Presented by: Nilen Bermal – Technical Director Wonderware Southern Africa

The Industry Standard for Reporting Ocean Data Systems - a Global Company Selling through our Partners Founded 2004 by Experts from the World of Automation Global Company with Offices in USA, Germany, France, Israel and E. Europe A distributed Support Team delivering Follow-The-Sun support. An Installed Base of almost 10,000 Licenses, Globally Delivered Primarily as an OEM Solution, Branded, Resold and Supported by Industry Leaders such as Wonderware, GE, Schneider Electric and others

3 Reasons Why Customers Implement Dream Report NEED Information ▪ Compliance – they need this to run/stay in business WANT Information ▪ Information needed to run their business better SEEK Information ▪ Tools to better understand their data, and to empower their workforce

A Solution for All Reporting Needs

Dream Report is… … professional Designer- Friendly™ Reporting Software for Industrial & Process Automation Open & Direct Connectivity • Real- time connectivity to SCADAs, HMIs, PLCs, … • Direct connectivity to process Historians • Connectivity to business data sources & databases (SQL Server, MySQL, Oracle, …) Easy-to-use • Quick learning curve • No programming or scripting • No software development skills are required to design reports Scalable All-In-One Solution • Simple installation • Access to Aggregated, Live and Raw Historical Data • Produces Web, PDF, Excel, Database output • Automatically Send to Printer, Email and Browser

How it Works and What it Does Publish & Dream Report Studio Distribute Reports File Server FTP Server Email Printers Mobile Generate Reports Design & Configure Real-time Data Sources (PLC’s, HMI’s, etc.) Connect to Data Data Sources Logger Existing Data Archives (Historians, SQL DB’s, CSV, etc.)

Connectivity HMI/SCADA Historical Archives Open Protocols ` And, Manual Data Entry! Web Forms Other Data Sources Over 85 Drivers!

Integration with Wonderware Products Direct, and Easily Integrated with System Platform Native Driver MX + Galaxy Access The Benefit: InTouch Application ➢ Seamless Integration with Machine Server SuiteLink/OPC Existing Systems Edition SuiteLink ➢ Supported & Sold by the DA Wonderware Channel InTouch Real-time Servers (local and ➢ Certified and Endorsed by remote) Wonderware Dream Report Historical InTouch IntelaTrac LGH Direct driver Native Historian Wonderware HMI and SCADA Alarm driver Online Technology Partner Product of the Logger A 2 High WW Year! Speed Historian Direct Alarms Direct driver driver Direct WW SDK driver & OData

Integration with Other Schneider Electric Products InduSoft connectors: IWS real-time (Native API) ✓ IWS historical values (ODBC) ✓ IWS historical alarms (SDK) ✓ Citect connectors: CitectSCADA real-time values & alarms ✓ CitectSCADA historical logs (trend files) ✓ CitectSCADA historical logs (DBF files) ✓ Citect Historian historical values ✓ Citect Historian historical alarms ✓ IntelaTrac connectors: IntelaTrac historical values (ODBC) ✓

Integration with Other Schneider Electric Products Eurotherm connectors: Realtime Values ✓ Historical Values in Review ✓ Historical Alarms/Msgs in Review ✓ Realtime Batch Monitor in Review ✓ UHH DB, Historical and Files ✓ StruxureWare connectors: StruxureWare Central historical ✓ Schneider ION DB historical values ✓ ClearSCADA connectors: Historical values ✓ Historical Alarms & Events ✓ Real-time Values ✓

Report Configuration Environment User-friendly Environment Single-Node or Multi-Developer Dream Report Designer Integrated Graphical Objects Studio Built-in Statistical Functions Template-based Development Charts Tables Widgets Pictures

Repository-Based Project Configuration Project’s configuration completely contained in a single configuration database ➢ Simpler to Manage and to Secure ➢ Facilitates a True Multi-Developer Environment ▪ Local or Remote Developers ▪ Concurrent Project Development ▪ Project Integrity – Locking at Report and Module Level ▪ Maintains Configuration Audit Trail ▪ Project Deployment option – Develop and Test on a Test System, and Deploy to a Runtime/Production Server

Browser-based Portal – Any User, Any Time Secured Browser and Mobile access Report Review, Dashboards, Manual Data Entry & Ad-Hoc Use “Out of the Box” or Customize for User Selections, Drill -down, etc.

PC and Mobile Support - Automatically Drill Down and Review Data – Export to Excel, Email & Print

Manual Data Entry Enables users enter and save “manual data” through the DRWeb portal Simply create “web” reports >> data entry forms Data can be corrected and validated by other users Report on this data along with other process data

Batch Reports Dream Report can generate reports based on a Batch/Lot/ WorkOrder/RollID /etc. definition…. Batch Time-Period can be retrieved in 3 ways: 1. From a Realtime Tag 2. From an External Tag 3. From an External “Lookup” Database Dream Report determines the Start and End Times, and uses those in All Objects on the Report ➢ Then, trigger the report by real-time event (e.g., End-of- Batch PLC trigger, HMI action, etc.)

DEMO

Equipment & OEE Reports Dream Report has built-in functions to calculate: Equipment Running time Equipment Down time On Counter / Off Counter System Availability Production KPIs Conditional calculations Drive down Operating & Proactive Maintenance Reports - Automatic Report Generation Maintenance costs and Distribution with predictive maintenance Generate and send report as soon up-time reaches pre-defined value Generate and send service request upon equipment running time Let system analyze and control maintenance of your equipment for you!

Secure Environment Ready for Regulated/Validated Environments: User Management ▪ Local or Windows-integrated user management ▪ Support Windows local or/and domain users and user groups ▪ Extended user access control to reports and modules ▪ Localized language by User or Group This is significant in Version Control our industries - ▪ Secure version ID stamp on reports other reporting packages ▪ Track user changes in secure database don’t offer this! ▪ Ability to roll back to the specific (certified) report version Audit-Trail Recording ▪ Record all runtime activities Electronic-Signatures

Dream Report - Licensing Licensed by Tag Count and Web Clients Any number of reports can be created, as long as the number of tags licensed is not exceeded Tag - any external item/entity that Dream Report references in a report: ▪ HMI or Historian Tag ▪ PLC Register ▪ Database Field (but not alarm tags exposed through an Alarms driver) A Tag, exposed through a specific instance of a Communication Driver, is only counted once (even if used on multiple reports)

In Summary Wide Range of Easily Turn Raw Connectivity Real Time/Historical Data into KPI’s access to Data Dream FDA Approved Report Compliance Time to Delivery FDA/Archive Ease of Use File Server FTP Server Email Printers Mobile
