Raw materials for Agricus compost Ralph Noble, East Malling Research, UK RAW MATERIALS FOR AGARICUS COMPOST Straw types and analysis Alternative carbon sources Poultry manure and other nitrogen sources Recycled water Gypsum

slide-1
SLIDE 1

Raw materials for Agricus compost

Ralph Noble, East Malling Research, UK

slide-2
SLIDE 2

RAW MATERIALS FOR AGARICUS COMPOST

  • Straw types and analysis
  • Alternative carbon sources
  • Poultry manure and other nitrogen sources
  • Recycled water
  • Gypsum
  • Organic mushroom compost
  • Effects on mushroom quality and moulds
slide-3
SLIDE 3

STRAW PROBLEMS

  • Cost – alternative uses, e.g. energy, feed
  • Availability – local and every year?
  • High moisture content
  • Variability in composting and cropping
  • Change in properties during storage
slide-4
SLIDE 4

Linseed Barley Wheat Rye

slide-5
SLIDE 5

Rape straw

slide-6
SLIDE 6

Cotton straw

slide-7
SLIDE 7

Rice straw

slide-8
SLIDE 8
slide-9
SLIDE 9

Wheat straw stem

slide-10
SLIDE 10

Wheat straw Barley straw

slide-11
SLIDE 11

Wheat straw

slide-12
SLIDE 12

Barley straw

slide-13
SLIDE 13

WHEAT STRAW VARIABLES

  • Cultivar, spring or winter wheat
  • Growing site, soil, climate
  • Fertiliser (Nitrogen) applications
  • Fungicides and plant growth regulators
  • Harvesting method and conditions
  • Storage duration and conditions
slide-14
SLIDE 14

STRAW ANALYSIS METHODS

Information about organic polymers (lignin, cellulose, hemicellulose)

  • Vis-near infrared spectroscopy (Vis-NIR)
  • Derivative Thermogravimetry (DTG)
slide-15
SLIDE 15

Transformed vis-NIR spectra of straw showing variability in composition

Moisture peaks Nitrogen Cellulose

2266

Oil 2072 Nitrogen

1514

Aromatics

slide-16
SLIDE 16

Overlay of DTG curves of straw samples

mg

  • 0. 0
  • 0. 5
  • 1. 0
  • 1. 5
  • 2. 0
  • 2. 5
  • 3. 0

mi n °C 50 100 15 0 2 00 250 30 0 35 0 40 0 45 0 50 0 550 2 4 6 8 10 12 14 16 18 2 0 22 24 26 \M Gst -2- 1 MG st- 2-1 , 3 .08 50 mg \M Gst -3- 2 MG st- 3-2 , 3 . 09 80 mg \S ola n w hea t s t raw-3 So lan wh eat st r aw-3, 3 .02 50 mg mgmin^-1

  • 0.8
  • 0.6
  • 0.4
  • 0.2
  • 0.0

mi n 2 4 6 8 10 12 14 16 18 2 0 22 24 26 mg min^-2

  • 2

2 mi n 2 4 6 8 10 12 14 16 18 2 0 22 24 26

Cellulose Lignin fraction Hemicellulose (structural)

Hemicellulose amorphous

slide-17
SLIDE 17

STRAW ANALYSIS METHODS

Chemical constituents and residues

  • Gas Chromatography-Mass Spectrometry (GC-MS)
  • Mineral analysis (N, P, K etc)
  • Soluble carbohydrates and polyphenols
  • Proteins, lipids
  • pH and electrical conductivity
slide-18
SLIDE 18

Cultivar Site Fenpropimorph Tebuconazole mg/kg Claire Cross 0.09 0.09 Claire DownP 0.01 0.08 Claire Lim 0.12 0.11 Malacca Cross 0.09 0.09 Malacca DownP 0.01 0.08 Malacca Lim 0.12 0.03 Richmond Cross 0.11 0.22 Richmond DownP 0.01 0.09 Richmond Lim 0.09 0.13 Tanker Cross 0.08 Tanker DownP 0.06 Tanker Lim 0.04 0.04

Fungicide residues on wheat straw

slide-19
SLIDE 19

Cultivar Chlormequat, mg/kg Site Kirton Welles Cross DownP Lim Axona 1.3 Hereward 7.8 Tanker 1.7 1.3 0.7 1.0 Richmond 4.8 2.2 0.6 0.5 Claire 1.3 0.5 1.2 Malacca 1.5 0.4 1.2

Chlormequat residues on wheat straw

slide-20
SLIDE 20

DIGESTABILITY

Digestability

  • Enzyme digestibility (Pepsin, Pentopan, Cellulase)

(dry matter digestability and hemicellulose digestability)

  • Neutral detergent fibre

(cellulose, hemicellulose, lignin etc)

slide-21
SLIDE 21
  • Water retention properties

(moisture content and retention)

  • Mechanical properties

(Tensile strength, stiffness, dynamic modulus)

slide-22
SLIDE 22

Mechanical Tests on Straw

Instron tensile tests - stress, strain and elastic modulus

slide-23
SLIDE 23

Straw composting experiments

slide-24
SLIDE 24

Strawy Degraded

slide-25
SLIDE 25
slide-26
SLIDE 26

Effect of wheat cultivar on mushroom yield from windrow composts

50 100 150 200 250 300 Hereward Tanker Richmond Malacca Axona cultivar yield, kg/ tonne compost winter spring

slide-27
SLIDE 27

Straw of different types - New and old

slide-28
SLIDE 28
slide-29
SLIDE 29
  • Fig. 8 Effect of wheat cultivar and site on mushroom yield

in flask experiment composts

200 400 600 800 1000 M a l a c c a R i c h m

  • n

d T a n k e r C l a i r e Yield, g/kg compost dry weight Limnavady Crossnacreevy Downpatrick Warwick HRI wheat cultivar

