OHare Modernization Program and Chicago Federal Aviation Administration Airspace Project Overview Presented to: Northwestern University Transportation Center By: Christina Drouet, P.E. Manager, Chicago Modernization Program April 4,


  1. O’Hare Modernization Program and Chicago Federal Aviation Administration Airspace Project Overview Presented to: Northwestern University Transportation Center By: Christina Drouet, P.E. Manager, Chicago Modernization Program April 4, 2014 Date:

  2. Briefing Agenda • Federal Aviation Administration (FAA) Overview • Chicago/Chicago Department of Aviation (CDA) and the O’Hare Modernization Program (OMP) • Federal Aviation Administration (FAA) actions and analysis • Funding and schedule • Chicago Airspace Project (CAP) • Enhancing safety and efficiency OMP/CAP Overview Federal Aviation April 4, 2014 Administration 2

  3. Federal Aviation Administration • Agency within the US Department of Transportation. The Secretary of Transportation is a member of the President’s Cabinet. • Responsibilities include: o civil aviation safety o air traffic control/management o promoting aviation o enforcing aviation regulations OMP/CAP Overview Federal Aviation April 4, 2014 Administration 3

  4. FAA Lines of Business • Four operational organizations – Air Traffic Organization – Airports – Aviation Safety – Commercial Space Transport • Numerous staff offices that provide human resource, legal, financial, communications and other support services to the Agency OMP/CAP Overview Federal Aviation April 4, 2014 Administration 4

  5. FAA relationship with Airport Sponsors • Regulatory – airport certification for commercial service airports • Financial ― federal grants for airport improvements ― oversight and approval authority to collect airport- specific passenger fees ― compliance with conditions associated with grants and fees • Technical – airport planning and design standards • Collaborative – provide air traffic control and supporting infrastructure OMP/CAP Overview Federal Aviation April 4, 2014 Administration 5

  6. OMP/CAP Overview Federal Aviation April 4, 2014 Administration 6 6

  7. Brief Overview of OMP • In 2001 the City of Chicago proposed a ~$7 billion reconfiguration of O’Hare, known as the O’Hare Modernization Program (OMP). • The FAA issued a Record of Decision (ROD) approving the OMP and master plan projects in September 2005. • The OMP changes the airport from a predominantly intersecting runway configuration to six parallel runways with two crosswind runways. • Future terminal plans are included. OMP/CAP Overview Federal Aviation April 4, 2014 Administration 7

  8. OMP Funding and Schedule • To date, Chicago Department of Aviation (CDA) has spent over $3.28B on the OMP. • The estimated overall program cost through the completion of Phase 2A (October 2015) is $4.4B. • Phase 2B is not funded or scheduled. Estimated construction cost is over $2B. • Passenger Facility Charge (PFC) authorization to date - $3.3B • Through two Letters of Intent and two amendments, the total FAA Airport Improvement Program (AIP) funding commitment for the entire OMP is $902 million. • The City of Chicago provides additional funding, through the use of General Airport Revenue Bonds (GARBS) OMP/CAP Overview Federal Aviation April 4, 2014 Administration 8

  9. FAA involvement with the O’Hare Modernization Program • Special Projects Office established in 2002 – Staff from appropriate functional areas • Manager represents the FAA and acts as a single point of communication with Chicago – Briefs and advises FAA executive management – Conducts the FAA orchestra • Design and implement major airspace changes for the larger Chicago metropolitan area • Provide design and installation services for FAA equipment and systems OMP/CAP Overview Federal Aviation April 4, 2014 Administration 9

  10. O’Hare Modernization Program (OMP) Runway 9L-27R November 2008 Runway 14L-32R 7,500 x 150 feet Decommissioning: NLT Aug 2015 Runway 4L-22R Temporary Closure TBD Runway 14R-32L 11,245 x 200 feet Temporary and extended closures TBD 11,260 x 150 feet Runway 9C-27C TBD Runway Ext 9R-27L TBD 13,000 x 150 feet Runway Ext 10L-28R 10,800 x 200 feet September 2008 Runway 10C-28C 7,500 x 150 feet October 2013 Runway 10R-28L October 2015 OMP/CAP Overview Federal Aviation April 4, 2014 Administration 10

  11. Airspace and Runway Utilization • How O’Hare runways were used before new OMP runways were completed • Step through runway construction and corresponding airspace configurations • Runway utilization after Runway 10C/28C commissioning in October 2013 • Final O’Hare configuration OMP/CAP Overview Federal Aviation April 4, 2014 Administration 11

  12. Noise Contours OMP/CAP Overview Federal Aviation April 4, 2014 Administration 12

  13. Runway Utilization Pre-OMP West Flow East Flow approx 42% with approx 36% with optimal weather optimal weather Information from FAA EIS, Exhibit D-1 OMP/CAP Overview Federal Aviation April 4, 2014 Administration 13

  14. Runway Utilization with Runway 10C/28C East Flow West Flow approx 18% with approx 68% with optimal weather optimal weather Information from FAA EIS, Exhibit D-3 OMP/CAP Overview Federal Aviation April 4, 2014 Administration 14

  15. Runway Utilization Post - OMP East Flow West Flow approx 41% with approx 13% with optimal weather optimal weather Information from FAA EIS, Exhibit D-4 OMP/CAP Overview Federal Aviation April 4, 2014 Administration 15

  16. Chicago Airspace Project • Stage 1: East Enhancements Completed March 2007  Four eastbound departure routes ZMP ZAU • Stage 2: South • Stage-3: (Completion ZOB West Flow Enhancements Stage) West and North C90 WISMO ORDEA ORDWA ELX ORDEB NW2 ORDWB ADIME ORDWC ORDEC  Five southbound ORDWD MDWE MDWW ORDED GIJ Enhancements ORDSB ORDSD ORDSE ORDSA ORDSC departure routes  Four westbound GLANT NORDL KUCLA BLABE  High & Wide BULLR departure routes ZKC arrival procedures ZID  High & Wide arrival ZMP for ORD west flow ZAU procedures for ORD  Allows triple parallel arrival ZOB east flow East Flow for west flow at ORD  Enabling Infrastructure C90 WISMO ORDEA ORDWA ELX ORDEB NW2 ORDWB ADIME ORDWC ORDEC ORDWD MDWE ORDED GIJ  Allows triple parallel MDWW ORDSB ORDSD Completed ORDSE ORDSA ORDSC arrival east flow at ORD November 2008 GLANT NORDL KUCLA BLABE BULLR ZKC ZID Completed October 2013 OMP/CAP Overview Federal Aviation April 4, 2014 Administration 16 16

  17. OMP/CAP Overview Federal Aviation April 4, 2014 Administration 17 17

  18. CAP Implementation Departure Routes 4 Routes to 8 Transitions 2 Corridors • • Consistent Controller Vectored • • Predictable Route Variable • • User Selectable Linked to Destination Before CAP After CAP OMP/CAP Overview Federal Aviation April 4, 2014 Administration 18

  19. CAP Implementation Arrival Routes 2 Arrival Routes 1 Arrival Route • Full RNAV • Controller vectored • Estimated 1000 flight • mile daily reduction on Step d own altitudes arrival After CAP Before CAP OMP/CAP Overview Federal Aviation April 4, 2014 Administration 19

  20. 1993 2005 OMP/CAP Overview Federal Aviation April 4, 2014 Administration 20 20

  21. 2008 2013 OMP/CAP Overview Federal Aviation April 4, 2014 Administration 21 21

  22. OMP/CAP Overview Federal Aviation April 4, 2014 Administration 22 22
