Tri- -State Consulting Co. State Consulting Co. Tri Introduction - PowerPoint PPT Presentation

Tri- -State Consulting Co. State Consulting Co. Tri Introduction Introduction Team Members: Jamie (Team Leader) Mark Justin John Ritchie Assignment & Objectives Assignment & Objectives Create a catapult


  1. Tri- -State Consulting Co. State Consulting Co. Tri

  2. Introduction Introduction � Team Members: � Jamie (Team Leader) � Mark � Justin � John � Ritchie

  3. Assignment & Objectives Assignment & Objectives � Create a catapult able to throw a specified object a certain distance � Have quick and easy adjustments � Safe for the consumer � Consistent and accurate � Strong � Cost effective � Present finished product and presentation

  4. Rules and Regulations Rules and Regulations � Catapult � Target – No larger than 1.5 cubic – Set 3 meters away from feet catapult – Propulsion by springs – Diameter of bulls eye: or elastic bands 3 in. – Distance of bulls eye � Projectile off the ground: 20.5 in. – 50 gram ball – Direct hit – 100 pts. (golf ball)

  5. Initial Ideas Initial Ideas � Design – Spring that pulls � Location(s)? � Materials – Metal and wood � Drew initial sketches � Thought of our objectives

  6. Initial Design Initial Design � Mostly made of wood � Spring that pushes � Little room for adjustments

  7. Final Design Final Design � Changed Position and type of Spring � Changed Arm � Changed Stopper � Wood Base Remained the Same � Added Elevation Adjustment bolts

  8. Final Design Pictures Final Design Pictures Side view Front View Top view

  9. Tools Used Tools Used � Drill press � Bench Grinder � Hacksaw � Table Saw � Milling Machine � Glue Press � Sander � Router

  10. Materials Materials � Wood Base � All Thread Lever � Spring � Nuts, Bolts, & Washers � Aluminum Holder � Metal Bases to Support Apparatus

  11. Cost Cost � Wood Base $6.00 � Lever $2.50 � Angle Iron $2.50 � Aluminum $1.50 Bar Stock � Nuts, Bolts, $2.50 & Washers � Total $15.00

  12. Construction and Assembly Construction and Assembly � Used all available resources to effectively produce desired results – John’s brother’s house � Scrap metal reduced cost, increased strength

  13. Results Results � 3 Hits of 90 100 � 100% Accurate 90 � Very Safe first shot 80 � Cost Efficient second shot 70 � Easy Assembly third shot 60 50 shots
