SLIDE 1

Efficient IoT Framework for Industrial Applications

DOCTORAL THESIS

Pablo Puñal Pereira

Industrial Electronics

SLIDE 2

Department of Computer Science, Electrical and Space Engineering Division of EISLAB Luleå University of Technology, Luleå, Sweden Supervisors: Jens Eliasson and Jerker Delsing

SLIDE 3

Introduction to IoT
Research
Access control
Efficient IoT

Framework

Case studies
Results
Discussion
Conclusion
Future work

3

CONTENT

SLIDE 4

4

What is Internet of Things?

INTRODUCTION

SLIDE 5

INTRODUCTION

5

“An IoT device is a resource-constrained embedded system with the capability to perform a number of well-defined tasks, such as sensing, signal processing, and networking. It usually has wireless communication capabilities and is powered by batteries”

Internet of Things

SLIDE 6

6

INTRODUCTION

Resource-constrained embedded device

✓ Small size ✓ Low weight ✓ Low cost ✓ Low power consumption ✓ Multiple I/Os

Communications
Sensors & Actuators

๏ Low processing ๏ Low memory

Program memory
Working memory
Data storage

๏ Battery lifetime restricted 

SLIDE 7

7

RESEARCH

Research questions

1.Is it feasible to use IoT-SOA technology in WSANs for industrial applications? 1.What are the benefits of adding IoT technology to industrial WSANs? 2.Is it possible to increase interoperability while mitigating performance impact? 2.How can access to exposed IoT nodes be protected and controlled while maintaining performance? 3.How can zero-configuration operation be achieved for an IoT node?

SLIDE 8

8

RESEARCH

Baseline of the research

Standards Communication Security Stack Application protocols Hardware compatibility Semantics Services Encryption Hardware Security Mechanisms Security level

SLIDE 9

9

RESEARCH

Evolution

IP-based Nodes Enable resources Access control Services Complex functionalities Bootstrapping Configuration Zero- configuration Run-time reconfiguration How to protect them?

SOA
Access policies
Customized

A B E G A D B C F G C F G EG G G

SLIDE 10

10

RESEARCH

Network architecture

Industrial Network Area to cover G1 N1 N2 N3 G2 N5 N4 N6 G3 N7 N8 Internal Servers Clients External Servers

SLIDE 11

11

RESEARCH

Network architecture

Application JSON/CBOR CoAP NTP UDP IP / IPsec 6LoWPAN IEEE 802.15.4

SLIDE 12

12

RESEARCH

Access control

Authentication Authorization

SLIDE 13

13

RESEARCH

Access control - Standardized solutions

RADIUS DIAMETER Kerberos

Complex processing
Low-power criteria
Latencies
Additional overhead
Communication
Computation
Extra communication
Low-power criteria
Network performance

SLIDE 14

14

RESEARCH

Access control - Proposed solution

Ticket-based access control

Reduced message overhead
Reduced extra-communications
Reduced processing overhead
Dual-Authentication

SLIDE 15

15

RESEARCH

Access control - Proposed solution IP header UDP header CoAP header Data IPsec header

69 bytes 20 bytes + 20 bytes + 8 bytes + 21 bytes 20 bytes + 20 bytes + 8 bytes + (21+8) bytes 77 bytes

SLIDE 16

16

RESEARCH

Access control - Proposed solution

Message size (bytes) 75 150 225 300 G E T P O S T P U T D E L E T E O B S E R V E A C K R E S E T . w e l l

k

n

w

n / c

r

e r e s p

n

s e

RFC Access control Dual authentication

8.2% 8.5% 8.5% 8.5% 8.0% 8.5% 8.5% 7.2% 3.4%

SLIDE 17

17

RESEARCH

Access control - Authentication

Client AAA Server Authentication Request Authenticator Challenge Request-Response Encrypt Password Ticket Authentication Process Authentication Process

SLIDE 18

18

RESEARCH

Access control - CoAP

CoAP Client CoAP Server AAA Server CoAP Request Standard Request without Access Control Standard Request without Access Control

SLIDE 19

RESEARCH

Access control - CoAP

CoAP Client CoAP Server AAA Server CoAP Request Get Ticket Check Ticket Valid Ticket Access Control - Access Allowed - First Request Access Control - Access Allowed - First Request CoAP Request Get Ticket and check Access Control - Access Allowed - Non-First Request Access Control - Access Allowed - Non-First Request 19

