Uralmash Oil and Gas Equipment Holding LLC Modern drilling rigs - PowerPoint PPT Presentation

Uralmash Oil and Gas Equipment Holding LLC Modern drilling rigs 2015 Uralmash Oil and Gas Equipment Holding, LLC integrate design and manufacturing capabilities in the areas of drilling equipment capabilities in the areas of drilling


  1. “Uralmash Oil and Gas Equipment Holding” LLC Modern drilling rigs 2015

  2. Uralmash Oil and Gas Equipment Holding, LLC integrate design and manufacturing capabilities in the areas of drilling equipment capabilities in the areas of drilling equipment manufacturing and service for oil and gas industry. Headcount of the Holding is ~ 3000 people Gazprombank is a strategy Gazprombank is a strategy partner of the Holding . 2

  3. Holding Structure Uralmash OGE Holding, LLC Management of all Holding business units Managing company, Moscow Engineering Uralmash OGE Holding, LLC Engineering center and managing unit for all branch in Yekaterinburg the engineering Designing and manufacturing of complete Designing and manufacturing of complete Neftegasengineering, LLC drilling rigs in accordance with customer Volgograd specific technical requirements Manufacturing of drilling equipment URBO, CJSC manufacturing and assembly of 25-30 Yekaterinburg complete drilling rigs a year 8000 t/year of welded metal structures Plant of modular packaged units, OJSC p g , Tyumen 3000 t/year of welded metal structures Neftemash factory, OJSC Otradny y Service Overhaul of drilling equipment, upgrade of Uralmash Techservice, LLC , drilling rigs and equipment, surveys and Moscow technical diagnostic of oil and gas equipment 3

  4. Holding Geography Management Engineering Production Drilling rigs control assembly Service Moscow Vankor oil field Vankor oil field Yekaterinburg Otradny Tyumen Tyumen Volgograd V l d Buzuluk 4

  5. Manufacturing capabilities Manufacturing capabilities are located at three enterprises of Holding – CJSC URBO Manufacturing capabilities are located at three enterprises of Holding CJSC URBO (Yekaterinburg), Plant of modular packaged units, OJSC (Tyumen), Neftemash factory, OJSC (Otradny). Complete drilling rigs production actual capabilities Complete drilling rigs production actual capabilities – up to 30 drilling rigs up to 30 drilling rigs a year, in the short term – up to 50 pcs. a year. All the produced units of the drilling equipment (pumps, swivels, derricks, hook blocks, crown blocks, drawworks, rotors) are tested under load on facility. Drilling rigs are assembled on two check assembly sites in Yekaterinburg. Up to seven heavy D illi i bl d h k bl i i Y k i b U h drilling rigs can be assembled on the sites at the same time. 5

  6. Drilling equipment engineering Modern software is used during engineering process: Modern software is used during engineering process: � 3D modeling with Siemens NX, � electrotechnical design system «EPLAN Electric»; � CAD � CAD «Intermech»: Search, CadMech, AVS; Intermech : Search CadMech AVS; � engineering analysis tools package NX CAE. 6

  7. Range of produced drilling equipment and services � Mobile drilling rigs of load capacity from 160 to 200 t � � Drilling rig weight from 500 to 1000 tonnes Drilling rig weight from 500 to 1000 tonnes � Cluster drilling rigs of load capacity from 160 to 450 t � Drilling rig weight from 1200 to 1900 tonnes � Land drilling rigs of load capacity up to 600 t and drilling depth up to 15000 meters � Drilling rig weight from 1000 to 3000 tonnes � Drilling equipment sets for onshore and offshore drilling , load capacity from 160 to 320 tonnes � � Units and spare parts of drilling equipment Units and spare parts of drilling equipment � Drilling rigs upgrading � � Technical service of drilling equipment Technical service of drilling equipment 7

  8. Offshore equipment Uralmash Oil and Gas Equipment Holding designs and manufactures drilling equipment for offshore platforms. Irrespective of function drilling equipment can be installed at: � stationary (fixed platforms); � jack-up platforms (jack-ups); � semi-submersible semi submersible platforms (semi); � drilling ships. 8

  9. Potential fields of application of Holding equipment q p Drill ships can be used for Drill ships can be used for drilling in any deep water Stationary (fixed platforms) y ( p ) and semi-submersible For Arctic and Sakhalin island offshore development all the platforms (semi) are used three types can be used: in the Caspian and Black stationary (fixed platforms), sea sea semi-submersible platforms (semi) and jack-ups 9

