View Invalidation for Dynamic Content Caching in Multitiered Architectures

• K. Selçuk Candan

Divyakant Agrawal Wen-Syan Li Oliver Po Wang-Pin Hsiung NEC USA, C&C Research Labs. CA USA

12/3/2002 Presented by K. Selçuk Candan

Multi-tiered architectures….

• Clients do not access the

database directly.

E F

• Instead, they use applications

–

which invoke DBMSs

• r they access result caches

–

proxy cache (A)

–

front-end cache (B)

–

edge cache (C)

–

user side cache (D)

–

middle-tier caches (E)

12/3/2002 Presented by K. Selçuk Candan

Problem…..

Users

12/3/2002 Presented by K. Selçuk Candan

Result caches and consistency

Various

–

view materialization and update management techniques

have been proposed to deal with updates to the underlying data.

These techniques guarantee that cached results are always

–

consistent

with the underlying data.

12/3/2002 Presented by K. Selçuk Candan

Strong consistency requirements..

Data Warehouse Data Data

12/3/2002 Presented by K. Selçuk Candan

Strong consistency requirements..

Data Warehouse Data Data

12/3/2002 Presented by K. Selçuk Candan

Strong consistency requirements..

Data Warehouse Data Data Queries

12/3/2002 Presented by K. Selçuk Candan

Result Caches and consistency

Various

–

view materialization and update management techniques

have been proposed to deal with updates to the underlying data.

These techniques guarantee that cached results are always

–

consistent

with the underlying data.

Other applications do not require caches reflect the database

exactly all the time.

12/3/2002 Presented by K. Selçuk Candan

Relaxed consistency requirements..

Data Warehouse Data Data Queries Middletier Cache Data Data Queries Misses

12/3/2002 Presented by K. Selçuk Candan

Invalidation vs. view maintenance

Result caches need

–

all out-dated results be invalidated

in a timely fashion.

12/3/2002 Presented by K. Selçuk Candan

Example

Page: http://www.autobuy.com/modelinfo?car=Toyota

select maker, model, price from Car where maker = "Toyota"; is cached.

12/3/2002 Presented by K. Selçuk Candan

Example (cont.)

If a new tuple

–

(Toyota; Avalon; 25000)

is inserted into Car, then we can either

–

recompute the new results of this query (preferably incrementally) and

–

rerun the application to regenerate the page.

–

purge the corresponding page from the cache.

–

the request can still served from the database!

• r

12/3/2002 Presented by K. Selçuk Candan

Overinvalidation as a tool

Overinvalidation can be used if accurate invalidation is

–

too expensive or

–

not feasible in a given time frame

Underinvalidation is not acceptable!

Invalidation is inherently cheaper than view maintenance:

• we do not need to compute all consequences of updates
• to reduce the invalidation delay, we can overinvalidate

12/3/2002 Presented by K. Selçuk Candan

Query and update streams…

up1 up2 up3 q1 q2 q3 q4 q5 inv1 inv3 inv2

12/3/2002 Presented by K. Selçuk Candan

Example

• Query,

select * from Car, Mileage where Car.maker = "Toyota" and Car.model = Mileage.model;

• New tuples:

–

(“Mitsubishi", “Galant", 23000),

–

(“Toyota", “Avalon", 25000),

• For the second tuple, we need to check whether

–

Car.model = Mileage.model

can be satisfied using the data in the database.

(No additional information required) (Additional information required) (Polling query)

12/3/2002 Presented by K. Selçuk Candan

Polling queries (cont.)

Polling query that has to be answered:

select * from Mileage where "Avalon" = Mileage.model;

If the result to polling query is non-empty, then

–

the newly inserted tuple affected the query Keypoint: We only need to check for existence, we do not need to evaluate the polling query completely

12/3/2002 Presented by K. Selçuk Candan

?: the effect of updates on join views

12/3/2002 Presented by K. Selçuk Candan

?: the effect of updates on join views

• no distinction between deleted or inserted tuples
• no need to evaluate entire ?

12/3/2002 Presented by K. Selçuk Candan

Challenges in calculating ?

available from the update logs

12/3/2002 Presented by K. Selçuk Candan

Challenges in calculating ?

available from the update logs not available !!!

• synchronous: a single copy is maintained

–

the copy is locked during invalidation

• snapshot-based: a copy of the database is maintained
• asynchronous: a single copy is maintained

–

no locking is used

12/3/2002 Presented by K. Selçuk Candan

Snapshot-based approach (new and old versions are available)

12/3/2002 Presented by K. Selçuk Candan

Results

Snapshot-based approach

–

no over- or under-invalidation

–

replication overhead

12/3/2002 Presented by K. Selçuk Candan

Synchronous approach (only new available)

• old version of the database is not available!!!

OVERINVALIDATION

12/3/2002 Presented by K. Selçuk Candan

Results

Snapshot-based approach

–

no over- or under-invalidation

–

replication overhead

Synchronous approach

–

when there are more than two relations, unrecoverable over- invalidation is possible

–

locking overhead

12/3/2002 Presented by K. Selçuk Candan

Asynchronous approach (neither old nor new is available)

12/3/2002 Presented by K. Selçuk Candan

Results

Snapshot-based approach

–

no over- or under-invalidation

–

replication overhead

Synchronous approach

–

when there are more than two relations, unrecoverable over- invalidation is possible

–

locking overhead

Asynchronous approach

–

when there are more than two relations, unrecoverable under- invalidation is possible

–

no overhead

12/3/2002 Presented by K. Selçuk Candan

Efficiency: consolidated invalidation

TIME

12/3/2002 Presented by K. Selçuk Candan

Consolidated invalidation

12/3/2002 Presented by K. Selçuk Candan

Consolidated invalidation

12/3/2002 Presented by K. Selçuk Candan

Consolidated invalidation

12/3/2002 Presented by K. Selçuk Candan

Consolidated invalidation

12/3/2002 Presented by K. Selçuk Candan

Consolidation versus individual invalidation

Individual invalidation:

–

is the average top-1 retrieval cost

–

is the number of queries

Consolidated invalidation:

–

is the total size of ?

12/3/2002 Presented by K. Selçuk Candan

Polling query overhead

12/3/2002 Presented by K. Selçuk Candan

Polling query overhead

12/3/2002 Presented by K. Selçuk Candan

Overinvalidation vs. table sizes

12/3/2002 Presented by K. Selçuk Candan

Overinvalidation vs. update rate

12/3/2002 Presented by K. Selçuk Candan

Conclusions

Fast invalidation is key for caching in multi-tiered architectures Hard consistency is not required by many applications

–

Overinvalidation is acceptable

–

Underinvalidation is not!

View invalidation is inherently cheaper than view maintenance View invalidation is feasible!
