US R&E Initiatives: NLR, Abilene, HOPI and TransPAC2 Chris - PowerPoint PPT Presentation

US R&E Initiatives: NLR, Abilene, HOPI and TransPAC2 Chris Robb Presented at the APAN 2005 Fall Meeting, NOC Engineering Session 25 August 2005 Focus The first half of this talk will provide a very brief overview of the state of some of


  1. US R&E Initiatives: NLR, Abilene, HOPI and TransPAC2 Chris Robb Presented at the APAN 2005 Fall Meeting, NOC Engineering Session 25 August 2005

  2. Focus The first half of this talk will provide a very brief overview of the state of some of the largest US-based R&E networking initiatives The second half will focus on the connectivity to these networks via TransPAC2, as well as a general TransPAC2 architectural update

  3. National Lambda Rail (NLR)

  4. National Lambda Rail Layer1

  5. NLR Layer2 What is deployed? 13 of 18 sites deployed as of 25 August 2005 SEAT CLE V CHIC PITT DEN NEWY SUN V KANS N WDC RALE LOSA ALB TULS U ATLA circuit up circuit pending ELPA site up site JACK site pending site BATO HOUS Cisco 6509 switch

  6. NLR Layer3 What is deployed? 6 of 8 sites deployed as of 25 August 2005 SEAT CHIC NEWY DENV WASH LOSA ATL A circuit up circuit pending site up site HOUS site pending site Cisco CRS Router

  7. HOPI

  8. HOPI Hybrid Optical Packet Infrastructure Testbed network owned by Internet2 signaling technologies lightpath experimentation cross-domain coordination Timeframe: two to three years

  9. HOPI Node Locations All nodes except New York installed New York install in early October

  10. HOPI Node Architecture

  11. HOPI Rack Architecture HOPI Wiring Scheme chrobb@indiana.edu 2005-03-31 v1.1 ISDN Cisco 2811 ISDN Provider Router DC AC DC DC Power AC Power Controller Controller L2 or L3 DC Abilene Cisco 2950 Racklan Switch Connector AC Control PC Console Connection AC Mgmt PC SMF Fiber Copper AC Measmnt PC AC Power Requirement DC Glimmerglass 10G Force10 E600 Ethernet Switch Abilene 10G DC 10G 10G DC NLR NLR East West

  12. Abilene

  13. Abilene Connections The Abilene Network completed connections: U RhodeIsland 245 participants Brown IBM lab 42 connectors + 7 IXs: 2 NGIXs, StarLight, AMPATH, 2 PacificWaves, ManLan Binghamton U U Conn 54 connections to 30 peer networks SUNY Albany U Wisc-Mad. Yale SInet Stony Brook U Boeing U Illinois-Urbana Singaren CERN Marquette GEMnet NOAA-PMEL Phantom ASNet Hawaii Vermont U Illinois-Chicago RIT KREONet2 U Wisc-Milw. MSOFT GLORIAD Maine Cornell Pacific/Northwest U Iowa UMass-Amherst NREN U Alaska WiscREN Rensselaer UNH S. Illinois U DTF Brandeis DREN MontanaSU SUNY Buffalo Northeastern SURFnet Northwestern Pacific 2* CAnet Boston C Rochester TAnet2 Wave U Montana N. Illinois U Dartmouth Starlight CERnet NYU EBSCO 2*CAnet U Idaho NotreDame Boston U JGN2 Syracuse Seattle Argonne WPI WashingtonSU Harvard DREN AARnet Columbia KREONet2 U Chicago Loyola U Washington OR HealthSci Tufts NISN NYSERNet* HARnet DePaul NCSA USGS MIT OR GradInst TAnet2 MREN ESNet Qatar DREN PortlandSU NOX USDept Commerce Wichita SU GÉANT HEAnet NISN Mayo Clinic OregonSU Chicago UCAR SetonHall 2*CAnet U Missouri-Rolla USGS S.DakotaMines&Tech NREN U Med & U Oregon U Wyoming U Del U Nebraska GÉANT UCAID Dent of NJ NGIX-Ames Oregon U S.Dakota WayneSU ManLan U Colorado-Dv NJIT KansasSU S.DakotaSU U Utah MichTechU MERIT* U Colorado-Bo NII U Kansas New York City BYU N.DakotaSU MAGPI MichiganSU Idaho SU U Missouri-Col MIX PAIX Eli Lilly Colorado SU U N.Dakota UMichigan Rutgers Utah SU U Missouri-SL StLouis U ESnet Temple Surfnet W.Mich U Inter- FrontRange EROS DataCtr Sunnyvale U Missouri-KC Children's Wash U Widener U mountain Hosp.of Phil GreatPlains Northern Purdue U ESnet UMN Johnson&Johnson Lab ProQuest USGS Indiana U Denver Lights Iowa SU U Akron Princeton Qwest Calren* OARnet Indiana Stanford vBNS res.lab Lehigh OhioSU UC San Francisco PennSU IBM U Arizona CaseW NISN U Penn Kansas City Indianapolis CMU lab KentSU UC Office Pres W Virginia GÉANT DREN ArizonaSU HOPI PSC CSU UC Santa Cruz NOAO NGIX U Cincinnati Pitt OneNet Memphis NREN Hayward NSF Dragon UC Davis Wright SU SInet Optiputer on DARPA VirCommonwealth U U Louisville Washington U Oklahoma Pacific BoSnet UTenn-Memphis Clev SU UNM WorldBank UC Berkeley Wave Drexel OklahomaSU HolocaustMus UCAID NMT Bowling Green Johnson&Johnson Lab U Tulsa ESNet NMSU GeorgeMason U Toledo Hewlett-Packard Lab Los Angeles NCSU U Arkansas UNC-CH NIH/NLM HOPI J.Hopkins Ohio U MAX* Mississippi SU U Arkansas-LR Apan/Transpac Duke NCNI HughesMed OldDominion U ArkansasMed Calren* UniNet WakeForest UMD U So.Miss Jackson SU VirginiaTech EastCarolina Atlanta SDSC ArkansasSU GWU UC Riverside NSF UT El Paso VIMS U Mississippi Florida SU U Kentucky UC San Diego Georgetown SWmed U Virginia UC Los Angeles SW ResInst Vanderbilt CatholicU Wm&Mary UC Irvine Tulane UC Santa Barbara UT-Austin U Tennessee-K NatArchives NCSA Access CalTech SOX San Diego SU U Md-Balt Clemson Fujitsu Lab JPL U Florida U N.Texas OakRidge NL USC-ISI U S.Carolina GSFC Smithsonian CSU San Bernardino SMU U Georgia UT Dallas U So.Florida NOAA MedU S.Car USC Gallaudet U LAnet CSU WestEd Houston North T exas Georgia Tech UT Arlington CensusBureau UMBC U Alabama-H LSU U Cent.Florida U Nevada-Reno TexasChristian Georgia SU U Alabama-T Southeast Texas OC3 POS/ATM DesertResInst OC12 POS/ATM o n o c Key: U Alabama-B Emory OC48 POS/GigE Florida A&M 1 May 2005 U Nevada-LV Rice U OC192 λ / 10GigE Auburn CUDI TexasTech Atlanta Abilene Core Node Cal Poly-SLO U Puerto Rico SFGP AMPATH U Houston Texas Abilene Connector U Miami NGIX Exchange Point BaylorCMed Florida Internat'l U Florida Atlantic U ANSP Indiana U Abilene Participant Abilene Network Operations Center Peer Network New World Symphony REACCIUN2 GÉANT Retina TexasA&M Indiana University multihomed connector * Gemini South coming soon www.abilene.iu.edu SFAustin SU

