Sisi Fan, Jemma Pilcher, Iain Bower, Matthew Chin, Margarita Kopniczky, Wenqiang Chi & James Strutt Could Synthetic Biology transform all this rubbish (t rash) into these? Plastic of the Future: Poly-3-hydroxybutyrate PHB A


  1. Sisi Fan, Jemma Pilcher, Iain Bower, Matthew Chin, Margarita Kopniczky, Wenqiang Chi & James Strutt

  2. Could Synthetic Biology transform all this rubbish (t rash)…

  3. …into these?

  4. Plastic of the Future: Poly-3-hydroxybutyrate PHB • A bacterial energy store • An alternative for petrochemical • Biocompatible PHB granules However… • Expensive • Produced from plant biomass

  5. Resources are lost in waste 700 million tons of trash is generated per year

  6. Human Solid Recovered Fuel is the target Practices • Human practice identified Solid Recovered Fuel (SRF) • SRF is a non-recyclable product of material recovery facilities It costs POWERDAY over $28 million a year to ship SRF for incineration. In August we visited POWERDAY the largest Materials Recovery Facility in SE England

  7. Human What is SRF made of? Practices 1/5 Plastics 4/5 Fibres Wood Simon Little, Paper Marketing Manager 320,000 tons per year

  8. Human The Right use for SRF Practices Consulted with the local government Greater London Authority at City Hall “Imperial’s research project… …sits well with achieving the Mayor’s vision” - Doug Simpson (Principal Policy and Programme officer, Waste and Energy Team)

  9. Our project is OUR AIM Human Practices driven Module 1: Making bioplastic from waste Module 2: Recycling bioplastics Module 1 Module 2 Waste to Bioplastic to Product

  10. How can we turn SRF into a recyclable resource? By engineering E. coli to: • Breakdown SRF to produce products and feedstock • Convert feedstock into bioplastic • Continually reprocess bioplastic Waste to Bioplastic to Product

  11. Module 1: Resource-full Waste Non-recyclable, mixed waste M1: Resource-full Waste Polyurethane Wood, paper Chemical degradation & fibres products M2: Plastic Fantastic Control phaZ1 lysate NATIVE PHB production P(3HB) degradation

  12. Module overview PHB

  13. Chassis choice- E.coli MG1655 Our chassis and parts: -GRAS: Generally regarded as safe - Already used in industry

  14. Our chassis thrives on waste The bacteria are still alive after 3 days No toxic effect LB Waste Incubated conditioned and plated media Growing our E.coli on PBS and waste And after 6 days!

  15. PHB production from waste Non-recyclable, mixed waste M1: Resource-full Waste Chemical Polyurethane Wood, paper products degradation & fibres M2: Plastic Fantastic Control phaZ1 lysate P(3HB) degradation PHB production

  16. Requirement for PHB production Our bacteria should: 1. Produce PHB 2. Produce PHB from the mixed waste M1 : Design Specifications Test Model

  17. Native operon, BBa_K934001 (Tokyo2012) Control phaCAB Nile red stains PHB Specifications Model Test M1: M1: M1 : Design Specifications Test Model

  18. Model-based flux optimisation 3 4 2 Metabolism 1 Glucose We created our models for the project from differential equations using MatLab M1 : Design Specifications Test Model

  19. Metabolic model of PHB production from glucose Glucose TCA Cycle Glycolysis Dixton et al., 2011 PHB synthesis Dixton et al., 2011 M1 : Design Specifications Test Model

  20. Model-based flux optimisation 3 4 2 Metabolism 1 Glucose M1 : Design Specifications Test Model

  21. Model-based flux optimisation 3 4 2 Metabolism 1 Glucose M1 : Design Specifications Test Model

  22. PHB production is sensitive to PhaB Sensitivity of [PHB] Time (minutes) M1 : Design Specifications Test Model

  23. PHB production is sensitive to PhaB 3 4 2 Metabolism 1 Glucose Our model for the project M1 : Design Specifications Test Model

  24. Increasing PhaB level: Effect on PHB production P3HB Concentration (g/L) M1 : Design Specifications Test Model

  25. Model Prediction J23104 increase PHB production rate Modelling data Constitutive Promoter, BBa_K1149052 Hybrid Promoter, BBa_K1149051 M1 : Design Specifications Test Model

  26. Key Result Hybrid operon produces much more PHB Native Hybrid M1: M1: M1 : Design Specifications Test Model

  27. Key Result: 60% of biomass is P3HB Imperial iGEM’s Native promoter Hybrid Promoter phaCAB phaCAB Dry Biomass (g) Native Hybrid 3.48 1.8 P3HB mass (g) 2.05 0.09 LB media volume (L) 1.2 1.2 Optimised Literature Imperial’s P(3HB) mass/dry mass 58.9 5 values are between cells (%) * 80% Tokyo Tech 2012 Highest P(3HB) 9.9 mass/dry mass cells(%) * 12x more PHB Imperial’s P(3HB) concentration 1.66 0.075 Tokyo Tech 2012 Highest P(3HB) 0.204 M1: M1: M1 : Design Specifications Test Model

