Puck XT Puck comparison Puck XT Previous Puck 16mm 15mm deep - PowerPoint PPT Presentation

Puck XT Puck comparison Puck XT Previous Puck 16mm 15mm deep 18mm 15mm deep IP66 IP66 IK10 IK10 18mm For curved & flat rails For curved & flat rails 5 Distributions achieved with reflector


  1. Puck XT

  2. Puck comparison Puck XT Previous Puck • 16mm Ø 15mm deep • 18mm Ø 15mm deep • IP66 • IP66 • IK10 • IK10 18mmØ • For curved & flat rails • For curved & flat rails • 5 Distributions achieved with reflector • 5 Distributions achieved with lens • 5 bodies for the 5 distributions • 2 Bodies and 2 optics • Symmetric version usually at 30 o can cause glare • Symmetric version can be under rail reducing glare • Asymmetric version for under rail not efficient • Asymmetric version for under rail very efficient • Greater spacings for same light level • 88 Llm/W • 124 Llm/W • ~30% less power • 3000 & 4000K • 3000 & 4000K

  3. Puck XT Design • Goal was to improve on what is a great product • Increase efficiency • Improve Glare • Reduce the number of parts to create the same range • Potential to use the product other than in handrails

  4. Puck XT Design

  5. Puck XT Alignment • A new insertion tool has been developed which makes it easy to install the new Puck and allows the installer to know where to position it so that the beam is in the correct direction. • This is achieved by missing one of the holes & pins in the new tool • The pins are smaller than the old Puck making it far more difficult to remove without the proper tool – increased vandal resistance.

  6. Puck XT benefit over Puck 1 • Previous puck was positioned at 30 o to achieve good spread of light • This meant that the light source was seen and could be viewed as glare • Puck XT can be positioned at the bottom of the rail and still achieve the same lighting results without glare

  7. Round Handrail Flat Walkway One-sided vs Asy XT Lux Levels 0 Current Gen. Puck XT 10 Spacings Avg. lx. u0 Avg. lx. u0 20 400 mm 163 lx 0.668 211 lx 0.605 Current Gen – One-Sided 30 600 mm 109 lx 0.665 141 lx 0.593 40 800 mm 82 lx 0.659 106 lx 0.593 50 1000 mm 65 lx 0.666 85 lx 0.582 60 1200 mm 54 lx 0.646 70 lx 0.552 70 1500 mm 44 lx 0.555 56 lx 0.461 80 2000 mm 33 lx 0.300 42 lx 0.304 2500 mm 25 lx 0.089 32 lx 0.214 Puck XT - Asy

  8. Round Handrail Stairway One-sided vs Asy XT Lux Levels 0 Current Gen. Puck XT 10 20 Spacings Avg. lx. u0 Avg. lx. u0 Current Gen – One-Sided 30 400 mm 147 lx 0.330 181 lx 0.236 40 600 mm 98 lx 0.341 121 lx 0.229 50 800 mm 73 lx 0.244 90 lx 0.137 60 1000 mm 59 lx 0.276 72 lx 0.155 70 1200 mm 49 lx 0.331 60 lx 0.227 80 1500 mm 40 lx 0.298 49 lx 0.227 2000 mm 32 lx 0.077 39 lx 0.191 2500 mm 26 lx 0.012 31 lx 0.142 Puck XT - Asy

  9. Round Handrail Flat Walkway One-sided Beam Lux Levels Current Gen. Puck XT 0 Spacings Avg. lx. u0 Avg. lx. u0 10 400 mm 163 lx 0.668 196 lx 0.697 20 600 mm 109 lx 0.665 131 lx 0.684 Current Gen 30 800 mm 82 lx 0.659 98 lx 0.651 40 1000 mm 65 lx 0.666 79 lx 0.614 50 1200 mm 54 lx 0.646 65 lx 0.614 60 1500 mm 44 lx 0.555 52 lx 0.627 70 2000 mm 33 lx 0.300 39 lx 0.601 80 2500 mm 25 lx 0.089 31 lx 0.516 Puck XT