  14. Abilene Developments Federal Network-International Transit allowable on a bilateral basis both parties need to agree and work with I2 to establish transit IPv6 Multicast enabled today MPLS handled on a case-by-case basis work has been done to establish an automated tool to set up LSPs across the backbone (BRUW)

  15. TransPAC2

  16. TransPAC2 Network Goals Production networking to facilitate research between US and Asia Cooperation with Internet2 HOPI project US-Asian cooperation on “lightpath” technologies will be crucial to future development Initial assets will allow for MPLS and GMPLS- like experimentation, with future equipment possibly supporting layer 2 and layer 1 services Security coordination Measurement coordination

  17. TransPAC2 Network Overview OC-192 circuit between Tokyo and Los Angeles Japanese side lands on APAN Tokyo XP router (AS7660) US side lands on US TransPAC router (AS22388) peerings with major North American networks: Abilene, ESNET, Canarie, DREN, NISN, NLR, etc. Intra-Asian connections: Tokyo and Hong Kong (2.5G) - link owner NICT-Japan operational today Tokyo to Singapore (TBD) - funded by NII-Japan operational Q1 2006 Backup agreements JGN2, SINET and TransPAC2 circuits all provide mutual backup to each other

  18. TransPAC2 Network Interconnects Los Angeles Tokyo OC-192 Tokyo XP TransPAC2 TransPAC2 Juniper T640 Juniper T320 Circuit Cisco 15454 8x TransPAC 10GigE Optical Switch Observatory Servers 8xGigE 10GIGE 10G Ethernet Switch 626 Wilshire Ave. 2xGigE Hong Kong OC-48 1 Wilshire Ave. 10GigE Cisco 15454 KDDI-A Dark Fiber Tokyo XP Optical Switch Network Pacific Wave Los Angeles 2xGigE Cisco 6509 CNGI 10GigE 10GiGE HKLight Open 2x OC-3 Abilene Exchange 10GiGE Point 10GiGE AARnet CA*net4 Asia & Australia 2xGigE GiGE 10GigE GEMnet DREN GigE GiGE Satellite Pacific Wave Seattle GigE Cisco 6509 2x OC-3 KREONet2 GiGE ESnet GigE GigE SingAREN TANET2 Seattle North America

  19. TransPAC2 Network Futures Much of what TransPAC2 will become is dependent on the next year of infrastructure development in the US, Asia and Europe NLR places a heavy emphasis on point to point lambda networking and Layer2 VLANs HOPI will be experimenting over the next two years with hybrid approaches to point to point “lightpath” connections and how to signal those connections Asian networks continue to build out optical networks in individual countries GEANT2 initiative in Europe will link many countries at the optical layer Who else? TransPAC2 is designed to adapt and participate in these changes, while maintaining production connections between the US and Asia

  20. TransPAC2 Project Futures Network security has become extremely important over the past several years TransPAC2 engineers will focus on bridging the information gap between the US and Asian engineering staffs Network measurement has moved beyond MRTG Who’s trading what Eminem song with whom? What’s happening on my network? When was I last attacked? Why is my multicast stream intermittent? Where is all of my traffic going? How long are TCP flows taking to complete between Asia and Europe?

  21. References TransPAC2 Webpage: http://www.transpac2.net HOPI Testbed Webpage: http://networks.internet2.edu/hopi contains presentations, HOPI whitepaper, and Corporate Advisory Team information National Lambda Rail: http://www.nlr.net Abilene: http://abilene.internet2.edu