  10. Offshore drilling equipment production history History of design, production and delivery of Uralmash equipment for offshore drilling began in 1970. From 1973 to 2011, in cooperation with shipbuilders and shipyards, 38 sets of main drilling equipment for offshore drilling were produced : f i d illi i t f ff h d illi d d � 10 sets for fixed platforms; � 16 sets for jack-up platforms; j p p ; � 11 sets for semi-submersible platforms; � 1 set for drilling ship. � 10 drilling equipment sets 160D for fixed platforms; The main customer ordering platforms was the Ministry of oil and gas industry of the USSR. Drilling equipment sets for installation on the platforms were delivered to the following companies: � «Krasnye Barrikady», Astrakhan; � Astrakhan shipbuilding production association (“Marine yard”); � Astrakhan shipbuilding production association ( Marine yard ); � «Lotos», Norimanov town, Astrakhan region; � Vyborg Shipyard, Vyborg town, Leningrad region; . 10

  11. Offshore equipment KB О KB О KB О KB О KB О Main parameters NBO-160D NBO-ESP 4000/250 5000/320 6500/400 5000/320 6500/400 ESP ESP PPE М PPE М EUM EUM DGSP DGSP BSE BSE Admissible hook load, kN 1600 2250 2500 3200 4000 3200 4000 Rated drilling depth, m 2500 4000 4000 5000 6500 5000 6500 Hook speed while reciprocating, m/s 0,2 0,18 0,1..0,25 0,1..0,25 0,25 0,2 0,25 Elevator no load lifting speed m/s Elevator no-load lifting speed, m/s 1 6 1,6 1 5 1,5 1 6 1,6 1,6 1 6 1 6 1,6 1 7 1,7 1 6 1,6 Input shaft rated power, kW 670 630 900 1420 1475 1400 1475 Rotary table opening, mm 700 700 700 1260 950 700 1260 Rotary drive rated power, mm 370 370 370 370 440 370 370 Mud pump power kW Mud pump power, kW 600 600 950 950 950 950 950 950 950 950 950 950 Diesel- generato Drive type Diesel Electric Electric Electric Electric r set Electric In operation Complexes produced 10 6 4 11 2 6 1 Sea of Sea of Okhotsk, Okhotsk, Caspian Barents Caspian Barents Operation region Caspian Sea Sea Sea Sea Sea 11

  12. Basic set of equipment for offshore platforms Basic set of equipment for offshore platforms produced by Uralmash Oil and Gas Equipment Basic set of equipment for offshore platforms produced by Uralmash Oil and Gas Equipment Holding includes the following main drilling equipment: � Derricks � Swivels � Swivels � Hook blocks � Top drive � Derrick manifold standpipe Derrick manifold standpipe � Drawworks with drives and control system � Rotary tables with a drive � Catworks � Hydraulic catheads � Driller’s cabins with integrated control systems of top drive, automatic drilling tongs � Hydraulic stations � Mechanized catwalk � Mud pumps with drives � Mud circulation system � Compressor modules � Auxiliary mechanisms drives 12

  13. Units and systems for offshore drilling Basic set produced by Uralmash Oil and Gas Equipment Holding for offshore platforms includes the following main drilling equipment : � Derricks � Swivels � Hook blocks Hook blocks � Top drive � Derrick manifold standpipe � Drawworks with drives and control system � Rotary tables with a drive � Catworks � � Hydraulic catheads Hydraulic catheads � Driller’s cabins with integrated control systems of top drive, automatic drilling tongs g � Hydraulic stations � Mechanized catwalk � Mud pumps with drives � � Mud circulation system Mud circulation system � Compressor modules � Auxiliary mechanisms drives 13

  14. Major maintenance services ■ ■ Maintenance service of mechanical own manufactured equipment Maintenance service of mechanical own manufactured equipment ■ Maintenance service of SCR, ACS ■ Warranty maintenance service of equipment ■ ■ Technical maintenance of field operated drilling rigs Technical maintenance of field operated drilling rigs ■ Maintenance and emergency repair of drilling equipment in the regions. Repair and hydraulic pressure testing of blowout preventers ■ Complete overhaul of equipment ■ Supervising installation, assembling and setting up of new equipment ■ Re- installation and setting up of installed equipment ■ Training for drilling companies staff to operate and maintain modern Russian drilling equipment ■ Upgrading ■ Supply necessary materials and technical resources using system of regional warehouses within complex service projects SEPT 2014 14

  15. Thank you for Thank you for your attention! y “Uralmash Oil and Gas Equipment Holding” LLC 117036, Moscow, 60-letiya Octyabrya pr., 21, bld. 4 Tel.: +7 (495) 783-05-67 ( ) Fax: +7 (495) 783-05-68 E-mail: info@uralmash-ngo.com Branch of “Uralmash Oil and Gas Equipment Holding” LLC in Yekaterinburg in Yekaterinburg 620012 Russia, Yekateringburg, Pervoy Pyatiletki Sq. Tel.: +7 (343) 270-12-00 Fax: +7 (343) 270-12-01 E-mail: ngo@urbo.su 15
