Time - Aware Test Suite Prioritization Kristen R. Walcott, Gregory M. Kapfhammer, Mary Lou S offa Robert S . Roos University of Virginia Allegheny College International S ymposium on S oftware Testing and Analysis Portland, Maine July 17 - 20, 2006

Regression Testing � S oftware is constantly modified � Bug fixes � Addition of functionality � After making changes, test using regression test suite � Provides confidence in correct modifications � Detects new faults � High cost of regression testing � More modifications › larger test suite � May execute for days, weeks, or months � Testing costs are very high

Reducing the Cost � Cost - saving techniques � S election: Use a subset of the test cases � Prioritization: Reorder the test cases � Prioritization methods � Initial ordering � Reverse ordering � Random ordering � Based on fault detection ability

Ordering Tests with Fault Detection � Idea: First run the test cases that will find faults first � Complications: � Different tests may find the same fault � Do not know which tests will find faults � Use coverage to estimate fault finding ability

Prioritization Example Prioritized Test S uite (with some fault information) T2 T1 T4 T5 T6 T3 1 fault 3 faults 3 faults 3 faults 7 faults 2 faults 1 min. 9 min. 4 min. 4 min. 4 min. 3 min. Faults found / minute 1.0 0.778 0.75 0.75 0.75 0.667 • Retesting generally has a time budget • Is this prioritization best when the time budget is considered? Contribution: A test prioritization technique that intelligently incorporates a time budget

Fault Aware Prioritization FAULTS/ f 1 f 2 f 3 f 4 f 5 f 6 f 7 f 8 TEST CASE X X X X X X X T1 X T2 X X T3 X X X T4 X X X T5 X X X T6 TESTING GOAL: Find as many faults as soon as possible

Time Budget: 12 minutes T1 f 1 f 2 f 4 f 5 f 6 f 7 f 8 T2 f 1 T3 f 1 f 5 T4 f 2 f 3 f 7 T5 f 4 f 6 f 8 T6 f 2 f 4 f 6 Fault - based Prioritization T4 T5 T6 T1 T3 T2 3 faults 3 faults 3 faults 7 faults 2 faults 1 fault 9 min. 4 min. 4 min. 4 min. 3 min. 1 min. Finds 7 unique faults in 9 minutes

Time Budget: 12 minutes T1 f 1 f 2 f 4 f 5 f 6 f 7 f 8 T2 f 1 T3 f 1 f 5 T4 f 2 f 3 f 7 T5 f 4 f 6 f 8 T6 f 2 f 4 f 6 Naïve Time - based Prioritization T2 T3 T5 T1 T4 T6 1 fault 2 faults 3 faults 3 faults 3 faults 7 faults 1 min. 3 min. 4 min. 4 min. 4 min. 9 min. Finds 8 unique faults in 12 minutes

Time Budget: 12 minutes T1 f 1 f 2 f 4 f 5 f 6 f 7 f 8 T2 f 1 T3 f 1 f 5 T4 f 2 f 3 f 7 T5 f 4 f 6 f 8 T6 f 2 f 4 f 6 Average - based Prioritization T2 T1 T5 T3 T4 T6 1 fault 7 faults 3 faults 3 faults 3 faults 2 faults 1 min. 9 min. 4 min. 4 min. 4 min. 3 min. Finds 7 unique faults in 10 minutes

Time Budget: 12 minutes T1 f 1 f 2 f 4 f 5 f 6 f 7 f 8 T2 f 1 T3 f 1 f 5 T4 f 2 f 3 f 7 T5 f 4 f 6 f 8 T6 f 2 f 4 f 6 Intelligent Time - Aware Prioritization T5 T4 T1 T6 T3 T2 3 faults 3 faults 2 faults 7 faults 1 fault 3 faults 4 min. 4 min. 3 min. 9 min. 1 min. 4 min. Finds 8 unique faults in 11 minutes

