Evaluation of Aspects of E* Test Using HMA Specimens with Varying - PowerPoint PPT Presentation

Evaluation of Aspects of E* Test Using HMA Specimens with Varying Void Contents Dr. Geoffrey Rowe - Abatech Inc. Mr. Salman Hakimzadeh - University of KY Mr. Phillip Blankenship The Asphalt Institute Dr. Kamyar Mahboub University of


  1. Evaluation of Aspects of E* Test Using HMA Specimens with Varying Void Contents Dr. Geoffrey Rowe - Abatech Inc. Mr. Salman Hakimzadeh - University of KY Mr. Phillip Blankenship – The Asphalt Institute Dr. Kamyar Mahboub – University of KY TRB Annual Meeting - 2009

  2. Objectives of paper � Consider and compare different analysis techniques for construction of the master curve � Measure and analyze the effect of permanent strain on samples that have been tested using the SPT modulus test Study formed part of project being conducted for Kentucky Transportation Cabinet (with support from FHWA) to assess the effect of differing levels of compaction on a typical mixture performance.

  3. Overview � Experimental � Analysis � Observations � Recommendations � Conclusion

  4. Overview � Experimental � Analysis � Observations � Recommendations � Conclusion

  5. Experimental - Mix design � Used a standard KY mix design � 25% Limestone # 8’s � 26% limestone sand (unwashed), 14% limestone sand (washed) � 15 percent natural sand (rounded) � Asphalt binder (PG 64-22)

  6. Specimen and test setup Specimen production � from gyratory specimens by cutting and coring Temperature � condition Tested in IPC SPT � tester

  7. Experimental - Compaction levels � Compacted in Superpave Gyratory Compactor to give different volumetrics

  8. Testing � |E* | tests AASHTO TP 62-03 � 7 series � (14 specimens – 2 at each void content) � 3 temperatures (4, 20 and 40 o C) � 9 frequencies (25, 20, 10, 5, 2, 1, 0.5, 0.2, 0.1 Hz) � |E* | and δ for each test condition

  9. Typical data – expressed as E’ and E”

  10. Overview � Experimental � Analysis � Observations � Recommendations � Conclusion

  11. Analysis - to produce E* master curve in MEPDG format

  12. E* format α MEPDG referenced as = δ + log E * Witczak’s (symmetrical β + γ ω + (log ) 1 e or standard logistic) Sigmoid α Alternate sigmoid - = δ + log E * [ ] λ Richards’ (non- 1 / + λ β + γ ω (log ) 1 e symmetrical or generalized logistic) Sigmoid δ Lower asymptote, limit for |E* | at long loading times and high temperatures α Describes upper asymptote, ( δ + α ) gives limit for |E* | at short loading times and low temperatures β , γ , λ Describes the shape of the sigmoid

  13. Analysis methods � Excel-Solver analysis using solver to obtain master curve fits using the Witczak sigmoid function. � RHEA™ produced an analysis with discrete spectra to obtain glassy and equilibrium modulus values and other contributing parameters to the relaxation and retardation spectra. � RHEA - further used to determine fits to both Witczak’s (standard logistic curve) and the Richard’s sigmoid (generalized logistic curve) functions.

  14. Why Generalized logistic Generalized logistic curve � (Richard’s) allows use of non-symmetrical slopes 1 Introduction of additional � Typical range in parameter λ 0.9 inflection values When λ = 1 equation � 0.8 becomes standard logistic 0.7 When λ tends to 0 – then � 0.6 equation becomes λ =-0.5 Gompertz y λ =0.0 Gompertz 0.5 λ must be positive for Standard logistic inflection λ =0.6 � λ =1.0 Logistic analysis of mixtures 0.4 λ =2.0 since negative values will Minimum inflection 0.3 not have asymptote and produces unsatisfactory 0.2 inflection in curve Minimum value of � 0.1 inflection occurs at 1/e – or 36.8% of relative 0 height -6 -4 -2 0 2 4 6 x

  15. Glassy and equilibrium � Glassy and equilibrium modulus are considered as the asymptotes that are obtained from the various model fits with the glassy modulus corresponding to the higher asymptote and the equilibrium corresponding to the lower asymptote α = δ + log E * β + γ ω + (log ) 1 e α + δ = glassy modulus equilibrium modulus

  16. Glassy and equilibrium � Glassy and equilibrium modulus also computed for visco-elastic solid fit of discrete spectra to data set n ∑ − λ = + t / G ( t ) g g e i e i Generalized Maxwell Model = i= 1 to n i 1 ω λ 2 2 g e n ∑ ω = + i G ' ( ) g g … e i + ω λ 2 2 1 = i 1 i ωλ n = ∑ ω i G " ( ) g + ω λ i 2 2 1 Consider = i 1 i Spring constant, stiffness, g i Relaxation time, viscosity/stiffness, λ i = η i /g i EQUATIONS FOR VISCO-ELASTIC SOLID

