S.E.T.F. Presentation www.barracudauae.com Vision Setting Goals - PowerPoint PPT Presentation

Dec 28, 2022 •333 likes •976 views

2019 - 2020 S.E.T.F. Presentation www.barracudauae.com Vision Setting Goals is Easy, Achieving Goals and Fulfilling Dreams Requires Focus, Motivation and Passion. Never Settle for Second Best. Keep Exploring, Dreaming, Succeeding, Keep

  1. 2019 - 2020 S.E.T.F. Presentation www.barracudauae.com

  2. Vision Setting Goals is Easy, Achieving Goals and Fulfilling Dreams Requires Focus, Motivation and Passion. Never Settle for Second Best. Keep Exploring, Dreaming, Succeeding, Keep Moving ,,, Our vision is to be the leading professional manufacture in the Gulf region providing a dry type cast coils transformers with unique attributes, characterized by quality products, services, and excellence that satisfies our customers.

  3. To Provide The Highest Quality Of Dry Type And Cast Coil Power Transformers Using The Latest Automated Machinery And Employing More Than 50 Technicians And Engineers To Give Our Customers The Best Technology In Dry-type Power Transformer And The Utmost In Quality And Reliability With Our Flagship SETF Warranty – 5 Years Warranty .

  4. Established in 1999, the Saudi Electrical Transformers Factory S.E.T.F. implanted its main manufacturing plants in the fourth zone of the industrial city of Jeddah. The original production line was designed to manufacture low voltage home appliance auto-transformers. Soon the outstanding quality of S.E.T.F. products imposed itself as a standard benchmark in the world of auto-transformers as it also gave the company momentum to expand into newer and more diversified products. The first 500 kVA low voltage power transformer to be manufactured by S.E.T.F. rolled out in 2000 as this marked the first in a series of expansions that led the company to become one of the major dry-type manufacturers in the MENA (Middle East, North Africa) region. The year 2001 marked yet another milestone for S.E.T.F. as the company designed, manufactured and delivered its first Medium Voltage, dry type power transformer. The particularity of this event was that for the first time a transformer was completely manufactured using local expertise and processes only. The tremendous success of this first order gave S.E.T.F. a place in the sun and ever since it has moved from strength to strength expanding its original production premises from the initial 4000 square meters to the actual 7500, with plans to open a second production plant of 15000 sqm by the end of 2019. The main drive behind this set of expansions was the outstanding The technological and quality features lined within S.E.T.F. products and the restless pursuit of perfection, be it in state of the art Company machineries, processes or even design practices. Today S.E.T.F. is a leader in the Gulf markets for dry type and epoxy resin transformers (medium and low voltage) combining years upon years of design expertise, exceptional processes and out of the box quality control and assuring techniques, keeping the customers a notch ahead of the competition.

  5. CEO ’ s Since the very beginning I recognize that my major investment are people, I have focused on attracting the Message very best professionals to S.E.T.F. and built the dynamic, competent, highly motivated, and reliable team. The power comes from inside, “ Any company is only as strong as the people who bring it to life ” . Companies do not service or solve problems, people do. Dr. Eng. Joseph N. Maalouli Behind S.E.T.F. success is our thriving team of professionals. We operate as S.E.T.F. team with one unifying vision ‘ Powering your future ” . We value our customers ’ needs and will go an extra mile and work shoulder to shoulder with them as S.E.T.F. team. We see our customers as partners and strive for them to see us not just as a service provider but as a reliable long-term partner. Our edibility and fast decision-making bring each conclusion, safely and within budge. We are fast and right solution. Process the implementing phase quickly, and react to changing needs. My message would be lacking without a look forward to the future. The efforts of our international operations continue to focus on expanding our marks. S.E.T.F. has a long-term international growth strategy, its goal is to grow and succeed in the international arena for clients ranging from traditional state owned utilities to independent power plant developers. J. N. Maalouli

  6. S.E.T .F . In Numbers OVER 1999 250 5 YEARS EST ABLISHED CLIENTS WARRANTY OVER MORE THAN OVER 7 25 10 100 ENGINEERS Years Employees SUPPLIERS Experience Production Range OVER OVER 900,000 From 10 VA to 5 MVA Skilled 40 Technician From 12 V up to 36 kV TRANSFORMERS SOLD

  7. S.E.T .F . ™ Business Units & Products The Saudi Electrical Transformers Factory grew and diversified with time to include at present time multiple business units. These business units take care of various production Power Transformers ranges as well as various services and after (Low Voltage) sales services. Presented in diagrammatically below, these units have been modeled and designed to keep a great flexibility and provide a very fast response to customer feedback, while Power Transformers keeping utmost quality and high production Control (Medium Voltage) capacity. Transformers Auto Transformers Isolation Transformers

  8. Why Why Hi Hire re Us ? Us ? Huge Knowledge Documentation and Strong Partnership Our Commitment to After sales services and Experience, Organization, We with Clients. Quality, Attention to We are in the have Strong System Detail is the Heart of Market Since of Document Everything We Do and 1999 Controlling quick delivery. And the most important thing !!!!