  10. Round Handrail Flat Walkway Asymmetric Lux Levels Current Gen. Puck XT 0 Spacings Avg. lx. u0 Avg. lx. u0 10 400 mm 149 lx 0.503 211 lx 0.605 20 600 mm 100 lx 0.501 141 lx 0.593 Current Gen 30 800 mm 74 lx 0.486 106 lx 0.593 40 1000 mm 60 lx 0.490 85 lx 0.582 50 1200 mm 50 lx 0.475 70 lx 0.552 60 1500 mm 40 lx 0.408 56 lx 0.461 70 2000 mm 30 lx 0.220 42 lx 0.304 80 2500 mm 22 lx 0.115 32 lx 0.214 Puck XT

  11. Round Handrail Flat Walkway Double-sided Lux Levels Current Gen. Puck XT 0 Spacings Avg. lx. u0 Avg. lx. u0 10 400 mm 119 lx 0.244 112 lx 0.616 20 600 mm 79 lx 0.410 75 lx 0.623 Current Gen 30 800 mm 59 lx 0.411 56 lx 0.614 40 1000 mm 48 lx 0.405 45 lx 0.566 50 1200 mm 40 lx 0.417 38 lx 0.518 60 1500 mm 32 lx 0.367 30 lx 0.453 70 2000 mm 24 lx 0.183 23 lx 0.328 80 2500 mm 18 lx 0.087 17 lx 0.222 Puck XT

  12. Round Handrail Stairway One-sided Beam Lux Levels Current Gen. Puck XT 0 Spacings Avg. lx. u0 Avg. lx. u0 10 400 mm 147 lx 0.330 176 lx 0.296 20 600 mm 98 lx 0.341 118 lx 0.305 Current Gen 30 800 mm 73 lx 0.244 88 lx 0.223 40 1000 mm 59 lx 0.276 71 lx 0.242 50 1200 mm 49 lx 0.331 59 lx 0.311 60 1500 mm 40 lx 0.298 48 lx 0.326 70 2000 mm 32 lx 0.077 37 lx 0.309 80 2500 mm 26 lx 0.012 30 lx 0.260 Puck XT

  13. Round Handrail Stairway Asymmetric Lux Levels Current Gen. Puck XT 0 Spacings Avg. lx. u0 Avg. lx. u0 10 400 mm 115 lx 0.187 181 lx 0.236 20 600 mm 77 lx 0.184 121 lx 0.229 Current Gen 30 800 mm 57 lx 0.110 90 lx 0.137 40 1000 mm 46 lx 0.137 72 lx 0.155 50 1200 mm 37 lx 0.115 60 lx 0.227 60 1500 mm 31 lx 0.076 49 lx 0.227 70 2000 mm 25 lx 0.031 39 lx 0.191 80 2500 mm 20 lx 0.012 31 lx 0.142 Puck XT

  14. Round Handrail Stairway Double-sided Lux Levels Current Gen. Puck XT 0 Spacings Avg. lx. u0 Avg. lx. u0 10 400 mm 111 lx 0.207 112 lx 0.456 20 600 mm 74 lx 0.206 75 lx 0.447 Current Gen 30 800 mm 56 lx 0.142 56 lx 0.288 40 1000 mm 45 lx 0.160 45 lx 0.353 50 1200 mm 37 lx 0.109 37 lx 0.323 60 1500 mm 30 lx 0.047 30 lx 0.234 70 2000 mm 24 lx 0.020 25 lx 0.102 80 2500 mm 20 lx 0.012 20 lx 0.044 Puck XT

  15. Puck XT Collar • We have been asked in the past to use the Puck in canopies and in situations where the back is exposed. • It was not easy to double insulate the 2 wires • A collar has been developed as an accessory that screws into the rear of the Puck XT housing allowing a heat shrink sleeve to be applied

  16. Catalogue No. Mount Optic Lumens Colour Temperature MP1201501-70-30 Curved Standard 169 3000K MP1201501-70-40 Curved Standard 177 4000K MP1201503-70-30 Curved Double Sided 170 3000K MP1201503-70-40 Curved Double Sided 185 4000K MP1201505-70-30 Curved Asymmetric 159 3000K MP1201505-70-40 Curved Asymmetric 169 4000K MP1201511-70-30 Flat Asymmetric 156 3000K Puck XT MP1201511-70-40 Flat Asymmetric 158 4000K MP1201513-70-30 Flat Double Sided 170 3000K MP1201513-70-40 Flat Double Sided 180 4000K
