PROJECT: ELECTRONIC MACHINE GENERATOR FOR WIND POWER TURBINE (EMG - PowerPoint PPT Presentation

PROJECT: « ELECTRONIC MACHINE GENERATOR FOR WIND POWER TURBINE » («EMG FOR WPT») PARTICIPANT: VDM-TECHNIKA LLC (RUSSIA) INVESTOR: SKOLKOVO FUND (RUSSIA) INVESTOR: OVERON GROUP CORPORATION (USA) MOSCOW, 05/02/2016

The average annual wind speed at 3-6 m/s is presented at no less than 50% of the Earth surface 2

WIND CLASSES IEC 61400 CLASS I CLASS II CLASS III CLASS IV WTG TYPE HIGH WIND MEDIUM WIND LOW WIND ULTRALOW WIND (8,5-10 m/s) (7,5-8,5 m/s) (6,0-7,5 m/s) (< 6,0 m/s) NORDEX N90/2500, N100-3300 VESTAS V105-3,3MW, V112-3,3 MW GOLDWIND GW 70/1500 NORDEX N100/2500, N117/3000 VESTAS V112-3,3MW, V117-3,3 MW GOLDWIND GW 77/1500 NORDEX N117/2400, N131/3000 VESTAS V126-3,3 MW GOLDWIND GW 82/1500 VDM-TECHNIKA 3

THE PROJECT SUMMARY THE PROJECT PRODUCT THE MAIN DIRECTIONS OF DEVELOPMENT Direct drive WPT with EMG. Rated wind speed at 6.5 m/s THE ESSENCE OF THE INNOVATION There are the technical decisions for WPT’s, affording efficient energy transformation of the low potential wind flow energy to the electric energy, based on the usage of EMG, allowing to regulate the electromagnetic torque on the generator’s shift in the extended range of rotation speeds, including the areas with the annual average wind speed at 3-6 m/s  Wind rotor, adapted to the low potential wind flow  The synchronous electric generator with a slotless designed stator that allows to lower starting torque at about 10 times  Electronic power converter (EPC) for adjusting the shaft torque and increasing the efficiency coefficient of EMG in the extended rotation speed range Normalized power output of WPT with EMG in comparison with analogs 4

COMPETITIVE ADVANTAGES The annual The cost of wind Rated Annual Rated Wind output of Rated power turbines for 1 wind power LCOE, Analogs Manufacturer Stage power, Turbine electricity per 1 wind turbine kW of installed speed, generation, USD/kWh kW Price, USD kW of installed capacity factor capacity, USD m/s kWh capacity, kWh 1 VDM-2 к W "VDM-tekhnika" LLC, Russia Development 2,0 8000 4000 6,5 5654 2827 0,32 0,18 2 Kestrel e400nb 3.5kW Eveready Diversified Products (Pty) On market 2,5 9700 3880 11,0 1880 752 0,09 0,67 250V Ltd, RSA 3 Skystream 3.7 Xzeres Wind Corporation, USA On market 2,4 15000 6250 13,0 1736 723 0,09 1,13 4 S-343 Endurance Wind Power Inc., USA On market 5,4 30600 5667 12,0 4078 755 0,09 0,98 5 EXCEL 6 BERGEY Windpower Company, USA On market 5,5 49170 8940 11,0 5522 1004 0,11 1,61 6 Evance Wind Turbines Limited, UK On market 4,7 48960 10417 11,0 4962 1056 0,12 1,29 Evance R9000 7 On market 5,2 48348 9298 13,0 4629 890 0,10 1,36 KW6 Kingspan Renewables Ltd., UK 8 On market 11,0 76500 6955 12,0 16220 1475 0,17 0,61 GW133-11 kW Gaia-Wind, UK 9 On market 10,0 70000 7000 13,8 7135 714 0,08 1,28 Excel 10 BERGEY Windpower Company, USA *Data referred to an average annual wind speed of 4 m/s **Calculations are made in accordance IEC 61400-2 Product design has unique competitive advantages in the segment of small wind 5

WIND ROTOR, ADAPTED TO THE LOW-POTENTIAL WIND FLOW. CALCULATION PROCEDURE We analyzed about 100 known wind rotor profiles and performed optimization calculations for 16 options of profile We selected 2 prototypes of wind rotors – output coefficient is 0,48-0,49 at the wind speed of 4-7 m/s. We created the calculation method 6

WIND ROTOR, ADAPTED TO THE LOW-POTENTIAL WIND FLOW. TEST The flow speed at 4 m/s, 10 rad/s The flow speed at 6 m/s, 14 rad/s Tests of the wind rotor prototype with diameter of 0.8 m on the aerodynamic stand The flow speed at 8 m/s, 18 rad/s 7