SLIDE 20

20

RESEARCH

Access control - AAA Server Architecture

RADIUS Server CoAP MQTT XMPP HTTP ... RADIUS Client

Ticket Generation Ticket Validation Per Access Per Time

Accepted Protocols AAA Server Accounting

SLIDE 21

21

RESEARCH

Access control - Custom services example

Non-authorized Authorized Administrator

SLIDE 22

22

RESEARCH

Efficient IoT framework

Scalability Security Interoperability Industrial IoT requirements Companies/Alliances on IoT Intel, IPSO, OMA, IETF, Microsoft, ZigBee-Alliance, IBM, Cisco, Motivity, IIC…

SLIDE 23

23

RESEARCH

Efficient IoT framework

Bootstrapping Access control Device Manager Configuration Efficient IoT Framework

SLIDE 24

24

RESEARCH

Efficient IoT framework - Bootstrapping

Primary Service (before deployment)
Preconfigured endpoint / discoverable
Provides routes to other basic services
Access control
Configuration
Device manager
Accept service replication [robustness and scalability]

SLIDE 25

25

RESEARCH

Efficient IoT framework - Device manager

OMA LWM2M-based
Provide relevant information of the Nodes:
Serial number
Endpoints
Model number
Firmware version

SLIDE 26

26

RESEARCH

Efficient IoT framework - Configuration

Service-Producer
Services configuration
Actuators configuration
Sensors configuration
Service-Consumer
Services to use
How to use the services (type of access, semantics,…)

SLIDE 27

27

RESEARCH

Efficient IoT framework - Security

The framework is not dependent of one specific

technology:

IPsec + IKEv2
Standard
Custom
An energy consumption profile is needed

SLIDE 28

28

CASE STUDIES

Characteristics

Condition monitoring:
Wheel-loader
Rock bolts
The use of wires is problematic:
Wireless communication
Batteries

SLIDE 29

29

CASE STUDIES

Mobile Machinery Monitoring

SLIDE 30

30

) Period)covered:)) ) ) From)month)13)))))))))))))))))))))to))month)24) ) Task)leader:)))PerNErik)Larsson,)SKF)))))))))))))))))))))))))

per-erik.larsson@skf.com

!

CASE STUDIES

Mobile Machinery Monitoring

SLIDE 31

31

Standard rock bolt

1900s technology
Reinforce critical structures

CASE STUDIES

Smart rock bolt

SLIDE 32

32

CASE STUDIES

Smart rock bolt

SLIDE 33

33

IKE_INIT IKE_AUTH Bootstrapping Configuration Authentication Authorization Manager

5 10 15 20 25 30 35 500 1000 1500 2000

Energy consumption (mJ) Services @ 96 MHz @ 48 MHz

RESULTS

Energy consumption by service

SLIDE 34

34

IKE_INIT IKE_AUTH Bootstrapping Configuration Authentication Authorization Manager

50 100 150 200 2000 4000 6000 8000 10000 12000

Delay (ms) Services @ 96 MHz @ 48 MHz

RESULTS

Delay by service

SLIDE 35

35

DISCUSSION

Limitations

Use of long timeouts to reduce the power

consumption

Standard technologies
OMA LWM2M
IPSO Smart Objects
6LoWPAN
Key negotiation mechanisms

SLIDE 36

36

DISCUSSION

Limitations

Use of big timeouts to reduce the power

consumption

Standard technologies
OMA LWM2M
IPSO Smart Objects
6LoWPAN
Key negotiation mechanisms

SLIDE 37

37

CONCLUSIONS

Research questions

1.Is it feasible to use IoT-SOA technology in WSANs for industrial applications? 1.What are the benefits of adding IoT technology to industrial WSANs? 2.Is it possible to increase interoperability while mitigating performance impact? 2.How can access to exposed IoT nodes be protected and controlled while maintaining performance? 3.How can zero-configuration operation be achieved for an IoT node?

SLIDE 38

38

FUTURE WORK

Access control

Accounting
Robust ticket generation (COSE-like)
CoAP-RADIUS reliability
Scalability analysis

SLIDE 39

39

FUTURE WORK

Efficient IoT framework

Efficiency
Security
Key negotiations
Run-time reconfiguration
Scalability
Quality of Service

SLIDE 40

THANKS TO

SLIDE 41

Efficient IoT Framework for Industrial Applications

DOCTORAL THESIS

Pablo Puñal Pereira

Industrial Electronics
