HMA Warranties The Wisconsin Experience HMA Warranties Historical Perspective What has been done so far The Benefits of Warranties Warranties in the 21 st Century - What the future holds for warranties HMA Warranties


  1. HMA Warranties The Wisconsin Experience

  2. HMA Warranties • Historical Perspective – What has been done so far • The Benefits of Warranties • Warranties in the 21 st Century - What the future holds for warranties

  3. HMA Warranties Historical Perspective • 1994 : WisDOT, FHWA and WAPA - Decided to pursue an innovative contracting method -Development of a warranty specification • 1995 : 3 warranty projects constructed • 1996 : 3 warranty projects constructed

  4. HMA Warranties Historical Perspective (cont.) • 1997: 3 warranty projects constructed - Revised the original specification and included a provision for sealing all joints at the end of the third year. - Developed a specification for overlaying PCC pavements. - Constructed a PCC overlay warranty

  5. HMA Warranties Historical Perspective (cont) • 1998 : Constructed 4 projects – Minor revision changed the sealing of cracks from 3rd to 4th year • 1999 : Constructed 5 projects - Warranties were expanded to include ancillary pavement • 2000 : Constructed 6 projects - Original 3 projects, constructed in 95, reached warranty expiration in 2000

  6. HMA Warranties Historical Perspective (cont) • 2001 10 projects • 2002 11 projects . Total of 45 warranty projects for 330 lane miles

  7. HMA Warranties The Benefits of Warranties • One of the major benefits of warranties is a superior performing pavement. • We measure pavement performance through Pavement Distress Index (PDI) and International Roughness Index (IRI). • Warranties are performing better under both indices.

  8. HMA Warranties PDI Values for Typical and Warranty HMA Pavements 30 25 20 15 Typical Warranty 10 5 0 New 1 st 2 nd 3 rd 4 th 5 th Year Year Year Year Year

  9. HMA Warranties IRI Values for Typical and Warranty HMA Pavements 1.6 1.4 1.2 1 0.8 Typical 0.6 Warranty 0.4 0.2 0 New 1 st 2 nd 3 rd 4 th 5 th year Year Year Year Year

  10. HMA RIDE MODELS 5 Historical HM A "new" construction data 4 Historical "Good" initial ride data 3 PSI HMA Warranty data Rehab. Trigger 2 1 23 yr Service Life 18 yr Service Life 0 0 10 20 30 AGE

  11. HMA Warranties Cost Analysis • Using performance data we can do LCCA comparison between typical and warranty pavements. • LCCA shows an economic benefit of warranted pavements (Break even point at 7% increase in initial cost.

  12. Life Cycle Cost Analysis Life Cycle Cost Analysis 122 100 27 $ 27 27 0.5 0.5 0.5 0.5 = 0.7 0.7 0.7 0 30 18 42 Time STANDARD HMA LCCA ? ? 27 27 27 0.5 = 0.5 0.7 0.7 35 47 0 23 Time HMA WARRANTY PROJECTION

  13. Life Cycle Cost Analysis Life Cycle Cost Analysis LCCA: TYPICAL vs. WARRANTY Present Worth Project Cost of Typical Projects Typical HMA Project Initial Cost (100) 18 yr life Maintenance (0.5) @ yr 3 Maintenance (0.7) @ yr 5 Overlay (27) 12 yr life 100 Maintenance (0.5) @ yr 21 Present Worth Maintenance (0.7) @ yr 23 Project Cost Mill & Overlay (27) 12 yr life Maintenance (0.5) @ yr 33 Maintenance (0.7) @ yr 35 Mill & Overlay (27) 12 yr life Maintenance (0.5) @ yr 45 Warranty HMA Project 50 Initial Cos t (??) 23 yr life Overlay (27) 12 yr life Maintenance (0.5) @ yr 26 Maintenance (0.7) @ yr 28 Mill & Overlay (27) 12 yr life Maintenance (0.5) @ yr 38 Maintenance (0.7) @ yr 40 Mill & Overlay (27) 12 yr life 0 100 105 110 Warranty Project Initial Cost (as a percent of Typical HMA Project Initial Costs)

  14. HMA Warranties Other Benefits of Warranties • Reduced WisDOT delivery costs • Reduced maintenance expenditures • Allows contractor innovation in researching and applying new technology • Warranties are a tool. • Manufacturer is responsible for their product

  15. HMA Warranties What are the hurdles • Change – Warranties are a wholesale change in the way we do business. • There is a shift in responsibility from WisDOT to the contractor.

  16. HMA Warranties The 21st Century • Improvements made to the selection process/criteria • All Asphalt Pavement projects will be “ considered ” for warranty • Updating Chapter 14 of the FDM to include direction on Warranties • Subgrade improvement initiative

  17. HMA Warranties The 21st Century (cont) • Extended Warranty Periods will be considered (ex: 7 year period) or tighter distress thresholds • Incentive pay for exceptional performance

  18. HMA Warranties Conclusion Warranties are a quality based initiative. Warranties are cost effective. Warranties are a tool. John Volker 608/246-7930 John.volker@dot.state.wi.us
