ABOUT SISMALAB The SISMALAB Srl, based in Crispiano (Italy), is a - PowerPoint PPT Presentation

Nov 26, 2023 •178 likes •414 views

ABOUT SISMALAB The SISMALAB Srl, based in Crispiano (Italy), is a service company specialized in anti-seismic experimental engineering solutions and tests, part of PNEOILGROUP SpA . The SISMALAB Srl was founded in 2009 with the needs of the

  2. ABOUT SISMALAB The SISMALAB Srl, based in Crispiano (Italy), is a service company specialized in anti-seismic experimental engineering solutions and tests, part of PNEOILGROUP SpA . The SISMALAB Srl was founded in 2009 with the needs of the Italian Government and its Department of Civil Protection, to test in site the new civil constructions after the tragic earthquake of L’Aquila (Italy), in terms of dynamic response of the anti- seismic device installed (n.7368 pendulum isolators) and the entire structures, for a project named C.A.S.E.

  3. THE PLANT Hydraulic Plant Service Pressure 300 bar, Hydraulic accumulators system Flow Rate 6000 lt/min Service Pressure 300 bar, Accumulation Capacity 3000 lt.

  4. ORGANIZATION CHART GENERAL MANAGER (Martina Caramia) QSA MANAGER (L. Luccarelli) ADMINISTRATIVE DEPT TECHNICAL (Tiziana Caramia) DIRECTOR LABORATORY (Ciro Caramia) TESTS AND ELABORATION DATA (*) (G. Pellegrino) (*) TYPES OF DEVICES: - ISOLATORS: Elastomeric / Curved and Flat Surface Sliders - FVD Fluid Viscous Dampers - DDD Displacement Dependent Devices - STU Shock Transmission Unit

  5. SISMALAB CERTIFICATIONS The SISMALAB S.r.l. conforms to the Quality Management System standard UNI EN ISO 9001:2008 . This certicate is valid for the scope of research and development, execution of tests designed to test homologation and acceptance of products for structural civil engineering scope, particularly for companies operating in the seismic sector. The accurate quality and technical management permits SISMALAB S.r.l. to cooperate costantly with european certification bodies, such as: • LPM – POLYTECHNIC OF MILAN • ICECON - BUCAREST • INCERTRANS - BUCAREST • MPA – STOCCARDA

  6. Testing Machine – OLEO100 TEST ON STU / FVD / DDD (*) • MAXIMUM HORIZONTAL LOAD F= ± 1400 kN, V=0,8m/sec (limitations can be modified changing the actuator) • MAXIMUM LENGHT AVAILABLE TO INSTALL THE DEVICE AND THE ACTUATOR L= 4039mm (*)TYPES OF DEVICES: - FVD Fluid Viscous Dampers - DDD Displacement Dependent Devices - STU Shock Transmission Unit

  7. Testing Machine - ISOL1000 TEST ON SEISMIC ISOLATORS (*) • MAXIMUM VERTICAL LOAD F = 10.000 kN • MAXIMUM HORIZONTAL LOAD F = 1350 kN, V=0,9mm/sec • MAXIMUM STROKE dS = ± 500 mm • DEVICES CLEARANCE a * b * h = 1000 * 1000 * 1000mm 2 DEVICES CAN BE TESTED SIMULTANEOUSLY (*)TYPES OF DEVICES: - Elastomeric - Curved and Flat Surface Sliders

  8. Testing Machine – OLEO650 TEST ON STU / FVD / DDD (*) • MAXIMUM HORIZONTAL LOAD F= ± 6500 kN, V=80mm/sec • MAXIMUM HORIZONTAL LOAD F= ± 2500 kN, V=0,8m/sec (limitations can be modified changing the actuator) • MAXIMUM LENGHT AVAILABLE TO INSTALL THE DEVICES AND THE ACTUATOR L= 4159mm (*)TYPES OF DEVICES: - FVD Fluid Viscous Dampers - DDD Displacement Dependent Devices - STU Shock Transmission Unit

  9. Testing Machine – ISOL2500 Engineering started at the end of March 2016 Start of assembly activities July 19 th 2016 Construction Completion at the end of July 2016

