REMOTE MONITORING OF EMERGENCY POWER SYSTEMS Senior Design Team - PowerPoint PPT Presentation

REMOTE MONITORING OF EMERGENCY POWER SYSTEMS Senior Design Team 1905 AG AGEN ENDA DA 01 Collaborators 02 Summary and Background 03 Technical Purpose 04 Project Phases and Budget SLIDE / COLLABORATORS Senior Design Team 1905 01


  1. REMOTE MONITORING OF EMERGENCY POWER SYSTEMS Senior Design Team 1905

  2. AG AGEN ENDA DA 01 Collaborators 02 Summary and Background 03 Technical Purpose 04 Project Phases and Budget SLIDE /

  3. COLLABORATORS Senior Design Team 1905 01 SLIDE /

  4. OUR TEAM LAYOUT ECE TEAM Collaborators • CSE team will be working on designing the website • ECE is designing the webserver Allysa Garcia Andrew Philippi Dinelson Rosario module CSE TEAM • The team advisors are Helena Silva and Song Han • Sponsor is Bill Schneeloch • Meetings between teamshappen jointly and separately Rania Chowdhury William Reid Emil Abraham Evan Langlais SLIDE / 4

  5. SUMMARY & BACKGROUND Senior Design Team 1905 02 SLIDE /

  6. BACKGROUND Kinsley Group is a leading energy solution supplier • They are a Kohler product distributer • Provide generator instillation, maintenance, and generator • rental services UConn uses Kinsley generators • The generators use Decision-Maker Controllers • They currently use direct connections to monitor generators • status SLIDE / 6

  7. Kinsley wants a way to for their • technicians to remotely check the status of their generators. We are developing a module which provides • an embedded Webserver A website will be designed to present • information from the generator Our project uses the DM-550 • This controller contains a Modbus output • SUMMARY Webserver will accept HTTP request • SLIDE / 7

  8. TECHNICAL PURPOSE Senior Design Team 1905 03 SLIDE /

  9. TECHNICAL PURPOSE Solutions PROJECT WEBSITE MODULE OVERVIEW Two ways we can conduct our Website must be a proper Converts Modbus data into project representation of all the meaningful HTTP requests and 1. Virtual Cable controllers information sends to an online webserver 2. Data Ingest Analytics Microprocessor • • Security Modbus adapter • • History • SLIDE /

  10. VIRTUAL CABLE Key Concepts Generator hardware listens and • responds to requests of its data API communicates with generator • hardware for data Website retrieves data from API and • displays it when it becomes available SLIDE / 10

  11. DATA INGEST MODEL Key Concepts Generator hardware is simple and • pushes data periodically Intake server processes and saves data • from all generators Website and other analytics products • interface with data 11 SLIDE /

  12. PROJECT OVERVIEW Pros Data Ingest Virtual Cable Little overhead and maintenance Extremely scalable • • Inexpensive to implement Resilient and highly redundant • • Enables all basic time-scale analytics Enables both real time and big data analytics • • SLIDE / 12

  13. PROJECT OVERVIEW Cons Virtual Cable Data Ingest Difficulty scaling above a certain point Requires cloud provider (AWS, Azure, etc) • • Reliant on generator hardware being Under threshold far more costly • • operational More maintenance and overhead • Responsiveness limited by slowest • connection SLIDE / 13

  14. WEBSITE Experimental Work SEARCH Log in system is implemented • If multiple generators are in use, • information for the specific one is pulled by using the serial search bar Will display data based on the event • codes listed in the DM-550 manual Analytics can be implemented to show • data trends from the generator LOGIN SLIDE / 14

  15. WEBSITE Simulation BIG DATA ANALYTICS Big data analytics can give predictive • figures of the generator Real time analytics provides immediate • information on the generator Red = Bad • Yellow = Warning • Green = Functioning • REAL TIME ANALYTICS Wireframe and mock inputs used for • simulation 15 SLIDE /

  16. HARDWARE Experimental Work Raspberry Pi to Modbus RS-485 Arduino Shield Port Using a Raspberry Pi microprocessor to • convert the Modbus RS-485 signals to HTTP requests Power is supplied through the USB • connection on the Raspberry Pi for the proof of concept Ethernet Port Ethernet connection provides access to • upload converted HTTP to API Raspberry Pi webserver Microprocessor SLIDE / 16

  17. HARDWARE Simulation Connecting device to the DM-550 • Using the given debug software • provided by Kinsley to see how information uploads to website Planning on using C++ for the • microcontroller. By using this our simulation will be based on the outputs 17 SLIDE /

  18. HARDWARE Quantitative Information The information contained in these • registers is the data being sent to the API server Our device (master) needs to be able to • communicate with the controller (slave) to gather information from these registers 18 SLIDE /

  19. PROJECT PHASES & BUDGET Senior Design Team 1905 04 SLIDE /

  20. PROJECT PHASES Project Management 01 02 03 04 A basic overview of our phase oriented process: Research Design Build Test 1. Research Gather the following resources: • Designed block diagrams • Program microcontroller • Use the controller to run 2. Design • DM-550 manual • Create flow charts • 3D print module case commands through our • Modbus to Ethernet converter • Design website wireframe • Adding website features webserver 3. Build manual • Building webserver proof of • User access • Stress testing • Microprocessor webservers concept • User support • Documentation 4. Test • Modbus communication • History • Debugging cod e protocol • Analytics SLIDE / 20

  21. TIMELINE Project Management PHASE 03 03 PHASE 01 01 Build Research Phase 1: September – October Phase 2: start October – November 2018 Phase 3: December – January PHASE 02 02 Design SLIDE / 20

  22. TIMELINE Project Management PHASE 04 Phase 4: Test January – April DEMO DAY Demo Day marks the end of senior design End Deliverables include: • Demonstrating knowledge on 2019 project management and development • Implementation of prototype SLIDE / 22

  23. BUDGET Project Management Items Provided Unit Price Raspberry Pi No $37.30 26% RP to Arduino Shield No $16.99 74% Arduino Modbus Kit No $15.95 DM-550 Yes $0.00 Modbus to Ethernet Yes $0.00 Used Converter Un-used Controller Debug Yes $0.00 Total Allocated: $1000 Software Ethernet Cable No $5.99 Modbus RS-485 Unsure $184.08 connection cable TOTAL: $250.31 SLIDE /

  24. THANK YOU CONTACT Allysa Garcia allysa.garcia@uconn.edu Andrew Philippi andrew.philippi@uconn.edu Dinelson Rosario dinelson.rosario@uconn.edu Senior Design Website http://ecesd.engr.uconn.edu/ecesd1905/ SLIDE /
