A Calibration concept for SAR ADC for operation in LAr TPC Name: Yuan Mei Brookhaven National Laboratory Instrumentation Division ULITIMA 2018 yuanmei@bnl.gov Yuan Mei 9/11/2018 1 Motivation Design a 12-bit ADC running 2MS/s for DUNE


  1. A Calibration concept for SAR ADC for operation in LAr TPC Name: Yuan Mei Brookhaven National Laboratory Instrumentation Division ULITIMA 2018 yuanmei@bnl.gov Yuan Mei 9/11/2018 1

  2. Motivation ▪ Design a 12-bit ADC running 2MS/s for DUNE ▪ Risk mitigation for cold temperature @77K ▪ Errors from analog circuits should be overcome with digital calibration , transferring complexity from analog to digital domain 9/11/2018 Yuan Mei 2

  3. SAR ADC Architecture Comparator Vin Digital Outputs SAR Logic DAC • Bottom plate sampling method with synchronous timing • 12-bit resolution with 14 conversion-cycle ( 2-bit redundancy ) • Digital foreground calibration implemented 9/11/2018 Yuan Mei 3

  4. Static Error sources • Conversion accuracy is subject to the non-idealities of analog components, the main error source are DAC mismatch and comparator offset errors. • SAR only has one comparator, offset won’t affect linearity. • Bottom-plate sampling is performed, thus injected charge to the top- plate is independent of input signal and contribute a fixed offset • Auto-zeroing and chopper techniques are often used to eliminate comparator offset • Capacitor mismatch is fatal to ADC performance if not solved 9/11/2018 Yuan Mei 4

  5. Capacitor mismatch issues • 12-bit matching is needed in the capacitor array o Random mismatch: Gaussian distribution o Gradient mismatch: Location-dependent o Routing mismatch: Layout dependent • Unit-cap and common-centroid layout can fix gradient mismatch and routing mismatch • Random mismatch can be solved by using larger unit-capacitor [1] or using calibration method 9/11/2018 Yuan Mei 5

  6. Capacitor mismatch in DAC DAC mismatch limit ADC performance and calibration would improve ADC! 9/11/2018 Yuan Mei 6

  7. Id Idea of f Digital Calibration • Post-processing of codes o Relies on digital signal processing o No feedback to ADC and thus no stability issue o Doesn’t required complex analog circuit o Digital circuits scale in advanced process Correlation-based calibration is selected for this prototype 9/11/2018 Yuan Mei 7

  8. Correlation-based Calibration • Inject a small amount of analog signal that is uncorrelated with the input signal. Since it passes through the same path as DAC signal, it encounter same non-idealities and hence can detect the mismatch error • Using a statistical correlator (histogram method) or the least mean square ( LMS ) algorithm, the inject signal can be “correlated out” in the digital back-end and capacitor mismatch error are estimated in the process [2] 9/11/2018 Yuan Mei 8

  9. Im Implementation of f Algorithm W2 D2 Encode 2 d2 Vin SAR dout CORE a • a e[n] Each sampled analog signal will be digitized twice d1 D1 Encode 1 LMS Calibration 2 • d Decimal output codes d1 and d2 will create a error function W1 engine • Error function will provide information to infer the unknown weighting vector W LMS : W k [N+1] = W k [n] - µ*e[n]*d k [n] e [N] = d 1 [n] - d 2 [n] -2 d • Adaptive learning algorithm (LMS) to update weight coefficient in DAC in which error is gradually forced to zero Fig. Block diagram of the perturbation based digital calibration for SAR ADC [3] • Learning procedure converges, the mean of d1 and d2 will yield the correct digital output codes 9/11/2018 Yuan Mei 9

  10. Capacitor ratio with redundancy 9/11/2018 Yuan Mei 10

  11. Notes : Single-ended for simplicity Calibration circuit Implemented in differential Calibration Circuit VCM 10 1920 1024 544 288 144 80 40 24 8 2 1 12 6 2 MSB LSB Calibration Cap Vinput VCM Bootstrap_Switch Vref_pos Transmission-Gate Switch Vref_neg Transmission-Gate Switch Advantage Disadvantage Controlled by SAR • • Calibration circuit can be utilized in DAC Decrease input dynamic range Logic • Calibration circuit is stable at cold • Calibration control is simple 9/11/2018 Yuan Mei 11

  12. Timing Diagram 40 Cycles Clk Reset Sample Input regeneration Output1 D1 D2 D14 D13 D12 Output2 D1b D2b D14b Timing diagram of the proposed calibration method • One complete conversion consist of a 5 clock-cycle sampling phase and two 14 clock-cycle conversion phases; • Besides, 1 clock-cycle is reserve for reset and 6 clock-cycle is for input regeneration. 9/11/2018 Yuan Mei 12

