Cirrus: A Serverless Framework for End-to-end ML Workflows Joao Carreira , Pedro Fonseca, Alexey Tumanov, Andrew Zhang, Randy Katz Machine Learning End-to-end ML workflows Modern end-to-end ML workflows are complex End-to-end ML
SLIDE 2
SLIDE 3
End-to-end ML workflows
- Modern end-to-end ML workflows are complex
SLIDE 4
End-to-end ML workflows
- Modern end-to-end ML workflows are complex
- ML workflows consist of 3 heterogeneous stages
SLIDE 5
End-to-end ML workflows
- Modern end-to-end ML workflows are complex
- ML workflows consist of 3 heterogeneous stages
Dataset Preprocessing
SLIDE 6
End-to-end ML workflows
- Modern end-to-end ML workflows are complex
- ML workflows consist of 3 heterogeneous stages
Dataset Preprocessing Model Training
SLIDE 7
End-to-end ML workflows
- Modern end-to-end ML workflows are complex
- ML workflows consist of 3 heterogeneous stages
Dataset Preprocessing Model Training Hyperparameter Tuning
SLIDE 8
End-to-end ML workflows
- Modern end-to-end ML workflows are complex
- ML workflows consist of 3 heterogeneous stages
ML workflows are interactive and iterative
Dataset Preprocessing Model Training Hyperparameter Tuning
SLIDE 9
Provisioning ML workflows
Provisioning ML workflows is challenging
- Complex infrastructure management detracts from ML work
- Resource waste due to overprovisioning of resources
Hard to accurately estimate resource demands of each stage Data scientists have limited systems expertise
SLIDE 10
Serverless computing
Output Input Code
AWS S3
SLIDE 11
Serverless computing
Output Input Code
SLIDE 12
Fine-grained resources Fine-grained billing High elasticity Automatic resource configuration / provisioning / maintenance
Serverless computing benefits
Tight provisioning of resources Simplifying infrastructure management
SLIDE 13
Challenges of serverless
Small local memory and storage Short-lived and unpredictable launch times Low bandwidth and no P2P communication Lack of fast shared storage Limited lambda package size
SLIDE 14
Existing approaches
Serverless Frameworks Machine Learning Frameworks
Short-lived and unpredictable launch times
SLIDE 15
Existing approaches
Serverless Frameworks Machine Learning Frameworks
PyWren
Short-lived and unpredictable launch times
- Limit. Pkg
size
Download dependencies from S3 High-latency communication through S3
No fast storage
Stragglers
Unpred. launch
SLIDE 16
Existing approaches
Serverless Frameworks Machine Learning Frameworks
PyWren
Short-lived and unpredictable launch times
- Limit. Pkg
size
Download dependencies from S3 High-latency communication through S3
No fast storage
Stragglers
Unpred. launch Small mem.
Unable to launch runtimes in lambdas No ring/tree reduces No driver-to-worker comm. Precludes MPI
Unpred. launch No P2P comm.
SLIDE 17
Cirrus: a framework for serverless end-to-end ML workflows
SLIDE 18
Robust handling of lambda termination Ultra-lightweight runtime + data prefetching
Limited pkg size
High-perf. data store (parameter-server and KV)
1）Addressing serverless challenges
No fast storage Low memory Limited package size No P2P communication Short lifetimes and unpredictable launch
Cirrus: design principles
SLIDE 19
Per-stage fine-grained variable agile scalability
Cirrus: design principles
Limited pkg size
Tight provisioning of resources Simplifying infrastructure management
High-level API supports end-to-end ML
2）Achieving benefits for end-to-end ML
SLIDE 20
Cirrus architecture (client side)
Dashboard Python API Client frontend
Preproc. Training Tuning Create/Stop Task
Client backend
Task Scheduler Lambda Manager
Client side (stateful) Data scientist
SLIDE 21
Cirrus Dashboard
SLIDE 22
Cirrus Dashboard
SLIDE 23
Cirrus Dashboard
SLIDE 24
Cirrus Dashboard
SLIDE 25
Server side (stateless)
Cirrus runtime
Data Iterator API Minibatch Buffer
Sparse LR
- Mat. Fact.
LDA
Data store client API put (gradient) get (model) Data store
PS API Key-value API Models Key-values SGD Adagrad Momentum
Cirrus architecture (server side)
put/get key
SLIDE 26
Cirrus evaluation
1. Cirrus provides benefits by specializing both for serverless and end-to-end ML 2. We show that Cirrus outperforms a state-of-the-art serverless system: PyWren
SLIDE 27
Evaluation setup
1. Deployment: AWS Lambdas (3GB of mem.) 2. Benchmark: async. distributed SGD Sparse Logistic Regression task 3. Dataset: Criteo Dataset (a dataset of display ads) 4. PyWren: a. Baseline: iterative synchronous SGD training using AWS S3 to store gradients and model b. + 3 incremental optimizations 5. Cirrus: 2 modes (with/without prefetching)
SLIDE 28
Cirrus outperforms vanilla serverless
Synchronous SGD training suffers from stragglers
Test Loss
SLIDE 29
- Multiple SGD iterations on
each lambda invocation
- Asynchronous SGD
Test Loss
Cirrus outperforms vanilla serverless
SLIDE 30
Sparse gradients and training data prefetching
Test Loss
Cirrus outperforms vanilla serverless
SLIDE 31
Replace AWS S3 with high-performance store (Redis)
Test Loss
+700x updates/sec
Cirrus outperforms vanilla serverless
SLIDE 32
Cirrus without training data prefetching
Test Loss
10x faster
Cirrus outperforms vanilla serverless
SLIDE 33
Cirrus with training data prefetching
Test Loss
10x faster 10x faster
Cirrus outperforms vanilla serverless
SLIDE 34
Conclusion
1. End-to-end ML workflows: a. time-consuming infrastructure management b. resource overprovisioning 2. Cirrus -- serverless end-to-end ML framework: a. simplify deployment of ML workflows b. per-stage provisioning of resources 3. Cirrus outperforms existing serverless solutions by specializing for serverless and ML
