E.R.A.S.E Explosives Remediation by Applied Synthetic E. coli TNT - PowerPoint PPT Presentation

E.R.A.S.E Explosives Remediation by Applied Synthetic E. coli TNT AND NITROGLYCERIN POLLUTANTS Direct Health Economic Environmental carcinogenic accumulation in water diminished crop yields cost of healthcare cause of cataracts decreased


  1. E.R.A.S.E Explosives Remediation by Applied Synthetic E. coli

  2. TNT AND NITROGLYCERIN POLLUTANTS Direct Health Economic Environmental carcinogenic accumulation in water diminished crop yields cost of healthcare cause of cataracts decreased land value cause of liver damage cost of remediation anemia toxic to plants toxic to animals

  3. THE PROBLEM TNT and NG waste sites

  4. THE PROBLEM Germany In WWII 800,000 t TNT produced For every ton: 40,000 L of water contaminated

  5. THE PROBLEM 56 military sites Hawaii: 1.4 g NG per Kg of soil New Mexico: 2.5 g TNT per Kg of soil Texas: 32 g TNT per Kg of soil

  6. CURRENT DECONTAMINATION PROCESSES Carbon adsorption columns Equipment is expensive HPLC required for confirmation Specialist training required Cannot be performed on site

  7. CURRENT DECONTAMINATION PROCESSES Contained incineration Destroys vegetation Reduced soil fertility Atmospherically polluting

  8. IMPORTANCE Funding: £4 million. Looking for short-term, proof-of-concept research proposals including: “sensor technologies to detect chemicals, such as explosives …” “… and decontamination approaches.”

  9. IDEAL SYNTHETIC SOLUTION Enzymes Degrade explosive pollutants to harmless Promoter Kill Switch products Detects substrate and Terminates lifecycle of organism regulates specific upon completion of function response

  10. IDEAL SYNTHETIC SOLUTION Sensor Produces an observable output signal to confirm substrate presence Enzymes Degrade explosive pollutants to harmless Promoter Kill Switch products Detects substrate and Terminates lifecycle of organism regulates specific upon completion of function response

  11. PROJECT AIMS Enzymes Degrade explosive pollutants to harmless Promoter products Detects substrate and regulates specific response

  12. MODELLING To assist with the design, analysis and debugging our system. Which properties should be characterised by experiment? Provides an abstract representation of how our project works.

  13. BIOCHEMICAL LEVEL Degradation rate is most influenced by enzymes ’ kinetic performance This model considers: -Enzyme kinetics -Substrate toxicity 25 [toxic substrate] 20 arb. units 15 10 5 Cell population 0 1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 Time Conclusion: Km, Vmax and toxicity must be experimentally determined to indicate how our system may perform.

  14. MULTI-CELLULAR LEVEL A spatial simulation of a population Degradation rate  [substrate] AND availability Growth response to regions of varying [substrate] Accounts for residual [substrate] remaining after cell death Accounts for intracellular [substrate] in daughter cells after division Probability cells dying or dividing (  local [substrate])

  15. Kill switch repressed by substrate The population may not degrade all TNT and NG in a sample where substrate distribution is non-uniform

  16. Our bacteria must be able to cope with samples where substrate distribution is non-uniform The maximum distance between islands of substrate can be altered by tuning different aspects of the bacteria: Kill switch delay and more Enzyme kinetics

  17. AIM 1: IDENTIFICATION OF AND CHARACTERISATION OF ENZYMES

  18. IDENTIFICATION OF ENZYMES PETN reductase enzyme is in the iGEM Registry But was not completely characterised Uncharacterised enzymes from scientific literature: XenB (BBa_K1398001) NemA (BBa_K1398003) Higher affinities for both TNT Similar to the comparatively and NG than PETN reductase well understood PETN reductase

  19. PURIFIED NEMA DEGRADATION OF NITROGLYCERIN Control experiments: 1. No protein 1,2,3. Protein minus cofactors 4. Cofactors + NemA protein: 90% of Nitroglycerin degraded after 15 minutes at room temperature Error: standard deviation in Raman spectrum

  20. IN VIVO DEGRADATION OF TNT Degradation of the aromatic ring of TNT causes a distinctive set of colour changes to be observed in the sample: Pablos et al. 2014: created a non biological sensor using the red coloured meisenheimer complex. We observed red fading to yellow, indicating further degradation.

  21. IN VIVO DEGRADATION OF TNT Wild Type 40 min 160 min 80 min Remains colourless

  22. IN VIVO DEGRADATION OF TNT XenB 40 min 160 min 80 min

  23. IN VIVO DEGRADATION OF TNT NemA 40 min 160 min 80 min

  24. PURE NEMA STOPPED ENZYME ASSAY Vi as a function of [nitroglycerin] 7.00E-07 ~Hyperbolic curve 6.00E-07 Vi /mol min-1 5.00E-07 4.00E-07 3.00E-07 2.00E-07 1.00E-07 0.00E+00 0 0.002 0.004 0.006 0.008 0.01 0.012 [nitroglycerin] /M Asymptote, Vmax  21  mol mg -1 min -1 Km  6 mM

  25. CONCLUSIONS OF CHARACTERISATION NemA degrades nitroglycerin in vitro NemA and XenB degrade TNT in vivo Preliminary kinetic characterisation of NemA Development of Raman and HPLC techniques Quantification of TNT and NG was VERY challenging This further highlights the need for a synthetic biological solution to quantification of these substrates

  26. AIM 2: IDENTIFYING AND ENGINEERING A PROMOTER

  27. TWO PROMOTERS BASED ON THE NEMR RESPONSE Synthetic promoter NemR UIR Responsive to the TNT- binding repressor protein NemR

  28. PROMOTER PERFORMANCE Minimal fluorescence 1500 Control Cells nemR Promoter in control cells Synthetic Promoter Fluorescence/OD 1000 Constitutive expression 500 for NemR UIR 0 0.00 0.05 0.10 0.15 0.20 0.25 Our inducible synthetic TNT concentration (mM) promoter responds positively to increasing TNT concentration

  29. CONCLUSIONS OF PROMOTER ASSAYS We have a promoter that responds to TNT This could facilitate use of: • A biosensor • A kill switch In future: test linear response to increasing concentrations of TNT

  30. IDEAL SYNTHETIC SOLUTION Enzymes Degrade explosive pollutants to harmless Promoter Kill Switch products Detects substrate and Terminates lifecycle of organism regulates specific upon completion of function response

  31. IDEAL SYNTHETIC SOLUTION Sensor Produces an observable output signal to confirm substrate presence Enzymes Degrade explosive pollutants to harmless Promoter Kill Switch products Detects substrate and Terminates lifecycle of organism regulates specific upon completion of function response

  32. PROJECT CONCLUSION Enzymes Degrade explosive pollutants to harmless Promoter products Detects substrate and regulates specific response

  33. OUTREACH: E.R.A.S.E THE GAME! A mobile game on Google Play Education to show off the degradation side of our project! https://play.google.com/store/apps/details?id=ppr.development.igemgameProject&hl=en_GB

  34. ACKNOWLEDGMENTS Undergraduate Team Supervisors Ed Muir Dr. John Love Peter Reader Dr. Thomas Bethany Hickton Howard Ben Miller Dr. Paul Katie Pearce James Max Smart Dr. Lizzy Martyn Bennett Dridge Jessica Rollit Dr. Christine Elize Hernendez Sambles