Design of WPT Strength and thermal calculations 8

STAND FOR SIMULATION OF WIND TURBINES BASED ON THE TEST BENCH FOR ELECTRICAL MOTORS CERTIFICATE № 432 -3582-15 FBU "TEST-S.- PETERSBURG“ ) R н Ключ ПК RS232/USB Коннектор ДН 2 U DC (t) CB-68LP ДТ 8 I DC (t) АЦП PCI-6220 ЭЭП ИРН ( Т ) RS232/USB Управляющая программа «CAN . vi» ДН 1 U AB (t) Ключ к ДТ 1... ДТ 8, ДТ 7 ДМ 1 I AB (t) 220 В AC Сеть БН +24 В DC AC-DC АВ Микропроцес сор 380 В AC Сеть АТ Трехфазный выпрямитель I DC (t) I U (t) M(t, ω НМ ) КВД I V (t) ДТ 4... ДТ 6 I W (t) Ключ T G (t) M(t), ω (t) ω (t) ДТ 1... ДТ 3 ТР Редуктор ЭМГ + М + ИД ДПР ДМ 1 Simulation of different wind regimes. Simulation modes of wind rotor, EMG with EPC. Measuring characteristics of EMG with EPC 9

WIND MEASURING SYSTEM. IEC 61400-12-1:2005 К фидеру БП 3 БП 1 ВК 1 220 В AC Galltec Mela KRC3/5 12V DC 24V DC GND БП 4 БП 2 12 V DC Barometric GND Heating Pressure Sensor 5 V DC 24V DC AB 100 GND1 V IN Anemometer Wind Speed 1 12V DC FLZ-520 Ethernet 24V DC Anemometer Wind Speed 2 Supply 24 V DC GND 5 V DC V IN Ethernet Ethernet GND GND 5 V DC Switch V IN Ammonit Meteo-40S A1 A2 A3 C1 C2 D1 Ethernet Ethernet Ethernet UP Link D А B А B А B CNT GND CNT GND IN CLK GND К серверу Wind Vane Thies TCP/IP First Class POT A1 A2, A3 C1 C2 D1 D P 0 24 V GND T 0 σ 0 24 V v 0 24 V GND v 0 24 V GND IN 24 V CLK GND GND Heating 24V DC GND1 P1 P2 P3 P4 P5 1 2 PE 1 2 PE 1 2 PE 1 2 PE 1 2 PE PHT-150 1P 2P PE 1P 2P PE 1P 2P PE 1P 2P PE 1P 2P PE Type of equipment Brand Н-15 The mast of WPT МС-14-76 Meteomast Cup anemometers Thies First Class Advanced Ultrasonic anemometer Young Model 86004 Measuring w ind direction Wind Vane Thies First Class POT Temperature and humidity sensor Galltec Mela KRC3/5 Atmospheric pressure sensor Ammonit AB100 Steel cabinet C6 (METEO-40) Type 650\11-04 Data logger Ammonit Meteo-40S Data logger storage Flash-Recorder-2-16RTC-SD Overvoltage protection Leutron DataPro 2x1-24V/24V-Tr Heater shield PHT-150 Temperature controller FLZ-520 Uninterruptible pow er supply BX800CI-RS/BX1100CI-RS 10

THE PROJECT REALIZATION THE RESULTS OF STAGE 1 OF THE PROJECT (APRIL-DECEMBER 2015) We designed, created and tested: • The prototype of the electronic machine generator with an electronic power converter • The wind rotor prototype with diameter of 0.8 m. We created bench for simulating the operation of the wind turbine based on the test bench for electrical motors (certificate № 432 -3582-15 "TEST-S.-Petersburg"). We designed a WPT with EMG, with rated wind speed at 6.5 m/s. We also created a test field for wind monitoring and full-scale testing of WPT with EMG. We file an international application PCT/RU2015/000918 from 12.23.2015, the patent for the invention “Power output take system of a wind motor” PLAN FOR STAGE 2 OF THE PROJECT (JANUARY-SEPTEMBER 2016) Producing the prototype of WPT with EMG of 2 kW capacity. Conducting full-scale tests of WPT with EMG according IEC 61400-12-1: 2005, certified experts DNV GL (http://www.dnvgl.com/about-dnvgl/default.aspx). The development of the commercial version of the Product with power output from 0.5 to 30 kW. Development of design documentation of pilot production and technology pilot production. Attraction of the investments 11

GENERAL MANAGER VDM-TECHNIKA LLC VLADIMIR G. MASOLOV, PH.D Thank you for attention! 12
