Autonomous ETL With Materialized Views Abhishek Somani, Adesh Rao May 2018

Agenda 1. Standard techniques for structuring data for SQL-on-Hadoop (Hive, Presto, Spark etc) 2. Difficulties in structuring data 3. A case for Materialized Views 4. Challenges with Materialized Views 5. Solution 2

Agenda 1. Standard techniques for structuring data for SQL-on-Hadoop (Hive, Presto, Spark etc) 2. Difficulties in structuring data 3. A case for Materialized Views 4. Challenges with Materialized Views 5. Solution 3

Data structuring for SQL-on-Hadoop ● Partitioning 4

Data organization for SQL-on-Hadoop ● Columnar File Formats Parquet ORC 5

Data organization for SQL-on-Hadoop ● Sorting ● Bucketing 6

Data organization for SQL-on-Hadoop Speedup of Unsorted vs Sorted ORC data on TPCDS scale 1000 7

Agenda 1. Standard techniques for structuring data for SQL-on-Hadoop (Hive, Presto, Spark etc) 2. Difficulties in structuring data 3. A case for Materialized Views 4. Challenges with Materialized Views 5. Solution 8

Difficulties in Structuring Data ● Workload Aware identification ● Evolving query patterns of optimal data structure ● Data pipeline dependencies ● Flexibility of data structuring ● Seamless restructuring ● Large number of consumers ● Continuous and automatic ● Data Admin Involvement maintenance ● Downtime NO DOWNTIME! 9

Agenda 1. Standard techniques for structuring data for SQL-on-Hadoop (Hive, Presto, Spark etc) 2. Difficulties in structuring data 3. A case for Materialized Views 4. Challenges with Materialized Views 5. Solution 10

Basics: Materialized View ● A materialized view is a database object that contains the results of a query. ● It is a view for which the data has been materialized . ● Materialized Views can be consumed automatically by the query engine Example: CREATE MATERIALIZED VIEW mv AS SELECT seller_id, seller_name, num_item*cost AS value FROM sales; Effect: Query rewrite SELECT seller_id, num_item*cost AS value FROM sales; ~ SELECT seller_id, value FROM mv; 11

Materialized Views in Hive for Data Restructuring Interesting properties of Materialized Views in Hive: ● A copy of the data(full, partial or transformed) ● Used automatically by the engine based on cost analysis ● Can be stored as ORC, Parquet etc ● Multiple materialized views can co-exist, optimally chosen Plus: Storage is cheap Idea: Create multiple materialized views of the full data with desired structures 12

Materialized Views for Data Restructuring Example: Original Table T1: Query1: SELECT * from T1 where customer_id = 26988 and month ● Partitioned on Year, Month, Day = “January”; ● Stored as Text Rewritten: SELECT * from MV1 where customer_id = 26988 and month = “January”; Materialized View MV1: ● Partitioned on Year, Month, Day ● Sorted on Customer_Id Query2: SELECT * from T1 where seller_id = 121 and month = ● Stored as ORC “January”; Materialized View MV2: Rewritten: SELECT * from MV2 where seller_id = 121 and month = ● Partitioned on Year, Month, Day “January”; ● Sorted on Seller_Id ● Stored as ORC 13

Materialized Views in SQL-on-Hadoop engines ● Basic implementation available in Apache Hive 2.3.0 ○ Uses Apache Calcite for query optimization and query rewrite ○ Multi file format support. Uses ORC (by default) for optimized columnar storage of materialized queries ● Not available in Presto ● Not available in Spark 14

Agenda 1. Standard techniques for structuring data for SQL-on-Hadoop (Hive, Presto, Spark etc) 2. Difficulties in structuring data 3. A case for Materialized Views 4. Challenges with Materialized Views 5. Solution 15

Challenges with Materialized Views ● Invalidation ○ Only a subset of use cases can work with stale data ● Rebuilds and Refreshes ○ Prohibitively expensive for full data copies ● Maintenance Isolation ○ Ongoing queries get affected 16

Agenda 1. Standard techniques for structuring data for SQL-on-Hadoop (Hive, Presto, Spark etc) 2. Difficulties in structuring data 3. A case for Materialized Views 4. Challenges with Materialized Views 5. Solution 17

FastCopy: A framework for Autonomous Materialized Views ● Materialized Views for Sorting, Partitioning and Bucketing for structuring data ● Synchronous invalidation on table updates ● Asynchronous automatic refreshes ● Maintenance isolation by refreshes in their own scheduler queues, or even their own cluster ● Recommendation Engine to suggest Materialized Views ● Cross engine support for using Materialized Views 18

Qubole FastCopy Infrastructure 19

Qubole FastCopy Infrastructure FastCopy Creation 20

Qubole FastCopy Infrastructure FastCopy Creation 21

Qubole FastCopy Infrastructure FastCopy Creation 22

Qubole FastCopy Infrastructure FastCopy Creation FastCopy Creation 23

Qubole FastCopy Infrastructure Incoming query for rewrite 24

Qubole FastCopy Infrastructure Query Rewrite 25

Qubole FastCopy Infrastructure Query Rewrite 26

Qubole FastCopy Infrastructure Query Rewrite 27

Qubole FastCopy Infrastructure Invalidation and Refresh 28

Qubole FastCopy Infrastructure Invalidation and Refresh 29

Qubole FastCopy Infrastructure Invalidation and Refresh 30

Qubole FastCopy Infrastructure Invalidation and Refresh 31

Qubole FastCopy Infrastructure Invalidation and Refresh 32

Qubole FastCopy Infrastructure Invalidation and Refresh 33

Qubole FastCopy Infrastructure Invalidation and Refresh 34

Fun Details ● Auto detect added, dropped or updated partitions using partition level tokens ● Multi Version Concurrency Control for FastCopy ● Minion clusters for workload isolation 35

Recommendations ● Top Tables 36

Recommendations ● Top Tables 37

Recommendations ● Column Usage as Filter predicates 38

Recommendations ● Column Usage as Filter predicates 39

Recommendations ● Column Usage as Filter predicates 40

Recommendations ● Top Tables 41

Recommendations ● Top Tables 42

Recommendations ● Column Usage as Filter predicates 43

Recommendations ● Column Usage as Filter predicates 44

Recommendations ● Column Usage as Filter predicates 45

Revise 1. Standard techniques for structuring data for SQL-on-Hadoop (Hive, Presto, Spark etc) 2. Difficulties in structuring data 3. A case for Materialized Views 4. Challenges with Materialized Views 5. Solution 46

Status ● FastCopy is at an internal Alpha ● Will soon be released as a beta for customers in the next Quarter ● Contribute to Open Source Thank You 47

Thank You Abhishek Somani, Adesh Rao May 2018