Time - Aware Prioritization � Time - aware prioritization (TAP) combines: � Fault finding ability (overlapping coverage) � Test execution time � Time constrained test suite prioritization problem 0/ 1 knapsack problem � Use genetic algorithm heuristic search technique � Genetic algorithm � Fitness ideally calculated based on faults � A fault cannot be found if code is not covered � Fitness function based on test suite and test case code coverage and execution time

Prioritization Infrastructure Genetic algorithm Program Selection Create initial Number tuples/iteration Tuple 1 Tuple 2 population Maximum # of iterations Percent of test suite Crossover execution time Calculate Crossover probability fitnesses Mutation probability Addition Deletion Mutation Addition probability Deletion probability Select Add new Test adequacy criteria Best tuples Program coverage weight Next Final test Test suite generation tuple

Fitness Function Secondary Fitness Primary Fitness Use coverage information to estimate � “ goodness” of test case Test Suite 1: 70% coverage Preferred! T2: 80% T1: 40% Block coverage � Test Suite 2: 40% coverage T1: 40% T2: 80% Method coverage � Fitness function components � Overall coverage 1. Cumulative coverage of test tuple 2. Time required by test tuple 3. If over time budget, receives very low fitness �

Creation of New Test Tuples Crossover • Vary test tuples using recombination • If recombination causes duplicate test case execution, replace duplicate test case with one that is unused

Creation of New Test Tuples � Mutation � For each test case in tuple � S elect random number, R � If R < mutation probability, replace test case � Addition - Append random unused test case � Deletion - Remove random test case

Experimentation Goals � Analyze trends in average percent of faults detected (APFD) � Determine if time - aware prioritizations outperform selected set of other prioritizations � Identify time and space overheads

Experiment Design � GNU/ Linux workstations � 1.8 GHz Intel Pentium 4 � 1 GB main memory � JUnit test cases used for prioritization � Case study applications � Gradebook � JDepend � Faults seeded into applications � 25, 50, and 75 percent of 40 errors

Evaluation Metrics � Average percent of faults detected (APFD) T = test tuple g = number of faults in program under test n = number of test cases reveal(i, T) = position of the first test in T that exposes fault i ∑ g reveal i T ( , ) 1 = = − + i 1 APFD T P ( , ) 1 ng 2 n � Peak memory usage � User and system time

TAP APFD Values Block coverage preferred: 11% better in Gradebook 13% better in JDepend

TAP Time Overheads More generations with smaller populations: • Took less time • Same quality results

Gradebook: Intelligent vs Random

JDepend: Intelligent vs. Random

Other Prioritizations � Random prioritizations redistribute fault - revealing test cases � Other prioritizations � Initial ordering � Reverse ordering � Fault - aware � Impossible to implement � Good watermark for comparison

Gradebook: Alternative Prioritizations % total Fault # Faults Initial Reverse TAP time aware 0.25 10 - 0.6 - 0.2 0.43 0.7 0.25 20 - 0.9 - 0.2 0.41 0.7 0.25 30 - 0.9 - 0.0 0.46 0.5 0.50 10 - 0.04 0.1 0.74 0.9 0.50 20 - 0.2 0.2 0.74 0.9 0.50 30 - 0.3 0.3 0.72 0.8 0.75 10 0.3 0.5 0.73 0.9 0.75 20 0.1 0.4 0.71 0.9 0.75 30 0.04 0.5 0.70 0.9 • Time - aware prioritization up to 120% better than other prioritizations

Conclusions and Future Work � Analyzes a test prioritization technique that accounts for a testing time budget � Time intelligent prioritization had up to 120% APFD improvement over other techniques � Future Work � Make fitness calculation faster � Distribute fitness function calculation � Exploit test execution histories � Create termination condition based on prior prioritizations � Analyze other search heuristics

Thank you! Time - Aware Prioritization (TAP) Research: � http:/ / www.cs.virginia.edu/ ~krw7c/ TimeAwarePrioritization.htm
