS/pluginDownload -p 4 -e wvplugin -s combined.o instantiatePlugin -p port [-h] [-ge] [-f filterId] pluginId flags # Gen plugin src src src dst dst dst srcAddr srcMask srcPort dstAddr dstMask dstPort protocol # Port Cfy Fid Id flags addr mask port addr mask port prot � instantiatePlugin -d -p 4 -g -f 0 200 0 0 0 0 192.168.220.2 255.255.255.255 5555 17 -p port : MSR Port to query -g : bind to general match classifier -e : bind to exact match classifier -f filterId : use this filter table entry (gen match classifier only) -h : Get this usage message Washington Washington John DeHart - 6/24/2003 9 John DeHart - 6/24/2003 10 WASHINGTON UNIVERSITY IN ST LOUIS WASHINGTON UNIVERSITY IN ST LOUIS Data Transfer Extra Supporting Notes MSR Kernel Dchannel Table Vaddr Length Next Addr Seq # Start of Virtual Length of block in Where next frame Next expected address block bytes (32b) should go. Initially frame sequence where data frames set to <Vaddr> number (first frame should go (32b) (32b) should be 1) (16b) Index(dchan#) 0 1 . . . DCHAN_MAX Washington Washington John DeHart - 6/24/2003 11 John DeHart - 6/24/2003 12 WASHINGTON UNIVERSITY IN ST LOUIS WASHINGTON UNIVERSITY IN ST LOUIS 3

  4. Data Transfer (continued) MSR Control Data Channel RATM AAL5 Frame Format (as it appears in the MSR Kernel) Shim Reserved space (8 Bytes) APIC Rx desc flags (8bits) dchan#(8bits) seq# (16bits) points here flags: framelength (16bits) pad (16bits) 1: Data 2016 B 2: Ack 2000 B 4: Nack 1992 B AAL5 Frame Data (<= 1992 Bytes) AAL5 Trailer (8 Bytes) Washington John DeHart - 6/24/2003 13 WASHINGTON UNIVERSITY IN ST LOUIS 4
