Energy Storage System MES150 Aki Tiira www.meruspower.com MES150 - PowerPoint PPT Presentation

Merus Power Dynamics Oy Energy Storage System MES150 Aki Tiira www.meruspower.com MES150 Normal active filters can provide only reactive power UPS-systems are not meant for PQ improvement MES150 is a combined solution


  1. Merus Power Dynamics Oy Energy Storage System MES150 Aki Tiira www.meruspower.com

  2. MES150 • Normal active filters can provide only reactive power • UPS-systems are not meant for PQ improvement • MES150 is a combined solution • Harmonic mitigation • Dynamic reactive power compensation • Load balancing • UPS-operation

  3. MES150 – Main components • Static switch • Separates system from faulty network • Inverter module • Produces output currents and voltages • Control system • Controls the Inverter module • Detects faults in the network • Energy storage • Provides active power when needed • Batteries or super capacitors

  4. MES150 - SLD

  5. MES150 – Operation modes • Active filtering mode • Eliminates harmonic currents in real time • Reactive power compensation in real time • Elimination of voltage fluctuations and flicker • Load balancing • Voltage source mode • Real Active and reactive power source • Voltage control

  6. MES150 - Active filtering mode

  7. MES150 - Voltage source mode

  8. MES150 – Operation

  9. MES150 - Applications • Locations which have frequent short interruptions • Voltage sags in transmission or distribution system • Power interruptions of transmission or distribution system • Auto reclose operations in transmission or distribution system • Loads which have high cost for short interruption • Continuous manufacturing processes • Sensitive equipment
