Veolia Water Outsourcing Waste Water and Energy Recovery Greg Turner Technical Director 23 rd April 2008
Veolia Environnement is the world leader in water services . Water and wastewater services management for local municipalities and industrial � customers Design , build, own, operate and maintain waste and wastewater treatment systems � � Optimisation and upgrade of existing systems Water recycling � � Product recovery – Added Value to Process Water source development � 2
Food and Beverage Industry Drivers Cost Control and - Innovative recycling of water/wastewater Economic Performance - Added value by-product identification - Process optimisation Complying with - Management of consents Regulations - EA relationship - Environmental Best Practice - Statuary utility provider relations - Anticipation of future regulatory change Improving Brand Image - Sustainability and Public Perception - Minimise Resource Utilisation - Environmentally Friendly image Hygiene, Safety and - ISO 1400 systems Quality Compliance - Multi barrier recycle strategy 3
Services within the Food and Beverage Industry Sludge Lighting, heating & management & cooling systems treatment Water source development Wastewater management Purified water Boiler facility management Power generation & Water re-use & maintenance recycling Facilities management Waste to energy Industrial water Distribution system management By-product recovery Waste transportation Liquid & dry waste management 4
Anaerobic Digestion A natural treatment method for organic waste Biological decomposition of organic matter in an environment without air supply Production of gas as recoverable energy (biogas) Used for organic waste with a high carbon content (soluble COD) Low volume sludge production Undigested matter can be dried and used as biomass fuel Residual organic matter used for composting and landspreading 5
Anaerobic Digestion and Waste Water Anaerobic Digestion and Waste Water Anaerobic digestion processes are used in the treatment of biomass from waste effluent, sludge, and organic matter produced by industry. The process is a very compact and efficient proven process can reduce loads of COD by 70-90% produces significantly less volumes of sludge than aerobic processes reduces the risk of odour can be applied to concentrated liquid or semi-solid organic wastes with high dissolved COD loads (4.5 to 100g/l) including: � Sludge from aerobic treatment of industrial effluent � Organic waste from industrial activity � Waste from catering service � Sludge from municipal wastewater � Municipal waste 6
Biogas: from Waste to Energy Biogas: from Waste to Energy Sales to local Power Grid SELF - USAGE RESIDUALS soil fertilization liquors organic manure e greases waste t s a w Non reusable portion: e r u 1 t s Flaring l u t c c u i d r g o A r p - o c Treated Water Sludge Activated ELECTRICITY Food Digestion / sludge co-digestion (yield: 30-40%) Processing Plant Carbon BIOGAS Credits (CO 2) Effluent 60-75% Combustion Engine méthane (CH 4 ) 2 COGENERATION boiler Treated Thermal Energy Water 4 (yield: 45-50%) Sludge Digestion (35 ° C) Heated Water @ 90 ° C Heating 3 Usage in Cleaining of Other usages: Plant Plant Heating of Digestor - vehicle fuel Process - natural gas distribution circuit RE - CYCLING 7
Benefits go beyond treatment performance Benefits go beyond treatment performance Anaerobic Digestion Process gives following main benefits High efficiency Production of a sludge with high fertilizer value (PKN) Renewable energy production: biodegradable organic matter is converted into biogas 70 – 80% methane (CH4), a source of “green energy” Cogeneration to thermal or electrical energy (non fossil fuels) Greenhouse gas reduction. CH4 recovery provides carbon credits allocations if sites consumption > 20 MW/yr 8
Benefits of Anaerobic Digestion Benefits of Anaerobic Digestion Cost savings in line with increased energy prices Attracts Government Incentive Programmes (renewable energy) Carbon Credits Reduction of Industrial Environmental Impact Demonstrates Sustainable Development Policy A Solution to Local Limitations on Organic Waste Disposal Wastewater + Organic Waste � Non Fossil Energy Biogas offers a combination of the Veolia Group Environmental Services of Water + Energy + Waste. 9
Case Studies Case Studies Royal Brewery, Manchester John Smiths, Tadcaster Carlsberg Heineken Danone Slaughter Houses Dairies Juice Manufacturers 10
Case Studies - Brewing and Distilling Brewing Company, UK Client’s needs The Client A solution was required to reduce the One of the world’s leading high cost of discharging untreated brewing groups with a strong wastewater to sewer and minimise the international market position. At impact to the local environment. It was this site, well known brands are the clients requirement to treat site brewed and packaged . wastewater and discharge to river to achieve both of these aims. Our solutions The results and benefits The turnkey project was Veolia proposed a turnkey solution commissioned in October based on high rate, small footprint 2007.Veolia will also operate anaerobic/aerobic processes, the WWTP on behalf of the including recovery of by-products brewery. The plant will such as methane. discharge to river. 11
Technology and Solution Full turnkey design and build solution Divert Odour Control Gas Buffer List of technologies by steps of treatment Gas Burner Primary treatment - 1mm screen Secondary treatment - Anaerobic + Aerobic Screen Balance Recirc.Tank Anaerobic Aerobic Tertiary treatment - DAF + Disc Filter Other treatments - Biogas recovery and re-use Disc Filter Services - Operation and maintenance Sludge Tank DAF Main technical Data - 42m 3 /hr- 4tons COD/d - Biogas 60m 3 /hr Belt Press Consent - BOD 20mg/l - SS 25mg/l - NH 4 10mg/l 12
Plant set-up 13
Veolia Water Outsourcing Thank You For further details please contact info@vwio.com 14