Effects of wheat cultivar and growing site

  • n mushroom yield
slide-30
SLIDE 30

Figure 4 Effect of wheat cultivar and site on % dry matter and dry matter digestibility 78 80 82 84 86 88 90 92 94 96 Malacca Richmond Tanker

% Dry Matter

18 20 22 24 26 28 30 32 Malacca Richmond Tanker

% Dry Matter Digestibility

Limavady Crossnacreevy Downpatrick Warwick HRI Wheat cultivar

slide-31
SLIDE 31

WHEAT STRAW ANALYSIS AND MUSHROOM CROPPING

  • 20% mushroom yield difference between ‘best’ and ‘worst’

straw batches

  • Growing site, N fertiliser and storage influenced wheat

straw properties and mushroom cropping

  • Barley, rape and rye straw can all be used

(at least 25%)

slide-32
SLIDE 32

WHEAT STRAW ANALYSIS AND MUSHROOM CROPPING

  • Wheat straw cultivar only had a small influence on straw

properties and mushroom cropping

  • No effects of fungicide (tebuconazle) or plant growth

regulator residues on spawn-run or yield

  • No relationship between mechanical properties and

mushroom yield

slide-33
SLIDE 33

WHEAT STRAW ANALYSIS AND MUSHROOM CROPPING

  • Straw with a high

* dry matter * dry matter digestability (pepsin and cellulase) * ratio of cellulose and hemi-cellulose to lignin (DTG) produced a higher mushroom yield than straw with low values

slide-34
SLIDE 34

STRAW QUESTIONS AND FUTURE

  • Is wheat straw best or should other straw types or blends

be used?

  • Is horse manure better than only straw?
  • What are the key properties of straw?
  • How can we adapt the composting process according to

straw analysis?

slide-35
SLIDE 35

ALTERNATIVE MATERIALS PROBLEMS

  • Cost – alternative uses, e.g. energy, feed
  • Local availability year round
  • High water content, low available C or N
  • Variability in composting and cropping
  • Change in properties during storage
  • EU waste legislation
slide-36
SLIDE 36

Tomato, pepper and cucumber haulms

slide-37
SLIDE 37

Vegetable wastes

slide-38
SLIDE 38
slide-39
SLIDE 39
slide-40
SLIDE 40
slide-41
SLIDE 41

Separated spent mushroom compost

slide-42
SLIDE 42

Separated spent mushroom compost

slide-43
SLIDE 43

Broiler poultry manure

slide-44
SLIDE 44
slide-45
SLIDE 45

Recycled ‘goody’ water

slide-46
SLIDE 46
slide-47
SLIDE 47
  • Fig. 37 Relationship between electrical conductivity and dry

matter content of goody water samples y = 1.0849x + 0.2368 R2 = 0.928 5 10 15 20 25 30 35 5 10 15 20 25 30 EC ms/cm dry matter, %

slide-48
SLIDE 48
slide-49
SLIDE 49

Pig manure and slurry Cattle slurry Fish by-products Shellfish wastes Wool waste

slide-50
SLIDE 50

Cocoa meal

slide-51
SLIDE 51

Anaerobic digestion

slide-52
SLIDE 52

PAS 110:2010 Specifi cation for whole digestate, separated liquor and separated fi bre derived from the anaerobic digestion of source-segregated biodegradable materials

slide-53
SLIDE 53

Ammonium sulphate

slide-54
SLIDE 54
slide-55
SLIDE 55

50 100 150 200 250 300

wheat barley rye +carpet +SMC + veg inorgan.

Yield, g/kg compost fresh wt. Bench Large

LSD (P = 0.05) 100% Straw/poultry manure 75% Straw/poultry manure

+wool

slide-56
SLIDE 56

Effects of compost ingredients on mushroom quality

  • Shelf life
  • Dry matter content
  • Firmness/ Density
  • Whiteness/ Bruisability
  • Flavour
slide-57
SLIDE 57

Trichoderma aggressivum 23443B

slide-58
SLIDE 58

Second flush

slide-59
SLIDE 59

Effect of moulds on mushroom yield in different composts

100 200 300 400 500 600 Normal Dry Wet Mature Strawy Yield, g/kg Control Penicillium Trichoderma

slide-60
SLIDE 60

Agricultural gypsum

citric acid by-product gypsum

No gypsum

slide-61
SLIDE 61

PAS 109:2013

Specification for the production of reprocessed gypsum from waste plasterboard

slide-62
SLIDE 62

ALTERNATIVE CARBON, NITROGEN AND GYPSUM SOURCES

  • Glasshouse and vegetable wastes, separated SMC and

animal manures/ by-products usable

  • Digestates are a possible ingredient
  • Plasterboard and citric acid gypsum,

ammonium sulphate + chalk can be used

  • EU legislation interferes with some materials
  • Effects of raw materials on yield, quality and compost

moulds need to be considered

slide-63
SLIDE 63

ALTERNATIVE MATERIALS – QUESTIONS AND FUTURE

  • Do we need alternatives to straw, horse manure and

poultry manure?

  • What are the implications for organic compost?
  • EU waste legislation – collaboration?
  • Is further research needed?
slide-64
SLIDE 64

Raw materials for Agricus compost

Ralph Noble, East Malling Research, UK
