  1. Week 9 - Friday

  2.  What did we talk about last time?  Graph basics  Graph ADT  Adjacency matrix representation

  3.  Wednesdays at 5 p.m. in The Point 113  Saturdays at noon in The Point 113

  4.  An adjacency matrix wastes a lot of space if the graph is not very dense  An alternative is an adjacency list  The form of an adjacency list is an array of length n where the i th element is a pointer to a linked list (or dynamically allocated array) of the nodes adjacent to node i  This is the approach the book focuses on, since most graphs are not dense

  5. 1 0 1 0 0 2 3 4 1 2 1 3 2 1 2 4 3 3 4 1 3 4

  6. 1 0 1 0 2 3 1 2 1 3 2 4 3 3 4 3 4

  7. It’s a trick! 1 Some other steps must be 0 taken to represent a 2 multigraph with an adjacency list. 3 Each node in the linked list must contain additional 4 information.

  8. Again, we need extra information in the lists. 1 5 0 5 1 2 0 2 2 0 5 3 6 4 9 1 2 1 2 3 3 2 6 9 3 3 1 6 2 3 4 4 3 4 1 9 3 4 4 4

  9.  Similar to a preorder traversal in a tree  We want to visit every node once, going down as far as possible before backing up  Issues:  No guarantee about ordering like a BST  Loops are a problem, how do we keep from repeating nodes?

  10. We might start at an arbitrary 1 1 1 1 1 1 location. 0 0 0 0 0 0 What’s a DFS look 2 2 2 2 2 2 like that starts at node 4? 3 3 3 3 3 3 4, 1, 0, 2, 3 4 4 4 4 4 4

  11.  We use pseudocode a lot when describing graph operations, since the details depend on implementation choice  Nodes all need some extra information, call it number  Startup Set the number of all nodes to 0 1. Pick an arbitrary node u and run DFS( u , 1 ) 2.  DFS( node v, int i ) Set number( v ) = i ++ 1. Do whatever other processing for v is necessary 2. For each node u adjacent to v 3. If number( u ) is 0 DFS( u , i )

  12.  What if we wanted to find paths from node s to other nodes?  We run DFS starting at s with an extra array of length | V | called edges  When we move from node u to node v, we set edges [ v ] = u  Then, to find a path from s to t , we backtrack by looking at edges [ t ] and working backwards until we get to s  This approach will find a path if there is one, but it may not be the shortest path

  13. B B C C Edge Node To find paths from B From to other nodes, we A B A A first do a DFS from B B E E C D D D D A H H E C G G F G I I F F G E H G J J I Working backwards, a path from F to B is: F G E C D A B J Thus, a path from B to F is: B A D C E G F

  14.  Similar to a level order traversal in a tree  We want to visit every node once, visiting all the children of one node before moving on to their children  Similar issues to a DFS

  15. We might start at an arbitrary 1 1 1 1 1 1 location. 0 0 0 0 0 0 What’s a BFS look 2 2 2 2 2 2 like that starts at node 4? 3 3 3 3 3 3 4, 1, 3, 0, 2 4 4 4 4 4 4

  16.  More pseudocode!  Nodes all need some extra information, call it number  BFS(node v ) Set the number of all nodes to 0 1. Create queue q 2. Set i = 1 3. number( v ) = i ++ 4. q .enqueue( v ) 5. While q is not empty 6. a. v = q .dequeue() b. Do whatever other processing for v is necessary c. For each node u adjacent to v If number( u ) is 0 Set number( u ) = i ++ q .enqueue( u )

  17.  Let V be the set of vertices and E be the set of edges  Thus, | V | is the number of vertices and | E | is the number of edges  If you are using adjacency lists then:  DFS is: ▪ O(| V | + | E |)  BFS is: ▪ O(| V | + | E |)  If you are using an adjacency matrix then:  DFS is: ▪ O(| V | 2 )  BFS is: ▪ O(| V | 2 )

  18.  We have spent a huge amount of time on trees in this class  Trees have many useful properties  What is the only difference between a tree and a graph?  Cycles  Well, technically a tree is also connected

  19.  Is a graph a tree?  It might be hard to tell  We need to come up with an algorithm for detecting any cycles within the possible tree  What can we use?  Depth First Search!

  20.  Nodes all need some extra information, call it number  Startup Set the number of all nodes to 0 1. Pick an arbitrary node u and run Detect( u , 1 ) 2.  Detect( node v, int i ) Set number( v ) = i ++ 1. For each node u adjacent to v 2. If number( u ) is 0 Detect( u , i ) Else Print “Cycle found!”

  21.  Even graphs with unconnected components can have cycles  To be sure that there are no cycles, we need to run the algorithm on every starting node that hasn’t been visited yet

  22.  A directed acyclic graph (DAG) is a directed graph without cycles in it  Well, obviously  These can be used to represent dependencies between tasks  An edge flows from the task that must be completed first to a task that must come after  This is a good model for course sequencing  Especially during advising  A cycle in such a graph would mean there was a circular dependency  By running topological sort, we discover if a directed graph has a cycle, as a side benefit

  23.  A topological sort gives an ordering of the tasks such that all tasks are completed in dependency ordering  In other words, no task is attempted before its prerequisite tasks have been done  There are usually multiple legal topological sorts for a given DAG

  24.  Give a topological sort for the following DAG: A F I C K G D J E H  A F I C G K D J E H

  25.  Create list L  Add all nodes with no incoming edges into set S  While S is not empty  Remove a node u from S  Add u to L  For each node v with an edge e from u to v ▪ Remove edge e from the graph ▪ If v has no other incoming edges, add v to S  If the graph still has edges  Print "Error! Graph has a cycle"  Otherwise  Return L

  26.  Connectivity  Minimum spanning trees  Shortest paths  Matching on bipartite graphs  Stable marriage

  27.  Work on Project 3  Finish Assignment 4  Due tonight!  Read 4.3 and 4.4
