Does Aspect-Oriented Programming Increase the Development Speed for Crosscutting Code? An Empirical Study Stefan Hanenberg, Sebastian Kleinschmager, Manuel Josupeit-Walter University of Duisburg-Essen, 2009 Presenter: Olivier Clerc ETH Zrich


  1. Does Aspect-Oriented Programming Increase the Development Speed for Crosscutting Code? An Empirical Study Stefan Hanenberg, Sebastian Kleinschmager, Manuel Josupeit-Walter University of Duisburg-Essen, 2009 Presenter: Olivier Clerc ETH Zürich 1

  2. Logging void foo() { bar(); } void bar() { baz(); } void baz() { System.out.println(“Hello, world!“); }  Extend the program such that each method call is written to a log 2

  3. OOP Solution void foo() { Logger.log("foo"); bar(); } void bar() { Logger.log("bar"); baz(); } void baz() { Logger.log("baz"); System.out.println(“Hello, world!“); }  Add logging instruction at beginning of each method  Tedious if number of methods is large  The logging behavior is dependent on the program 3

  4. Cross-cutting Concerns  Logging is a prime example of a cross-cutting concern  Definition: A behavior that affects multiple modules in traditional OOP 4

  5. Aspect-Oriented Programming (AOP)  Programming paradigm that addresses cross- cutting concerns  Separation of a software system‘s cross- cutting concerns from its core logic  Aspect = a cross-cutting concern  Base code = the core logic (traditional OOP)  Program = base code + set of aspects 5

  6. AOP Solution public aspect LoggerAspect { Pointcut: „WHEN?“ pointcut methodInvocation() : execution(* *(..)); before() : methodInvocation() { MethodSignature signature = (MethodSignature) thisJoinPoint.getSignature(); Logger.log(signature.getMethod().getName()); } Advice: „WHAT?“ }  Logging is represented as a new aspect  Completely decoupled from the rest  The aspect can be reused for any other OO program 6

  7. Intent of the Paper  Proponents of AOP claim...  It provides better modularization  It is more readable  It is more maintainable (suggested by another study)  What about the development time?  The paper tries to answer: “Under what circumstances does AOP reduce the development time ?“  Important: this question is only asked for cross-cutting concerns 7

  8. Assumption of the Authors  Assumption: “The more code targets a cross -cutting concern affects, the more it pays out to use AOP“  Rationale: For logging only 3 methods it is easier to simply add 3 lines of code, instead of writing an aspect. 8

  9. Experimental Setup  1 target application (small game of 9 classes)  20 subjects (students with 1.5h AOP experience)  9 tasks (extensions) to be implemented  To be done using both AOP (AspectJ) and OOP (Java)  Development time for a task was measured from the first code change until all test cases pass 9

  10. Tasks Task # code Code targets sim. ≠ 1. Logging 110 ≠ 36 2. Parameter Null = 3. Synchronization 52 = 4. Player Check 4 = 5. Notify Observers 19 = 6. Observers Null 15 ≠ 7. Refresh Constraint 8 ≠ 8. Label Value Check 6 = 9. Level Check 7 10

  11. Variance Analysis “What causes the different development times?“  The development time potentially depends on two factors :  the task  the language • Result of 2-factor ANOVA ( an alysis o f va riances) :  The task has an important effect  The language has an effect  The effect of the language depends on the task (interaction effect) 11

  12. Variance Analysis (2) Effect F value p value Main effect of task 55.02 ~0 Main effect of language 13.75 0.001 Interaction effect of task and language 9.85 ~0 12

  13. Equality of Development Times “For what tasks does the choice of language result in different development times?“  For each task there are 20 samples of the AO and OO development time  A Wilcoxon test was performed to check which of the following hypotheses hold:  H 0 : the development times for AO and OO are equal  H 1 : they are not equal 13

  14. Task # code Code targets sim. ≠ 1. Logging 110 ≠ 2. Parameter Null 36 = 3. Synchronization 52 = 4. Player Check 4 5. Notify = 19 Observers = 6. Observers Null 15 7. Refresh ≠ 8 Constraint 8. Label Value ≠ 6 Check = 9. Level Check 7 n/a n/a All tasks as one 14

  15. Task # code Code All targets sim. devs ≠ + 1. Logging 110 ≠ + 2. Parameter Null 36 = 3. Synchronization 52 0 = - 4. Player Check 4 5. Notify = - 19 Observers = - 6. Observers Null 15 7. Refresh ≠ - 8 Constraint 8. Label Value ≠ - 6 Check = 9. Level Check - 7 n/a n/a - All tasks as one 15

  16. Task # code Code All Fast Slow targets sim. devs OO OO devs devs ≠ + + 1. Logging 110 0 ≠ + 2. Parameter Null 36 0 0 = - 3. Synchronization 0 0 52 = - - - 4. Player Check 4 5. Notify = - - - 19 Observers = - - - 6. Observers Null 15 7. Refresh ≠ - - - 8 Constraint 8. Label Value ≠ - - - 6 Check = 9. Level Check - - - 7 n/a n/a - All tasks as one n/a n/a 16

  17. Task # code Code All Fast Slow Fast Slow targets sim. devs OO OO AO AO devs devs devs devs ≠ + + + 1. Logging 110 0 0 ≠ + 2. Parameter Null 36 0 0 0 0 = - - 3. Synchronization 0 0 0 52 = - - - - - 4. Player Check 4 5. Notify = - - - - - 19 Observers = - - - - - 6. Observers Null 15 7. Refresh ≠ - - - - - 8 Constraint 8. Label Value ≠ - - - - - 6 Check = - 9. Level Check - - - 0 7 n/a n/a - All tasks as one n/a n/a n/a n/a 17

  18. Threats to Validity  Authors:  The experiment was done in different sessions  Not all received exactly the same tutorial  Learning curve of subjects ignored  Are the tasks representative?  My opinion:  Are the statistics expressive? (only 20 samples)  Subjects were all AOP novices (only 1.5h of learning)  What about other AOP languages apart from AspectJ? 18

  19. Conclusion “Under what circumstances does AOP reduce the development time ?“ 1. if the developers are experienced ; 2. if the number of code targets is large (≥36); 3. if the OOP code snippets to be inserted are different from each other. 19

  20. Questions? 20