  9. We do not cheat …… .. Seems excellent?

  10. We do not cheat…….. Seems excellent? 0 50 F = 10 C ????

  11. Seems excellent?

  12. Replaced transformers COMPARING with S.E.T.F. dry type cast resin power transformer which is gratified with the highest tests performances level: E2,C2, F1 Environmental test E2 Nearly total condensation or heavy pollution or combination of both abnormal level of humidity up to 99% According to the new IEC 60076-16 Standard This transformer burned due to leakage of water into the transformer's chamber making a high level of humidity The transformer could not withstand the high humidity

  13. Replacing assemble Saudi Transformer manufactured outside of Saudia Another transformer located in Umm Al Qura university burned due to the crack in the RESIN. we also discovered that the transformer is made in Italy and mentioned as been made in SAUDIA S.E.T.F. dry type cast resin power transformers also prove the high grade …… .. design and manufacture quality to guarantee full safety for people & all type of buildings in case of fire. Fire withstand F1 Self-extinguishing transformer fire

  14. SETF Product

  15. S.E.T.F. Product Technical Overview LV & MV COIL WINDING LV COIL WINDING

  16. S.E.T.F. Product Technical Overview LV & MV COIL WINDING LV & MV COIL WINDING

  17. S.E.T.F. Product Technical Overview LV & MV COIL WINDING LV & MV COIL WINDING

  18. S.E.T.F. Product Technical Overview CASTING AND POLYMERIZATION CASTING AND POLYMERIZATION

  19. S.E.T.F. Product Technical Overview CASTING AND POLYMERIZATION

  20. S.E.T.F. Product Technical Overview CASTING AND POLYMERIZATION CASTING AND POLYMERIZATION

  21. S.E.T.F. Product Technical Overview ASSEMBLY

  22. S.E.T.F. Product Technical Overview ELECTROSTATIC PAINTING

  23. S.E.T.F. Product Technical Overview RESEARCH AND DEVELOPMENT

  24. S.E.T.F. Product Technical Overview TESTING

  25. S.E.T.F. Product Technical Overview MAINTENANCE AND STORAGE

  26. Some of our major projects

  27. Projects (Airports) King Fahd International Airport, King Abdulaziz International Airport, Dammam Jeddah

  28. Project (Al Madina Al Mounawara) King Abdullah Waqf Project Client Saudi Oger Transformer power 1600 kVA Rated voltage 13.8/400-231V Location Madinah, KSA

  29. Projects (Aramco, offshore) SOUTH TERMINAL OFFSHORE FACILITY, Yanbu

  30. Projects (Aramco facilities) Aramco facilities

  31. Projects (Aramco factories) Aramco factories

  32. Project (Banks) SAMBA Headquarter Client Siemens Limited (Al Arabia Equipment Co.) Transformer power 1600 kVA Rated voltage 13.8/400/231 V Location Riyadh, KSA

  33. Projects (Chemicals) Sumitomo Chemical, Rabigh

  34. Project (Cities) King Abdullah Financial District Client Al Fanar Co., Saudi Binladin Group/Cap France BAT Transformer power 250,1000,1250,1600,2000 kVA Rated voltage 13.8/400V Location Riyadh, KSA

  35. Project (Cities) King Abdullah Economic City Client SAUDI BIN LADEN GROUP Transformer power 1000,1500 kVA Rated voltage 13.8 KV - 220/127 V Location Makkah, KSA

  36. Projects (Exhibitions) Riyadh Exhibition Center, Riyadh

  37. Projects (Hospitals) King Hamad General Hospital, Manama Al-Hammadi Hospital, Riyadh Madinah Cardiac Center, Madinah Doha-Hospital , Doha

  38. Project (Hotels) Dar Al Tawhid Intercontinental Client Dar Al Tawhid Intercontinental Transformer power 200 kVA 13.8 KV - 380 V Rated voltage Location Makkah, KSA

  39. Projects (Industrial facilities) United Sugar Factory , Jeddah Steel Factory, Rabigh Rabigh Conversion Industrial Park Dev. Saudi Cable Factory Project, Rabigh

  40. Project (Makkah Al Moukarrama) King Abdul Aziz Endowment Project Chiller Plant Client SAUDI BIN LADEN GROUP Transformer power 2500 kVA, 13.8/11 kV Rated voltage 13.8/11 kV Location Makkah, KSA

  41. Projects (Ministries) Ministry Of Defense, Riyadh Ministry of Higher Education, Riyadh
