ACR 3413 BASIC STRUCTURAL ENGINEERING 3 Lecture 4 Univers rsit ity y Putra a Malaysia ysia - Communication - Talk to Architect, M&E Engineer and Other Consultants of their Requirements Item Verti tical Load {V} Horizon zonta tal


  1. ACR 3413 BASIC STRUCTURAL ENGINEERING 3 Lecture 4 Univers rsit ity y Putra a Malaysia ysia

  2. - Communication - Talk to Architect, M&E Engineer and Other Consultants of their Requirements Item Verti tical Load {V} Horizon zonta tal Load {H} Conceptual Design   Loading X  Scheme Design X  Analysis X  Design TODAY’S LECTURE X - Quality Control (QA) (V & H) - Do It All Again and Again 2

  3. Shorter Span, l x = 6m; Longer Span, l y = 8m; Floor to Floor Height = 3m; 10 Floors Slab Thk = 250mm Screeding and Tiling = 50mm; Client Specified Future SDL Allowance = 2.5kPa Services = Centralised Air-Conditioning Ducting Etc Architectural = Ceiling and Lighting Architectural = 150mm Internal Brickwall 25m Long Per Panel 3 Architectural = External Cladding 250mm Stone

  4. Span 1 Panel 1 LL: African Elephant = 5tonnes = 50kN  50kN/(6mx8m) = 1.1kPa Span 1 Panel 2 LL: Car Park = 3 cars x 2tonnes = 60kN  60kN/(6mx8m) = 1.25kPa But UBBL Says 2.5kPa Span 2 Panel 1 LL: Café With Fixed Seating = UBBL Says 4.0kPa Span 2 Panel 2 LL: Café Without Fixed Seating = UBBL Says 5.0kPa Span 3 Panel 1 LL: Library = UBBL Says 2.4kPa x Height Say 3m = 7.2kPa Span 3 Panel 2 LL: Residential Space = UBBL Says 1.5kPa 4

  5. All Spans All Panels DL: Slab Thk Given as 250mm = 0.25m x 24kN/m 3 = 6.0kPa All Spans All Panels DL: Beam Say 400mm x 900mm = 0.4m x 0.9m x 24kN/m 3 / 6m = 1.5kPa All Spans All Panels DL: Total = 6.0+1.5 = 7.5kPa 5

  6. All Spans All Panels SDL: Client Specified Future Allowance = 2.5kPa All Spans All Panels SDL: Screeding and Tiling Given as 50mm = 0.05m x 24kN/m 3 = 1.2kPa All Spans All Panels SDL: Centralised Air-Conditioning Ducting Given = 0.5kPa All Spans All Panels SDL: Ceiling and Lighting = 0.15kPa All Spans All Panels SDL: Brickwork Given As 25m Long Per Panel = 25m Long x 3m High x 19kN/m 3 x 0.150m = 215kN  215kN/(6mx8m) = 4.5kPa 6 All Spans All Panels SDL: Total = 2.5+1.2+0.5+0.15+4.5 = 8.85kPa

  7. SLS: 1.0DL + 1.0SDL + 1.0LL ULS: 1.4DL + 1.4SDL + 1.6LL 7

  8. Span 1 Panel 1 ULS : 1.4DL + 1.4SDL + 1.6LL = 1.4 x 7.5kPa + 1.4 x 8.85kPa + 1.6 x 1.1kPa = 25kPa Span 1 Panel 2 ULS : 1.4DL + 1.4SDL + 1.6LL = 1.4 x 7.5kPa + 1.4 x 8.85kPa + 1.6 x 2.5kPa = 27kPa Span 2 Panel 1 ULS : 1.4DL + 1.4SDL + 1.6LL = 1.4 x 7.5kPa + 1.4 x 8.85kPa + 1.6 x 4.0kPa = 30kPa Span 2 Panel 2 ULS : 1.4DL + 1.4SDL + 1.6LL = 1.4 x 7.5kPa + 1.4 x 8.85kPa + 1.6 x 5.0kPa = 31kPa Span 3 Panel 1 ULS : 1.4DL + 1.4SDL + 1.6LL = 1.4 x 7.5kPa + 1.4 x 8.85kPa + 1.6 x 7.2kPa = 35kPa Span 3 Panel 2 ULS : 1.4DL + 1.4SDL + 1.6LL = 1.4 x 7.5kPa + 1.4 x 8.85kPa + 1.6 x 1.5kPa = 26kPa 8