  28. The hybrid operon produces more PHB than the constitutive Nile red stains PHB M1: M1: M1 : Design Specifications Test Model

  29. Key Result PHB production from waste PHB extracted from our bacteria grown on waste Monomer detection Adapted 3-HB medical assay kit that turns yellow when 3HB is present Yellow colour change Control. Remains when 3HB is present colourless M1: M1: M1 : Design Specifications Test Model

  30. Successes in Module 1 1. PHB production 2. Massively improved PHB production 3. PHB from waste To the best of our and our advisors knowledge, this is the first time anyone has made PHB from SRF using Synthetic Biology

  31. Module 2: Plastic Fantastic Non-recyclable, mixed waste M1: Resource-full Waste Polyurethane Wood, paper Chemical degradation & fibres products M2: Plastic Fantastic Control phaZ1 lysate PHB production P(3HB) degradation

  32. The first Synthetic Biology PHB recycling platform

  33. Requirement for PHB recycling PHB degradation Our bacteria should: 1. Express PHB-degrading enzymes 2. Be resistant to 3HB toxicity M2 : Design Specifications Test Model

  34. PHB degradation Phaz1 - BBa_K1149010 M1: M1: M2 : Design Specifications Test Model

  35. Modelling PHB depolymerisation Wet Lab data guided further model optimisation M2 : Design Specifications Test Model

  36. Purified PHB depolymerase is active PHB depolymerase 4-Nitrophenol para-Nitrophenyl butyrate PHB depolymerase (phaZ1) Empty vector Substrate alone Blank phaZ1 M2 : Design Specifications Test Model

  37. Key Result PHB depolymerase (phaZ1) clears PHB emulsions 3HB monomer detection Day 0 Day 1 Day 3 M2 : Design Specifications Test Model

  38. Testing for 3HB toxicity OD600 Empty Vector at 6h Control phaCAB No toxic effect until 10 mM of 3HB. In a bioreactor we would filter off 3HB to prevent it reaching this concentration. M2 : Design Specifications Test Model

  39. Requirement for PHB recycling Our bacteria should: 1. Internalise 3HB monomer 2. Metabolise 3HB 3. Make PHB M2 : Design Specifications Test Model

  40. PHB from 3HB Permease J23104 Permease 0034 M1: M1: M2 : Design Specifications Test Model

  41. Metabolic model showing the production of PHB from glucose TCA Cycle Glycolysis PHB synthesis M2 : Design Specifications Test Model

  42. Metabolic model predicts that E.coli will produce PHB from 3HB M2 : Design Specifications Test Model

  43. Key Result: Permease internalises 3HB Permease Increased growth on Empty vector 3HB with permease Control Decrease of 3HB Decrease of 3HB outside of the cell M2 : Design Specifications Test Model

  44. As you now know from M1, we can make PHB • phaZ1 PHB depolymerase • Permease • pha CAB operon Now we have all the working parts to make the first synthetic biology PHB recycling platform. M2 : Design Specifications Test Model

  45. Industrialisation

  46. Human Our system + cellulose hydrolysis will Practices allow industrial development Commercial Viability Requires: 150 - 300,000 tons of sugar 50,000 tons of PHB 390,625 - 781,000 tons SRF 2.11% SRF to PHB Meeting Stuart Dunbar- Principal Scientist

  47. Human The next step Practices Our bioreactor at Imperial College

  48. Human Local solutions and future vision Practices CAD design Find out more about M.A.P.L.E. in our booklets Appliances that transform domestic waste into new 3D printed bioplastic objects. What would you 3D print? Collaboration with

  49. Human Communicating our project Practices GetSynBio article BBC Radio 4 Interview with Adam Rutherford for the major national radio station Helping iGEM High school team Celebration of Science 2 million listeners in the UK

  50. Thanks to our advisors Richard Kelwick Paul Freemont Richard Kitney Alex Webb Kirsten Jensen Guy-Bart Stan Thanks to our sponsors Thanks to for this awesome experience

  51. Sisi Fan

  52. Our Achievement • Increased PHB production • Produced PHB from waste • The first ever Synthetic Biology PHB recycling platform • 15 Biobricks submitted Trash to Treasure

  53. M1: M1: M1 : Design Specifications Test Model

  54. M1: M1: M1 : Design Specifications Test Model

  55. Modelling PHB production from glucose M1: M1: M1 : Design Specifications Test Model 57

  56. Purification of PHB from cells using SRF as a carbon source media M1 : Design Specifications Test Model

  57. Hybrid produces more P3HB than J23104 EV Constitutive Hybrid Constitutive Hybrid EV M1 : Design Specifications Test Model
