TSDM Transportation System Data Management Presentation By - PowerPoint PPT Presentation

Oct 26, 2022 •480 likes •748 views

TSDM Transportation System Data Management Presentation By BACKGROUND DelDOT owns approximately 87% of roadways in the state 13,000+ Lane Miles in Delaware Estimated 2 million assets Need to inventory assets and features in the

  1. TSDM Transportation System Data Management Presentation By

  2. BACKGROUND  DelDOT owns approximately 87% of roadways in the state  13,000+ Lane Miles in Delaware  Estimated 2 million assets  Need to inventory assets and features in the field  RIDE Application outdated  Need for modern features including GIS

  3. THE OLD WAY - RIDE

  4. TSDM – VISION INTO THE FUTURE  GIS as the primary focus not an addon  Incorporate LIDAR data  Data interoperability/sharing  Modern scalable/expandable technologies  Integrated mobile capabilities  One Application – All Data

  5. TSDM – VISION INTO THE FUTURE

  6. TSDM – THE CONCEPT

  7. TSDM – ENVISIONED COMPONENTS  New RIDE (TSDM)  LRS & Centerline  Issue reporting & resolution  External data interfaces  Public facing portals  Reporting and Analysis Tools  Validations

  8. TSDM – THE USER INTERFACE

  9. TSDM – THE USER INTERFACE

  10. TSDM – REVIEW TOOLS Useful tools for review are inside one application. “Road View” Linear Aerial Imagery Reference

  11. TSDM – DATA POPULATION Multiple methods of asset population; Click to add. • Draw on Map. • GPS. •

  12. TSDM – POINT ASSETS

  13. TSDM – POINT ASSETS

  14. TSDM – LINEAR ASSETS

  15. TSDM – POLYGON ASSETS

  16. TSDM – ITEM MANAGEMENT

  17. TSDM – USER MANAGEMENT

  18. TSDM – GROUP MANAGEMENT

  19. TSDM – LRS MANAGEMENT

  20. TSDM – VALIDATIONS

  21. TSDM – ISSUE REPORTING

  22. TSDM – THE ARCHITECTURE  Microservice Architecture  Independently deployable modular services  Continuous delivery and deployment  Netflix Zuul gateway Technology  Unified front door  Edge Service for TSDM APIs/Services  Request Routing and service discovery  Enables great flexibility for horizontal and vertical scaling

  23. TSDM – THE ARCHITECTURE

  24. TSDM – THE CURRENT STATUS  Data uploaded into TSDM from LiDAR extraction:  76 Feature/Asset types  1.2 Million Total Gross Features/Assets  All Roads have been migrated from RIMS database to TSDM  Currently in Phase 2 – Using continuous delivery model into production

  25. THANK YOU CONTACTS Jason Vogl Madduri Raghunath Jason.Vogl@state.de.us Madduri.Raghunath@Delasoft.com (302) 760 2163 (512) 633 3445