  9. Span 1 Panel 1 ULS Tributary Line Loading : w ULS = 25kPa x 6m/2 = 75kN/m Span 1 Panel 2 ULS Tributary Line Loading : w ULS = 27kPa x 6m/2 = 81kN/m Span 2 Panel 1 ULS Tributary Line Loading : w ULS = 30kPa x 6m/2 = 90kN/m Span 2 Panel 2 ULS Tributary Line Loading : w ULS = 31kPa x 6m/2 = 93kN/m Span 3 Panel 1 ULS Tributary Line Loading : w ULS = 35kPa x 6m/2 = 105kN/m Span 3 Panel 2 ULS Tributary Line Loading : w ULS = 26kPa x 6m/2 = 78kN/m 9

  10. Sum of Span 1 ULS Tributary Line Loading : Sw ULS,1 = 75kN/m + 81kN/m = 156kN/m Sum of Span 2 ULS Tributary Line Loading : Sw ULS,2 = 90kN/m + 93kN/m = 183kN/m Sum of Span 3 ULS Tributary Line Loading : Sw ULS,3 = 105kN/m + 78kN/m = 183kN/m 10

  11. Analysis Methods Available Statically y Determi minate te Structu tures 1. Use Statics – Practical to do by Hand 2. Use Tabulated Coefficients – Practical to do by hand 3. Use Stiffness Method – Not practical to do by hand, must use computers Statically y Indete etermin minate te Structu tures 1. Cannot Use Statics but Instead Use Moment Distribution Method / Moment Area Method / Flexibility Method – Practical to do by hand but superceded in practice by the stiffness method !! 2. Use Tabulated Coefficients – Practical to do by hand 3. Use Stiffness Method – Not practical to do by hand, must use computers 11

  12. 12

  13. 13

  14. 14

  15. 15

  16. ULS Bending Moment (Hogging), M ULS : Sw ULS,3 .L 2 /12 = 183kN/m x 8m 2 /12 = 1000kNm ULS Bending Moment (Sagging), M ULS : Sw ULS,3 .L 2 /24 = 183kN/m x 8m 2 /24 = 500kNm ULS Shear Force, V ULS : Sw ULS,3 .L/2 = 183kN/m x 8m/2 = 750kN ULS Axial Force, N ULS : No. of Floors x Sw ULS,3 .L/2 x 2 = 10 Floors x 750kN x 2 = 15000kN 16

  17. 17

  18. 18

  19. 19

  20. 20

  21. 21

  22. 22

  23. 23

  24. 24

  25. 25

  26. 26

  27. 27

  28. 28

  29. 29

  30. 30

  31. Definitions Scheme Design 1. Slab – Horizontal flat member supporting loads 1. RC Two-Way Slab With RC Beams 2. Beam - Horizontal member supporting slabs 2. RC One-Way Slab With RC Beams 3. Column / Wall – Vertical member supporting 3. RC Flat Slab beams and/or slabs 4. PT Flat Slab 4. Foundations – Vertical member supporting 5. ST Composite Slab With ST Beams columns Analys ysis Conc nceptua ual Design 1. ULS and SLS loading combinations 1. Discretization of Physical Model - Mechanism / 2. Structural analysis - mathematics Determinate / Indeterminate Structures 3. Force – internal distribution of effects bending moment (kNm) • Loading ng axial (kN) • shear (kN) • 1. Load – externally applied load torsion (kNm) • mass - kg / tonnes • 4. Deflections – externally displacements load – kN • pressure - kPa • Design 2. Dead load - externally applied v. DL (self- weight) 1. ULS Capacity 3. Superimposed dead load - externally applied v. - Stress SDL normal (direct) stress • 4. Live load - externally applied v. LL shear stress • 5. NHL load - externally applied h. NHL 2. SLS Capacity 6. Wind load - externally applied h. WL 7. EQ load - externally applied h. EQ 31
