Bayshore Boulevard/Cesar Chavez Street/ Potrero Avenue Intersection - PowerPoint PPT Presentation

Bayshore Boulevard/Cesar Chavez Street/ Potrero Avenue Intersection (The Hairball) Key Segment Improvements Municipal Transportation Agency Board of Directors 09/19/2017 N Hairball Item Project Area Map Jerrold Avenue (Barneveld Ave. to


  1. Bayshore Boulevard/Cesar Chavez Street/ Potrero Avenue Intersection (The Hairball) Key Segment Improvements Municipal Transportation Agency Board of Directors 09/19/2017

  2. N

  3. Hairball Item Project Area Map Jerrold Avenue (Barneveld Ave. to Bayshore Blvd.) NB Bayshore Blvd (Jerrold Ave. to Marin St.) West Side of Barneveld Ave. (McKinnon Ave. to Jerrold Ave.) Parking Restrictions Only

  4. Looking north from Marin Street into entrance to the Hairball and 101 N on-ramp

  5. Looking south from intersection of NB Bayshore Blvd. and Marin St.

  6. Looking south from intersection of NB Bayshore Blvd. and Marin St.

  7. Intersection of Jerrold Ave. at NB Bayshore Blvd. looking towards Barneveld Ave.

  8. Proposed Changes Intersection marking upgrades at Marin St. and Jerrold Ave. at Bayshore Blvd. New bike lane on SB Jerrold Ave. New protected bike lane on NB Jerrold Ave. Crosswalk upgrades at N Barneveld Ave. and Jerrold Ave. (3 crosswalks)

  9. Parking and Loading Changes TOW AWAY NO PARKING ANYTIME (east side of street only) TOW AWAY NO STOPPING, 10PM to 2AM EVERYDAY (west side of street only) N
