Product launch RPI M6A, M8A, M10A New design for more flexibility - PowerPoint PPT Presentation

Product launch RPI M6A, M8A, M10A New design for more flexibility Patrick SCHAHL / 22.05.2014 New June 2014 Delta Confidential 2014 : Delta launches three new inverters for home applications SOLIVIA 6.0 to 12TL EU T4 TL New RPI M6A, M8A,


  1. Product launch RPI M6A, M8A, M10A New design for more flexibility Patrick SCHAHL / 22.05.2014

  2. New June 2014 Delta Confidential

  3. 2014 : Delta launches three new inverters for home applications SOLIVIA 6.0 to 12TL EU T4 TL New RPI M6A, M8A, M10A Delta Confidential

  4. Technical points  3 phases inverters (6, 8 and 10KW)  Transformer less based technology  Dual MPPT > Automatic recognition (separate or //)  New concept of HMI interface > Easy installation Delta Confidential 4

  5. Technical points  High efficiency inverters : 98.3% / 98.5%  1000 V max DC voltage inverter  Ambient temperature -20°C~60°C. (power de-rating above 40°C)  33/67% asymmetric usability (only for 10TL) Delta Confidential 5

  6. Technical points  New size and housing  25 Kg  445*510*117mm Delta Confidential 6

  7. Technical points  Robust solution  IP65  For Indoor and outdoor usage  Natural cooling concept  Acoustic noise level < 35 dBa Delta Confidential 7

  8.  Flexible AC connections  Amphenol AC plug (same as 15/20TL)  3P3W (3-phase and PE)  L1-L2: 400 Vac ± 20%  3P4W (3-phase, N, and PE).  L1-N: 230 Vac ± 20%  Electrical DC/AC switch  2/3 pairs DC inputs Delta Confidential

  9. Technical points  communication port  RS485 bus / EPO and digital inputs  Compatible for monitoring with : Solivia Monitoring Meteocontrol Solarlog Delta Confidential 9

  10. Technical points  Two communication ports  RS485 bus / EPO, Dry contact, digital IN Delta Confidential 10

  11. Technical points Delta Confidential 11

  12. Technical points  RS485 communication network Delta Confidential 12

  13. Technical points  By using the new display concept ( 4 lines ) > 4 lines display / 20 char. > 4 buttons (same as 15/20TL) Delta Confidential

  14. Accessories  available into PV planner  available into Solivia Monitoring RPI M6A RPI602FA0E1000 RPI M8A RPI802FA0E1000 RPI M10A RPI103FA0E1000  5 years standard warranty, additional years as per price list Delta Confidential

  15. 400W/Kg ! 376 KW / m3 ! Delta Confidential 15

  16. Delta Confidential 16

  17. Delta Confidential 17

  18. Supported countries  Display  EN, FR, NL, DE  QSG / Manual  EN, FR, NL, DE (safety instruction in 20 languages)  Country settings  D/F/NL/B/A/CH/UK Delta Confidential 18

  19. Smarter. Greener. Together. www.deltaenergysystems.com Delta Confidential
