Our new mast series We offer 3 different Mast Series and a Military Trailer.

Our new mast series FTM Series Our FTM Series are stiff, strong, reliable and built for tough conditions with heavy loads . The FTM Masts consists of Carbon-Composite Telescopic Tubes, operated by an Electro-Mechanically Screw-Driven system. • To be mounted in our against light to heavy armored, wheeled and tracked vehicles, stationary - and naval platforms for : • Surveillance, Communication, Protection, • Electronic Warfare, Optical/Thermal & Radio Systems, Radars, Anti-Drone Systems, • Overhead Weapon Systems FTM-SD4 carrying 250 Kg Mortar Detection Radars

Our new mast series FTM Series Technical Advantages of FTM Series Able to be used extracted while driving the vehicle. Also able to be used manually easily. Mast can stand stable on any height thanks to its patented locking mechanism. Exceptionally strong longitudinal stability for Optronics or directional Antennas Patented FTM Locking System

Our new mast series FTM Series Technical Advantages of FTM Series Head Load from 120 Kg up to 300 Kg, extended heights from 3m to 15m The mast can be operated with remote controller from inside & outside the vehicle Height is indicated on Control Panel or Remote Controller w/ display screen. Can, RS485, Ethernet, … connections. The software is provided to the Our New Control Panel on customer. MIL-STD Icing Test

Our new mast series FTM Series MILMAST FTM Series SD3 SD4 SD6 SD8 SD10 SD12 SD15 Extended Height m 3 4 6 8 10 12 15 Nested Height m 1.08 1.35 1.63 1.8 2.05 2.3 2.7 Maximum Payload Capacity kg 300 300 200 200 170 140 120 Rated Payload kg 250 250 180 180 150 120 90 Weight (including Control kg 110 120 180 200 220 240 270 Panel) Survival Wind Speed km/h 160 160 160 160 128 100 85 Deployment Wind Speed * km/h 80 80 120 120 96 80 64 Erection Time with Power ** sec 55 60 50 68 90 110 140 Land Slope *** deg 10 8 6 5 Voltage VDC 28 Foot Print cmxcm 44x26 52x32 *:Operational wind speed depends on the Headload Surface Area. Must be analysed. **: Erection and Descension time can be adjusted according to required time. ***: Land Slope Strength depends on the headload. Must be analysed. Fully Extended FTM-SD8

Our new mast series FHM Series Our Cable-Driven Mast Series . With FHM series we are focusing on a cheaper, simpler, cable telescopic masts to meet with the lighter requirements of the military & commercial needs. A true masterpiece of engineering: there is no overlapping of cables, no undesired movements. Easily operated electrically or manually with a drive arm. Special 2 point locking system. Consists of Aluminum Square Sections Ideal for Electronic Warfare, Surveillance Cameras, Antennas FHM-10 Successful during MIL-STD-810G Ice Test Method 521.3

Our new mast series FHM Series Product FHM-4 FHM-6 FHM-8 FHM-10 FHM-12 FHM-15 Type : Cable Driven Material : Aluminum Units Info Extended : 4000 6000 8000 10000 12000 15000 mm (+-10 mm) Nested : 1340 1580 2000 2100 2220 2400 mm (+-10 mm) Section : 4 5 5 6 7 8 --- Weight : 60 70 90 100 130 150 Kg (+-2,5 kg) (Mast & Control Panel Incl.) Payload Capacity ≤ 50 50 50 50 50 50 Kg Erection Time ≤ 20 35 50 60 75 100 Sec (28 Vdc Rated Voltage) Descent Time ≤ 20 35 50 60 75 100 Sec (28 Vdc Rated Voltage) Operational Wind 100 100 100 100 70 70 km/h (With 0,06m2 Wind load area) Speed ≤ Survival Wind Speed≤ 125 km/h (With 0,06m2 Wind load area) Maximum Swing ≤ 300 400 460 460 650 650 mm (With 0,06m2 Wind load area) FHM Shelter Mounted Maximum Torsion ≤ 2 Degrees(With 0,06m2 Wind load area) Slope ≤ 10 10 10 10 5 5 Degrees Analysis required necessary over 5° Rated Voltage : 28 Vdc Operating Voltage : 18-32 Vdc Maximum Current ≤ 100 A (During Erection of the System) Nominal Energy Cons ≤ 500 Watt Noise Level ≤ 70 dBa Control Panel Cover IP66

Our new mast series FOM Series The solution for tanks. The Mast Consists of compact Carbon Fiber Telescopic Sections Different nested and extracted heights, capable of lifting heavy headloads The FOM Series are developed for specific demands due to the limited space inside armored vehicles.

Our new mast series FOM Series FOM FOM FOM Product Features SD2,5 SD4 SD6 m 2,5 4 6 Extended Height Nested Height m 0,75 0,92 1,4 Maximum Payload Kg 150 150 150 Capacity Weight Kg 110 150 180 Survival Wind Speed (0,75m2 windy when Km/h 125 160 125 it is fully nested) Deployment Wind Km/h 70 110 110 (0,75m2 windy when Speed it is extended nested) Erection Time with Sec 60 100 130 Fully Loaded with Power 24V Land Slope Deg 10 10 10 24V, 70 km/h when fully extended Voltage VDC 28 28 28 Foot Print cmxcm 45x33 45x33 45x33

Our new mast series Military Trailer Its Aluminum Light Chassis is able to carry weights up to 2000kgs. 1 Axle Adaptable for Field Shelters, Hospitals and Kitchen Applications, Radars, Antennas, Masts, Anti-Drone Systems, Weapon-Systems

Our new mast series Military Standards : MIL-STD-810G, 416E, 1275D : MIL-STD-810G MIL-STD-461E Factory-Level Functional Test • Low Pressure Method 500.5 rev. E 1. Deflection Test • rev. F 2. Load Test High Temperature Method 501.5 • Low Temperature Method 502.5 CS101 3. Torsion Test • Solar Radiation Method 505.5 CS114 • Rain Method 506.5 CS115 • Humidity Method 507.5 CS116 • RS103 Fungus Method 508.6 • Salt Fog Method 509.5 CE102 • Sand and Dust Method 510.5 RE102 • Vibration Method 514.6 RS101 Shock Method 516.6 Ice Method 521.3

Our new mast series Integration & Logistics Support Our ILS team is there whenever you need. The ILS team serves our customers when any service, repair etc. needed. Also the ILS team gives instructions and trainings to the personal when required/ordered. Our Guarantee Policy As standard, we provide 2 year warranty for masts and 10 year warranty for parts. Guarantee for masts can be extended when ordered.
