XiaMen city plus Innovation Never Forget Why We Started, Focus on - PowerPoint PPT Presentation

XiaMen city plus Innovation Never Forget Why We Started, Focus on Innovation and Move Forward Founder /CEO Mr. Li JinHua Graduated from The University of Sheffield in UK , Major in Electronic Information Control and System Engineer XMinnov IOT


  1. XiaMen city plus Innovation Never Forget Why We Started, Focus on Innovation and Move Forward

  2. Founder /CEO Mr. Li JinHua Graduated from The University of Sheffield in UK , Major in Electronic Information Control and System Engineer

  3. XMinnov IOT Industrial Park 2013 2007 2017 2007 2006 Find Id Div. Power Sensor Div. Supply 2018 FPC/PCB Unit Material 2012 2017 Division Division Mould & Injection Div. RFID Division Wottop Div. FPC,LED High & LED Temperature Backlight, 2018 Resistant, EMC Solar NFC/RFID finished Ferrite, Panel Location products such as Adhesive/Glue Material security tag & Service for Wire Cable RFID/NFC pocket retailers Div. reader

  4. Stock Code: 430525

  5. Summary Worker: 800+ / Engineers: 150 + / Sales Team: 50+ Current Factory Area: 2400*5floors*3building +12000(old factory)= 48000 Sqm Current Office Area: 2400Sqm*6floors = 14400 Sqm

  6. General Development Workflow Simulation Measure Requirement & Verify Analyze & Design Sample Preparation Sealed Sample & SPEC Releasing .

  7. RF Anechoic Chamber x2 sets

  8. Professional Team Digital Circuit Design Engineer 5+  Analog Circuit Design Engineer 28+  Layout Engineer 15+  RF Design Engineer 14+  Firmware Engineer 5+  PC/Android/iOS Software Engineer 8+  Equipment/Device Engineer 4+  Molding Engineer 11+  Structure Design Engineer 4+  Process Optimization Engineer 4+  Tooling Engineer 6+  Qualifying/Test Engineer 10+  Maintenance Engineer 15+ 

  9. In House Complete Production Line

  10. PCB/FPC Board Production Exposure Technology – Sheet by sheet/ Roll To Roll Pattern Film Conduct Raw Material Roll to Roll Antenna Etching Photosensitive dry film Exposure

  11. SMT Production Chip/IC assembly Reflow Soldering Transfer Screen Printing

  12. Roll to Roll Production Roll to roll Lamination Reinforce Inserting Machine Flip Chip Assembly

  13. Mould and injection Dept.

  14. Assembly Production Line Wave soldering/ 波峰焊 Assembly lines/ 流水线

  15. Most Advantage  In-house One Stop Production  Short Lead Time & Delivery Time In 2 hours  Fast Response To The Customization  Flexible Adjustment On Each Equipment  Different Antenna Solution  Customer Quality Control & Encoding Solution

  16. Advantage 1: Different options for your needs • Copper • Aluminum • Printing • Etching • Coating • Flip-chip • COB • SMT • Lamination • Insertion • Die-Cutting • Customized QC flow

  17. Advantage 2: Patented Adhesive Strong Adhesive with good performance in high temperature. 木材制品 Break On Removal design. Heating will generate more Viscous High Temperature Glue/Tape

  18. Advantage 3: Patented Anti-Tamper/Check on Open - Rich Experience in Anti- Tamper design - NXP NTAG213TT - SiliconCraft 43NT/43N1F - ST - Ustar ISO15693 TT - Fudan 21TT - Physical Damage to Label - Trigger Tamper Event www.rfidtagworld.com

  19. Advantage 4: Customized Encoding/Pre-Program • Serial No/1D/2D Bar-code • Pre-Program/Personalization • Association & Related Electronic Report www.rfidtagworld.com

  20. Advantage 5: High Performance Circuit Accuracy Patented Exposure Technology VS Printing Technology under 40 times microscope Smooth line Neat regular shape Irregular shapes

  21. Advantage 6: Extendable Facility & Capacity • All new expansion for the new equipment will take less than 2 weeks • All equipment & production line accept customization & fast produce with MOQ<10,000pcs • RFID Tag/Antenna Production Capacity 0.5m*2pcs*5m*(60m*24h)=7200sqm ≈ 7200*500pcs/sqm=3.6mil tag /day • 2000 square meters FPC/day (250/500mm sheet by sheet) Wave soldering/ 波峰焊 5line * 11hours * 4000pcs = 200,000pcs/day • • Flip-chip Capacity = 8units * 5000 * 24hours = 960,000 pcs/day • Converting/Lamination Capacity 0.25m*10m*(60m*24h)*10unit=36,000sqm/ *500pcs/sqm ≈ 18mil tags/day • Die-cut Capacity 5000*5columns*24h *10units = 6mil tags /day • Encoding/QC controller 50unit*5000*24h = 6mil tags/day

  22. What is our target development? Focus On Security & Customization

  23. Electronic Material

  24. High Precision FPC/PCB Capacitive touch screen Capacitive touch screen LED Light PCB RF antenna Medical Device Board COF Module Board

  25. Customized PSU

  26. Portable RFID Reader

  27. Application Case

  28. Customized RFID/NFC Tag

  29. Customized QC & Personalization Device

  30. Wine Promotion Cabinet

  31. Assets RTLS & Consumer Analysis

  32. Hotel Check In/Out Device

  33. Focusing On • Customization • Anti-Counterfeiting • Security • Brand Protection

  34. Thank You!
