Trading-off incrementality and dynamic restart of multiple solvers in IC3 Paolo Enrico Camurati, Carmelo Loiacono, Paolo Pasini, Denis Patti, Stefano Quer Dip. di Automatica ed Informatica, Politecnico di Torino, Torino, Italy Multiple


  1. Trading-off incrementality and dynamic restart of multiple solvers in IC3 Paolo Enrico Camurati, Carmelo Loiacono, Paolo Pasini, Denis Patti, Stefano Quer Dip. di Automatica ed Informatica, Politecnico di Torino, Torino, Italy

  2. • Multiple properties/targets for same model – As primary inputs – Generated by decomposition • Handle different properties as sub-problems – Target sorting and/or grouping • Interaction and synergy among proofs – Reuse reduction – Propagate learning 2

  3. • Focus on large circuits with several properties – Between 500 and 50K properties – Between 500 and 500K latches • Subset of HWMCC’13 (multiple and single tracks) Number of Properties Number of Latches 500000 50000 50000 5000 5000 500 500 3

  4. • Motivation • Property grouping – clustering – verification with learning • Property decomposition – partial verification – coverage estimation • Conclusions and future works 4

  5. F PI F 0 PI T 0 T F 1 T 1 FF … F n-1 T n-1 State Reg n-1 5

  6. • Straightforward verification – sequential – individual checks T • Overhead i – initialization and finalization of T j single properties T k • Repetition of shared sub- tasks 6

  7.   • Group properties together P : p i p i • Tuning to avoid scalability issues F PI F 0 PI T 0 T F 1 T 1 FF … F n-1 T n-1 State Reg n-1 Cooperation: share CEXes, invariants Grouping & Sorting Properties 7

  8. • Several strategies – sort properties by expected verification effort – classify properties according to mutual affinity • Group properties in subsets – tune verification within subset • Address scalability issues – COIs size explosion 8

  9. F k • Exploit learning PI T k – reuse discovered invariants • cluster to cluster State Reg k • target to target – reuse reductions and simplifications R+ =Constr – trade off between usability and size/costs • Filter CEXes F j – reorganize clusters removing PI T j failed properties • One hard property may hinder State Reg j whole cluster verification

  10. • Affinity estimated based on support variables V p within COIs  V V • Jacquard Index   j k  V V j k • Grouping performed if resulting value is above a chosen threshold • Verification starts from properties with smaller COIs 10

  11. • Comparison between our sequential and cluster based approaches • Best result among different clustering thresholds • Usually at least as good as sequential verification 11

  12. • COIs sizes tend not to grow so much to become intractable • Values normalized considering only non-constant properties 12

  13. 100000 10000 1000 100 10 1 Seq 25 200 500 Tot. Props. • The number of allowed clusters influences verification outcome • Automatic tuning of thresholds is an on-going effort 13

  14. 100000 10000 1000 100 10 1 Seq 25 200 500 Tot. Props. • The number of allowed clusters influences verification outcome • Automatic tuning of thresholds is an on-going effort 14

  15. 100000 10000 1000 100 10 1 Seq 25 200 500 Tot. Props. • The number of allowed clusters influences verification outcome • Automatic tuning of thresholds is an on-going effort 15

  16. 100000 10000 1000 100 10 1 Seq 25 200 500 Tot. Props. • The number of allowed clusters influences verification outcome • Automatic tuning of thresholds is an on-going effort 16

  17. 100000 10000 1000 100 10 1 Seq 25 200 500 Tot. Props. • The number of allowed clusters influences verification outcome • Automatic tuning of thresholds is an on-going effort 17

  18. • Motivation • Property grouping – clustering – verification with learning • Property decomposition – partial verification – coverage estimation • Conclusions and future works 18

  19. • Property decomposition aimed at full verification • Easy-to-solve properties of little interest – introducing overhead – no information to gain • Hard-to-solve still unsolvable as a whole – sub-problems can be as hard as the original

  20. • Compositional verification of monolithic properties • Relax goal of full verification – infer information from covered parts (bounds, CEXes , …) F 0 PI T 0 – better than nothing at all State Reg 0 … F n-1 F PI T T n-1 State FF Reg n-1 20 20

  21. • Divide & Conquer approach for hard-to-solve   P i p properties i • Identify a subset of “easier” properties – smaller COIs – sub-space constrained – only describing sub-behaviors • Treat original property as a grouped instance • SAT solvers as sub-target enumerator 21

  22. • Derive target from invariant   t p  t SAT ( t ) • Consider a minterm as first sub-target 0   p t 0 0 • Acquire over-approximated stateset representations as sub-product of previous verification 0  R , , R k • Iteratively select targets that hit the innermost reachable state ring • Terminate upon – identifying a partial target as reachable, disproving the property – acquiring a strong enough R set to prove the original property 22

  23. • Based on size/percentage of reachable states • State space estimation based on graph-based algorithm • Derived from life sciences and “capture -mark- recapture” approaches • Inherently difficult to produce almost exact estimation • Ongoing work in this direction 23

  24. Partial/Exact Bound Ratio • Focus on hard-to-solve 10,00 single property designs • SAT properties: – BMC runs to identify CEX bounds • UNSAT properties: – Standard verification to 1,00 identify pass bounds • Partial verification – Diminished time limit for sub-properties verification through UMC – Bound estimation derived from these runs 0,10 24

  25. • Motivation • Property grouping – clustering – sequential verification with learning • Property decomposition – partial verification – coverage estimation • Conclusions and future works 25

  26. • Preliminary results are promising and show room for improvement • Further investments in clustering techniques and heuristics • Automatization of threshold selection and cluster parametrization • Further research in partial verification as indicator for currently untreatable instances 26

  27. Trading-off incrementality and dynamic restart of multiple solvers in IC3 Paolo Enrico Camurati, Carmelo Loiacono, Paolo Pasini, Denis Patti, Stefano Quer Dip. di Automatica ed Informatica, Politecnico di Torino, Torino, Italy