  10. Testing Machine – ISOL2500 TEST ON SEISMIC ISOLATORS (*) • MAXIMUM VERTICAL LOAD F = 22 MN • MAXIMUM HORIZONTAL LOAD F = 3 MN • MAXIMUM STROKE dS = ± 750 mm • MAX DEVICES DIMENSION 1,5m X 1,5 m X 0,7 m • MAX HORIZONTAL VELOCITY 1,2 m/sec (*)TYPES OF DEVICES: - Elastomeric - Curved and Flat Surface Sliders

  11. ATTREZZATURE DI SUPPORTO REFRIGERATING UNIT FOR DEVICES • MAXIMUM TEMPERATURE + 50 ° C • MINIMUM TEMPERATURE -50 ° C TEST BENCH – SEALS WEAR TEST STRESS TEST TO EVALUATE THE DURATION OF ACTUATOR SEALS MAXIMUM STROKE +/- 110 mm MINIMUM STROKE +/- 50 mm

  12. OTHER EQUIPMENTS AND MACHINE N° 1 Electronic control and acquisition data system N° 1 video and audio acquisition system N° 2 structures to test mechanical characteristic of steel funes and bars

  13. TYPICAL REPORT - FVD (FLUID VISCOUS DUMPER)

  14. TYPICAL REPORT - FVD (FLUID VISCOUS DUMPER)

  15. TYPICAL REPORT - FVD (FLUID VISCOUS DUMPER)

  16. TYPICAL REPORT - ELASTOMERIC ISOLATOR

  17. TYPICAL REPORT - ELASTOMERIC ISOLATOR

  18. TYPICAL REPORT- ELASTOMERIC ISOLATOR

  19. TESTS PERFORMED 2010 – OCT 2017 TESTS PERFORMED PER YEAR 900 830 800 700 640 600 + 57% 500 407 400 + 46% 300 278 + 59% 200 175 100 34 56 5 0 2010 2011 2012 2013 2014 2015 2016 oct 2017 Total number of test up to oct2017 n. 2425

  20. TESTS PERFORMED 2010- OCT 2017 900 DEVICES (2010- oct 2017) PENDULUM 800 700 DEVICES (2010- oct 2017) OTHERS 600 DEVICES (2010- oct 2017) ISOLATOR 500 DEVICES (2010- oct 2017) SPHERICAL BEARING 400 DEVICES (2010- oct 2017) DDD 300 DEVICES (2010- oct 2017) STU 200 DEVICES (2010- oct 2017) FVD 100 0 2010 2011 2012 2013 2014 2015 2016 oct 2017 DEVICES (2010- oct 2017) TESTS YEARS SPHERICAL FVD STU DDD ISOLATOR OTHERS PENDULUM PERFORMED BEARING 4 0 0 0 1 0 0 5 2010 2011 1 1 14 0 18 0 0 34 0 1 0 0 55 0 0 56 2012 2013 2 5 1 0 167 0 0 175 22 16 8 23 209 0 0 278 2014 188 28 15 30 142 2 2 407 2015 2016 71 35 6 71 457 0 0 640 27 14 13 23 710 0 43 830 oct 2017 2425 TOTAL n.

  21. SISMALAB WORLDWIDE CLIENTS ASIA - CHINA - RUSSIA - TAIWAN - SOUTH KOREA OTHERS EUROPE - NEW ZELAND - ITALY - MEXICO - POLAND - ROMANIA - USA - SWITZERLAND - CANADA - SPAIN - SOUTH AMERICA -- TURKEY

  22. OUR CLIENTS MAIN CLIENTS  AGOM INTERNATIONAL S.R.L.  ALGA S.p.A. - FPC ITALIA S.p.A.  ANAS S.p.A.  TANGENZIALE DI NAPOLI S.p.A.  ATLANTE S.R.L.  C.M.M. F.lli RIZZI  DE.LA.BE.CH. COSTRUZIONI S.R.L.  INDUSTRIE ILPEA S.p.A.  ITALGUM S.R.L.  MAGEBA  RLS & DIS TURKEY DISTRIBUTOR EM-KE INSAAT TAAH. SAN. VE TIC. LTD.  ROBINSON SEISMIC LTD  S.C. ROMCONSTRUCT HOLDING GRUP S.A.  SOMMA S.R.L.  TAEMYUNG ENGINEERING INC.  TEC GROUP S.R.L.  TENSACCIAI S.R.L.  VSL Polska Sp. Z O.o.
