FORGING HEAT TREATMENTS MACHINING ASSEMBLIES Friulforgia is a manufacturer of middle-sized open die forgings. We can forge steel components of any shape and with several applications. Thanks to the wide range of TTN Group services and our advanced equipment, we are able to provide a single and complete solution to most of our customer’s needs. # 2 www.friulforgia.it

FORGING RANGE Weight: 500 - 30.000 Kg Length: up to 14 m Diameter: up to 2.000 mm MATERIALS Carbon steel Low alloyed steel High alloyed steel Stainless steel Duplex Super Duplex Tool steel # 3 www.friulforgia.it

HEAT TREATMENTS FRIULFORGIA Normalizing Quenching and Tempering Annealing TTN GROUP Vertical heat treatments Vacuum heat treatments Carburizing Gas and Plasma Nitriding Induction Hardening Case Hardening Salt and Polymer Quenching # 4 www.friulforgia.it

MACHINING HORIZONTAL LATHE TURNING: Dia. up to 2.500 mm Length up to 18 m VERTICAL LATHE TURNING: Dia. up to 2.700 mm Height up to 2.300 mm MILLING Max. 2000 x 2500 x 8000 mm DEEP BORE DRILLING + HONING Dia. up to 900 mm Length up to 17 m # 5 www.friulforgia.it

ASSEMBLIES BARRELS CASINGS WELDED SHAFTS SHRINK FITTING SPECIAL PRODUCTS # 6 www.friulforgia.it

TYPICAL PRODUCTS PROPELLER SHAFTS INTERMEDIATE SHAFTS STEERING PIPES HUBS TURBINE SHAFTS PISTON RODS PISTON CARRIERS SERVOCYLINDERS SOCKETS NOZZLES AND FLANGES BARRELS SHELLS CASINGS COVERS ROTOR SHAFTS INNER CASINGS 7 www.friulforgia.it

TYPICAL PRODUCTS PRESS PLATES SEGMENTS MANDRELS EXCENTRIC SHAFTS SECONDARY SHAFT PINIONS PRIMARY SHAFTS GEARWHEELS KINGPOSTS AND PILLARS DRUMS SEMI-RINGS BOGIE WHEELS ROLLS SPIGOTS JOURNALS SADDLES / HOUSINGS 8 www.friulforgia.it

CERTIFICATES ISO 9001 ISO 14001 OHSAS 18001 DNV-GL TÜV BV LLOYD’S R. ABS RINA KOREAN R. # 9 www.friulforgia.it

Friulforgia UDINE Open die forging Heat treatments MILAN Machining VENICE Assemblies TTN Piemonte TTN Nerviano TTN Vittuone TTC CRT TTN Veneta Heat treatments Thermochemical Machining Heat treatments PVD Heat treatments heat treatments Deep bore drilling Surface coating Heat treatments Friulforgia S.r.l. Loc. Pannellia 55 33039 Sedegliano Italy Tel: +39 0432 91 86 1 Fax: +39 0432 91 86 30 Email: info@friulforgia.it WEB: www.friulforgia.it # 10 www.friulforgia.it
