Calculation Engine Presented by Lyn Quek, Customer Support - PowerPoint PPT Presentation

Oct 02, 2022 •1.49k likes •1.63k views

Next Generation Calculation Engine Presented by Lyn Quek, Customer Support Engineer Prae Numswangneth, Customer Support Engineer Asset Based Analytics 2 3 Pre-release Software 4 Planned Version 1 Perform calculations using PE syntax

Next Generation Calculation Engine Presented by Lyn Quek, Customer Support Engineer Prae Numswangneth, Customer Support Engineer
Asset Based Analytics 2
3
Pre-release Software 4
Planned Version 1 • Perform calculations using PE syntax – Input: AF attributes – Outputs: AF attributes, PI Points, event frames • Support for Calculation dependencies • Aggregation and Rollup • Preview and test using historical PI data • Trigger-based or scheduled calculations • Manual backfill 5
Key Benefits • Easy! • Performance and scalability • Standardize/Reuse/Manageable • Not just numbers, but also events • Aggregate PI and 3 rd party data 6
Timing • Private CTP – Released in May • Public Beta – Est. Q3 2013 • Official Release – Est. Q1 2014 7
PI Power System Users Admins Get hands on knowledge of how to System use and get value from the PI System Developers Integrators OSIsoft Anyone Partners technical 8
Contact Us Lyn Quek lquek@osisoft.com Customer Support Engineer OSIsoft Asia Pte. Ltd. Prae Numswangneth prae@osisoft.com Customer Support Engineer OSIsoft Asia Pte. Ltd. 9
