TEP5000 Technical presentation Product overview Technology System - PowerPoint PPT Presentation

TECHNICAL PRESENTATION V1.2 .20 S tig ABRAHAMSON, TECHNICAL SUPPORT BUSINESS AREA: TEP-SERIES WEB-SITE: www.biosoft.se TEP5000 Technical presentation Product overview Technology System integration Support - 1 - TEP5000


  1. TECHNICAL PRESENTATION V1.2 .20 S tig ABRAHAMSON, TECHNICAL SUPPORT BUSINESS AREA: TEP-SERIES WEB-SITE: www.biosoft.se

  2. TEP5000 Technical presentation  Product overview  Technology  System integration  Support - 1 -

  3. TEP5000 characteristics  Future proof  Backward compatible  Desktop and OEM versions  Reliable, long service life  Compact, easy to integrate  Configurable - 2 -

  4. TEP5000 Desktop-series - 3 -

  5. TEP5000 OEM-series - 3 -

  6. TEP5000 Media & data carriers 1/3  Magnetic card tickets, direct thermal  RFID tickets, direct thermal  Plastic cards - 4-

  7. TEP5000 Media & data carriers 2/3  Magnetic card tickets, direct thermal  RFID tickets, direct thermal  Plastic cards - 5 -

  8. TEP5000 Media & data carriers 3/3  Magnetic card tickets, direct thermal  RFID tickets, direct thermal  Plastic cards - 6 -

  9. TEP5000 Technical presentation  Product overview  Technology  System integration  Support - 7 -

  10. TEP5000 Communication interfaces  Serial RS232 up to 115200baud  USB-com port emulator in PC  Ethernet interface RS232 USB Ethernet - 8 -

  11. TEP5000 Modular description Document entry Magnetic Track control mechanism encoder/reader engagement Cutting RFID Print roller module blade module module Upper document 9 Lower document Print head Cutter module Front document lift motor feed motor CW083-R1 - 9-

  12. TEP5000 Control board  Based on Actel FPGA  Flash Prom for F/W and fonts  EE-Prom for ticket counter etc.  Sram for variable and image store  Motor driver circuits  Analog to digital converter  Real time clock  Sensor inputs  Communication interfaces - 10 -

  13. TEP5000 Magnetic module  3 track write head  3 track read head  One pass verify - 11 -

  14. TEP5000 Magnetic encoding  LoCo and HiCo - LoCo 300oe used in most applications - HiCo 2700oe used when a “Household magnet” proof encoding is needed  ISO track positions 1, 2 and 3 or Center track  Encoding according to ISO F2F standard. - ISO, Characters according to ISO standard start, stop and checksum added automatically. - HEX, Full control of binary data on strip.  Bit density - ISO standard 75 and 210 bpi (bits per inch) - Non standard 105 and 161 bpi - 12 -

  15. TEP5000 RFID module  Direct communication PC - RFID  ISO 14443-A/-B MIFARE, MIFARE Ultra light, RFID Module Calypso  Custom module easily integrated 9 - 14 -

  16. TEP5000 Cutter module  Guillotine cutter  Self sharpening  High speed DC-motor with gearbox  Home sensor - 1 5-

  17. TEP5000 Thermal print  One consumable  Print density 8 dot/mm (203 dpi)  History control Printhead  Parameter control of burntime Paper roll Heaters Printout Platen - 16 -

  18. TEP5000 Technical presentation  Product overview  Technology  System integration  Support - 17 -

  19. TEP5000 System integration  Mechanical integration  Command based integration  Importance of status  System implementation  Biosoft services - 18 -

  20. TEP5000 Paper path F A N F O L D P A P E R F A N F O L D S T O C K S T O C K P r e v e n t t h e f a n f o l d p a p e r f r o m g e t t i n g c a u g h t b y s h a r p e d g e s a l o n g t h e p a p e r p a t h b e c a u s e t h i s m a y r e s u l t i n e n c o d i n g - 19 -

  21. TEP5000 Kiosk integration  Design paper path  Design eject  Prevent dust  Simple paper load  Easy access for maintenance - 20 -

  22. TEP5000 Command integration  Fixed and downloadable fonts  Multiple width and height  Text rotation  Bar codes  Graphics  Parameters stored in Flash Prom - 21 -

  23. TEP5000 Windows utility program - 22 -

  24. TEP5000 Technical presentation  Product overview  Technology  System integration  Support - 23 -

  25. Biosoft support  Access to more than 20 years of advanced, international, experience in ticket printers! - 24 -

  26. thank you for your attention! TECHNICAL PRESENTATION V1.2 .20 S tig ABRAHAMSON, TECHNICAL SUPPORT BUSINESS AREA: TEP-SERIES WEB-SITE: www. biosoft .se/ - 25 -