  13. Simulations with digital calibration • Simulations are done in Cadence @ 77K temperature • All blocks are implemented and simulated in transistor level • Unit capacitor is MIM cap provided by foundry (about 10 fF) • DAC mismatch errors are the major error source 9/11/2018 Yuan Mei 13

  14. Capacitor mismatch calibration verification • Set random mismatch on capacitor weights • Simulate to see if calibration can find the optimal weight and improve the performance • Other mismatch is excluded from this verfication 9/11/2018 Yuan Mei 14

  15. Capacitor mismatch calibration Simulated with 2^14 (16,384) samples, weights are converged around 10,000 samples Y-axis: Capacitor weight X-axis: # of samples 9/11/2018 Yuan Mei 15

  16. Capacitor mismatch calibration Simulated with 2^14 (16,384) samples, weights are converged around 10,000 samples Y-axis: Capacitor weight X-axis: # of samples 9/11/2018 Yuan Mei 16

  17. Capacitor mismatch calibration With calibration, all the weights in the DAC are updated Y-axis: Capacitor weight X-axis: # of samples 9/11/2018 Yuan Mei 17

  18. Dynamic test FFT points: 2^14 Without Calibration ENOB = 8.3 bits With Calibration ENOB= 11.2 bits • ENOB is improved • Dynamic range also improved 9/11/2018 Yuan Mei 18

  19. Dynamic test FFT points: 2^17 Without Calibration ENOB = 8.3 bits With Calibration ENOB= 11.9 bits With more samples : • ENOB is further improved from 11.2bits to 11.9bits • Dynamic range also improved from 69.1 dB to 73.6dB 9/11/2018 Yuan Mei 19

  20. Static test Sample points: 2^14 A lot missing codes! NO missing code! Without Calibration Without Calibration • Linearity is improved with the digital calibration 9/11/2018 Yuan Mei 20

  21. Static test With samples 16,384 (2^14) With samples 131,072 (2^17) • Linearity is further improved with more samples 9/11/2018 Yuan Mei 21

  22. Floorplan Digital Domain Analog Domain N-DAC DC Switches Vin- Bootstrap Switch Dummy Dummy Dummy Pre Dummy Dummy amp VCM N-DAC Switch Nomal Calibration Clock Generator Mode Mode Data Formatter Dummy Dummy Dummy Comparator SAR SAR +LVDS I/O Dummy Dummy Logic Logic VCM Dummy Dummy P-DAC Switch Pre amp Dummy Dummy Dummy Vin+ Bootstrap Switch P-DAC DC Switches Floorplan of SAR ADC prototype 9/11/2018 Yuan Mei 22

  23. Die Photo Die photo of SAR ADC prototype 9/11/2018 Yuan Mei 23

  24. Measurement • Chip came back in Mid-July and measurement will be done in October 9/11/2018 Yuan Mei 24

  25. Power consumption @77K(Simulation by PEX) Block Name Power consumption 2MS/s Digital 240 µw Analog 280 µW Total 520 µW 9/11/2018 Yuan Mei 25

  26. Acknowledgement • My colleagues : Gabriella Carini, Huchen Chen, Mietek Dabrowski, Shaorui Li , and Emerson Vernon • Fermi lab collaborators and their cold model for TSMC 65nm at 77K • DUNE and DoE for support of this work 9/11/2018 Yuan Mei 26

  27. Reference [1] Yi-long Yu, ADI talk, A 12 bit 100MS/s two step hybrid ADC in 40nm CMOS with statistical calibration [2] Ahmed M. A. Ali. 2016. High Speed Data Converters . Institution of Engineering and Technology. [3] W. Liu, P. Huang and Y. Chiu , "A 12-bit, 45-MS/s, 3-mW Redundant Successive-Approximation-Register Analog-to-Digital Converter With Digital Calibration," in IEEE J. of Solid-State Circuits, vol. 46, no. 11, pp. 2661-2672, Nov. 2011 . 9/11/2018 Yuan Mei 27

  28. Q & A Thank you for your attention. 9/11/2018 Yuan Mei 28

  29. Backup slides LMS : W k [N+1] = W k [n] - µ*e[n]*d k [n] e [N] = d 1 [n] - d 2 [n] -2 d W i represents the respective bit weight. µ i is the step size of the update equation and is scaled according to the bit. e[N] is the total error of the Nth step. d N are the raw ADC output; Δ d are digitized offset of the inserting analog offset Δ a 9/11/2018 Yuan Mei 29

  30. Convergence of f Error 9/11/2018 30