  17. Excel-Solver 5.00 4.00 1 - Data 1 - Fit 3.00 2 - Data 2 - Fit Log E*, MPa 3 - Data 3 - Fit 4 - Data 4 - Fit 2.00 5 - Data 5 - Fit 6 - Data 6 - Fit 1.00 7 - Data 7 - Fit Note – data does not define 0.00 end of master curve well. More extrapolation at high -1.00 temperature end. -2.00 -15 -10 -5 0 5 10 15 Log Reduced Frequency, T ref =20C

  18. Excel-Solver

  19. RHEA - standard logistic α = δ + 5.00 log E * + β + γ ω (log ) 1 e 4.00 3.00 Log E*, MPa 2.00 1 - Data 1 - Fit 1.00 2 - Data 2 - Fit 3 - Data 3 - Fit 0.00 4 - Data 4 - Fit 5 - Data 5 - Fit 6 - Data 6 - Fit -1.00 7 - Data 7 - Fit -2.00 -15 -10 -5 0 5 10 15 Log Reduced Frequency, T ref = 20C

  20. RHEA - generalized logistic 5.00 4.00 3.00 Log E*, MPa 2.00 1.00 1 - Data 1 - Fit 2 - Data 2 - Fit 3 - Data 3 - Fit 0.00 4 - Data 4 - Fit 5 - Data 5 - Fit -1.00 6 - Data 6 - Fit 7 - Data 7 - Fit -2.00 -15 -10 -5 0 5 10 15 Log Reduced Frequency, T ref = 20C

  21. Overview � Experimental � Analysis � Observations � Recommendations � Conclusion

  22. E* (glassy) (MEPDG) vs. other methods / EXCEL The glassy modulus predicted by the MEPDG predictive equation results in a higher value of modulus than that obtained by the other methods.

  23. E* (glassy) vs. air voids

  24. E* (equilibrium) vs. air voids

  25. E* and δ with frequency

  26. Phase angle for all void levels 60 1 - Measured phase 1 - Calculated 50 2 - Calculated 3 - Calculated Phase Angle 4 - Calculated 40 5 - Calculated 6 - Calculated 7 - Calculated 30 20 10 0 -3 -2 -1 0 1 2 3 4 5 log Frequency (reduced), Hz

  27. Phase angle calculation � Shown – for a wide variety of materials – that – δ = 90(dlog E* /dlog ω ) { or G* } α = δ + log E * Standard logistic function β + γ ω + (log ) 1 e [ ] β + γ ω (log ) d log E * e δ ω = × = − αγ [ ] ( ) 90 90 ω β + γ ω 2 + d log (log ) 1 e

  28. Phase angle for all void levels 90 � All data sets 80 1 2 3 4 Phase Angle Calculated, δ show deviation 70 5 6 7 at highest 60 50 temperature 40 30 20 10 0 0 10 20 30 40 50 60 70 80 90 Phase Angle Measured, δ

  29. Change is specimen dimensions The change in specimen dimensions most likely has some effect � on the data The difference in air voids before and after the tests are small � The difference between replicates (and retests) is small �

  30. Response to haversine loading Stress is varied to Test keeps obtain strain required – level of Strain note pre-load. dynamic strain Stress constant Permanent strain

  31. 25Hz

  32. 20Hz

  33. 10Hz

  34. 5Hz

  35. 2Hz

  36. 1Hz – no creep

  37. 0.5 Hz – strain lower, no creep

  38. 0.2Hz – strain lower, creep

  39. 0.1Hz – strain lower, creep

  40. � Hysteresis and average loop, 25 Hz Hysteresis

  41. Evolution of hysteresis � The test moves from the high frequency to low – as per the direction of the red line � The strain changes by over 1000 microstrain – the equipment appears to reset and the strain reduces � The reduction is strain is an artifact of the software and is not really occurring � Really the specimen is deforming more in the axial direction

  42. Overview � Experimental � Analysis � Observations � Recommendations � Conclusion

  43. Test frequencies � Adding some additional test frequencies to the isotherms will improve the stability of shifting � This is important if we wish to assess suitability of different functional forms � Does not extend significantly the testing time

  44. Additional study/analysis � Need to determine effect of permanent strain of E* mastercurve � What is effect of plastic strain occurring � How to quantify a “reset” that occurs in current software � Probably best not to use specimens for flow testing

  45. Use of phase angle � Can use phase angle predictive relationship to assist with assessment of quality of data � If is does not agree – then look for issues with testing � Always inspect quality of data sets by careful examination of wave forms

  46. Overview � Experimental � Analysis � Observations � Recommendations � Conclusion

  47. Conclusions -1 of 2 � The values of equilibrium and glassy modulus are significantly affected by the selected analysis method as well as by the volumetric properties of the mixture. � The MEPDG prediction procedure significantly over-predicts the glassy asymptote. � The phase analysis data obtained from the high temperature testing did not coincide with the expected relationship for this parameter. It is highly likely that large permanent strain is significantly affecting this parameter.
